MFC界面美化第三篇----自绘按钮(重绘按钮)

1.前言

最近发现读者对我的mfc美化的专栏比较感兴趣，因此在这里进行续写，这里我会计划写几个连续的篇章，包括对MFC按钮的美化，菜单栏的美化，标题栏的美化，list列表的美化，直到最后形成一个完整的成品效果。

2.最终效果展示

点击启动按钮之后，能响应功能。

博主不会UI设计图片显示的效果比较差，用更好的图片贴上去，就能显示更好的效果的

3.思路分析

1.使用我们设计好的图片，来美化按钮。把图片贴到按钮上

2.创建一个按钮类，继承CButton,来重绘按钮

3.核心还是重写了 DrawItem，函数来实现重绘的效果

4.实现过程

1.在MFC的界面那里，创建两个按钮，启动和停止按钮。

2.找到按钮的属性那里，把所有者描述改成true,不然重绘是不能成功的，这一步是一定要做的

3.核心代码

头文件里面声明按钮变量

public:CMyButton m_button_start;CMyButton m_button_stop;afx_msg void OnBnClickedButton2();afx_msg void OnBnClickedButton1();

OnInitDialog()函数

BOOL CMFCDrawnTitleDlg::OnInitDialog()
{CDialogEx::OnInitDialog();// 将“关于...”菜单项添加到系统菜单中。// IDM_ABOUTBOX 必须在系统命令范围内。ASSERT((IDM_ABOUTBOX & 0xFFF0) == IDM_ABOUTBOX);ASSERT(IDM_ABOUTBOX < 0xF000);CMenu* pSysMenu = GetSystemMenu(FALSE);if (pSysMenu != nullptr){BOOL bNameValid;CString strAboutMenu;bNameValid = strAboutMenu.LoadString(IDS_ABOUTBOX);ASSERT(bNameValid);if (!strAboutMenu.IsEmpty()){pSysMenu->AppendMenu(MF_SEPARATOR);pSysMenu->AppendMenu(MF_STRING, IDM_ABOUTBOX, strAboutMenu);}}// 设置此对话框的图标。  当应用程序主窗口不是对话框时，框架将自动//  执行此操作SetIcon(m_hIcon, TRUE);			// 设置大图标SetIcon(m_hIcon, FALSE);		// 设置小图标// TODO: 在此添加额外的初始化代码//退出按钮绘制CRect rtBtnClo;GetClientRect(&rtBtnClo);rtBtnClo.left = rtBtnClo.right - 20;m_btnExit.SetImagePath(_T(".\\res\\icon_popup_off.png"), _T(".\\res\\icon_popup_off.png"), _T(".\\res\\icon_popup_off.png"));m_btnExit.InitMyButton(rtBtnClo.left, 5, 16, 16, true);//最大化按钮绘制GetClientRect(&rtBtnClo);rtBtnClo.left = rtBtnClo.right - 50;m_btnMax.SetImagePath(_T(".\\res\\icon_square.png"), _T(".\\res\\icon_square.png"), _T(".\\res\\icon_square.png"));m_btnMax.InitMyButton(rtBtnClo.left, 5, 16, 16, true);//最小化按钮// GetClientRect(&rtBtnClo);rtBtnClo.left = rtBtnClo.right - 80;m_btnMin.SetImagePath(_T(".\\res\\icon_minimiz.png"), _T(".\\res\\icon_minimiz.png"), _T(".\\res\\icon_minimiz.png"));m_btnMin.InitMyButton(rtBtnClo.left, 5, 16, 16, true);return TRUE;  // 除非将焦点设置到控件，否则返回 TRUE
}

5.button重绘的头文件和cpp文件

mybutton.h

pch.h, 和framework.h这两个文件的路径，可以改的。根据你的项目文件实际放置情况

#pragma once#include <afxwin.h>
#include "../pch.h"
#include "../framework.h"
// CMyButtonclass CMyButton : public CButton
{DECLARE_DYNAMIC(CMyButton)public:CMyButton();virtual ~CMyButton();protected://正常状态图像路径CString m_strNormalImgPath;//按下状态图像路径CString m_strPressImgPath;//悬浮状态图像路径CString m_strFloatImgPath;//正常状态图像CImage m_imgNormal;//按下状态图像CImage m_imgPress;//悬浮状态图像CImage m_imgFloat;//窗口背景图片CImage m_BkImg;public://设置按钮图片路径void SetImagePath(CString strNoramlImgPath, CString strPressImgPath, CString strFloatImgPath);//初始化按钮，主要是调整按钮的位置，处理透明色  bool InitMyButton(int nX/*左上角X坐标*/, int nY/*左上角Y坐标*/, int nW/*图像宽*/, int nH/*图像高*/, bool bIsPng/*是否是PNG图片*/);//自绘制函数  void DrawItem(LPDRAWITEMSTRUCT lpDrawItemStruct);//初始化窗口背景void SetBkImg(CString strBkImg);//释放图片资源，方便最大化 void ReleaseImg();
protected://光标是否在窗口内BOOL m_bIsInWnd;DECLARE_MESSAGE_MAP()
public:afx_msg void OnMouseMove(UINT nFlags, CPoint point);afx_msg void OnMouseHover(UINT nFlags, CPoint point);afx_msg void OnMouseLeave();};

mybutton.cpp

// MyButton.cpp : 实现文件
//#include "pch.h"
#include "MyButton.h"// CMyButtonIMPLEMENT_DYNAMIC(CMyButton, CButton)CMyButton::CMyButton()
{m_bIsInWnd = FALSE;
}CMyButton::~CMyButton()
{
}BEGIN_MESSAGE_MAP(CMyButton, CButton)ON_WM_MOUSEMOVE()ON_WM_MOUSEHOVER()ON_WM_MOUSELEAVE()
END_MESSAGE_MAP()// CMyButton 消息处理程序//设置按钮图片路径
void CMyButton::SetImagePath(CString strNoramlImgPath, CString strPressImgPath, CString strFloatImgPath)
{m_strNormalImgPath = strNoramlImgPath;m_strPressImgPath = strPressImgPath;m_strFloatImgPath = strFloatImgPath;
}void CMyButton::SetBkImg(CString strBkImg)
{if (strBkImg.IsEmpty())return;m_BkImg.Load(strBkImg);
}//初始化按钮，主要是调整按钮的位置，处理透明色
void CMyButton::ReleaseImg()
{if (m_imgNormal){m_imgNormal.Destroy();}if (m_imgPress){m_imgPress.Destroy();}if (m_imgFloat){m_imgFloat.Destroy();}
}
bool CMyButton::InitMyButton(int nX/*左上角X坐标*/, int nY/*左上角Y坐标*/, int nW/*图像宽*/, int nH/*图像高*/, bool bIsPng/*是否是PNG图片*/)
{HRESULT hr = 0;if (m_strNormalImgPath.IsEmpty())return false;if (m_strPressImgPath.IsEmpty())return false;if (m_strFloatImgPath.IsEmpty())return false;hr = m_imgNormal.Load(m_strNormalImgPath);int a = GetLastError();if (FAILED(hr))return false;hr = m_imgPress.Load(m_strPressImgPath);if (FAILED(hr))return false;hr = m_imgFloat.Load(m_strFloatImgPath);if (FAILED(hr))return false;if (bIsPng){if (m_imgNormal.GetBPP() == 32){int i = 0;int j = 0;for (i = 0; i < m_imgNormal.GetWidth(); i++){for (j = 0; j < m_imgNormal.GetHeight(); j++){byte * pbyte = (byte *)m_imgNormal.GetPixelAddress(i, j);pbyte[0] = pbyte[0] * pbyte[3] / 255;pbyte[1] = pbyte[1] * pbyte[3] / 255;pbyte[2] = pbyte[2] * pbyte[3] / 255;}}}if (m_imgPress.GetBPP() == 32){int i = 0;int j = 0;for (i = 0; i < m_imgPress.GetWidth(); i++){for (j = 0; j < m_imgPress.GetHeight(); j++){byte * pbyte = (byte *)m_imgPress.GetPixelAddress(i, j);pbyte[0] = pbyte[0] * pbyte[3] / 255;pbyte[1] = pbyte[1] * pbyte[3] / 255;pbyte[2] = pbyte[2] * pbyte[3] / 255;}}}if (m_imgFloat.GetBPP() == 32){int i = 0;int j = 0;for (i = 0; i < m_imgFloat.GetWidth(); i++){for (j = 0; j < m_imgFloat.GetHeight(); j++){byte * pbyte = (byte *)m_imgFloat.GetPixelAddress(i, j);pbyte[0] = pbyte[0] * pbyte[3] / 255;pbyte[1] = pbyte[1] * pbyte[3] / 255;pbyte[2] = pbyte[2] * pbyte[3] / 255;}}}}MoveWindow(nX, nY, nW, nH);return true;}
//自绘制函数
void CMyButton::DrawItem(LPDRAWITEMSTRUCT lpDrawItemStruct)
{if (!lpDrawItemStruct)return;HDC hMemDC;HBITMAP bmpMem;HGDIOBJ hOldObj;bmpMem = CreateCompatibleBitmap(lpDrawItemStruct->hDC, lpDrawItemStruct->rcItem.right - lpDrawItemStruct->rcItem.left, lpDrawItemStruct->rcItem.bottom - lpDrawItemStruct->rcItem.top);if (!bmpMem)return;hMemDC = CreateCompatibleDC(lpDrawItemStruct->hDC);if (!hMemDC){if (bmpMem){::DeleteObject(bmpMem);bmpMem = NULL;}return;}hOldObj = ::SelectObject(hMemDC, bmpMem);int nW = lpDrawItemStruct->rcItem.right - lpDrawItemStruct->rcItem.left;int nH = lpDrawItemStruct->rcItem.bottom - lpDrawItemStruct->rcItem.top;RECT rectTmp = { 0 };rectTmp = lpDrawItemStruct->rcItem;MapWindowPoints(GetParent(), &rectTmp);if (m_BkImg.IsNull() == false)m_BkImg.Draw(hMemDC, 0, 0, rectTmp.right - rectTmp.left, rectTmp.bottom - rectTmp.top, rectTmp.left, rectTmp.top, rectTmp.right - rectTmp.left, rectTmp.bottom - rectTmp.top);if (lpDrawItemStruct->itemState & ODS_SELECTED){//按钮被选择  m_imgPress.AlphaBlend(hMemDC, 0, 0, nW, nH, 0, 0, nW, nH);}else{//默认状态  m_imgNormal.AlphaBlend(hMemDC, 0, 0, nW, nH, 0, 0, nW, nH);}::BitBlt(lpDrawItemStruct->hDC, 0, 0, nW, nH, hMemDC,0,0,SRCCOPY);SelectObject(hMemDC, hOldObj);if (bmpMem){::DeleteObject(bmpMem);bmpMem = NULL;}if (hMemDC){::DeleteDC(hMemDC);hMemDC = NULL;}return;
}void CMyButton::OnMouseMove(UINT nFlags, CPoint point)
{// TODO:  在此添加消息处理程序代码和/或调用默认值CButton::OnMouseMove(nFlags, point);if (!m_bIsInWnd){TRACKMOUSEEVENT       tme;tme.cbSize = sizeof(TRACKMOUSEEVENT);tme.dwFlags = TME_HOVER | TME_LEAVE;tme.dwHoverTime = 10;tme.hwndTrack = m_hWnd;_TrackMouseEvent(&tme);m_bIsInWnd = TRUE;}
}void CMyButton::OnMouseHover(UINT nFlags, CPoint point)
{// TODO:  在此添加消息处理程序代码和/或调用默认值HDC hMemDC;HBITMAP bmpMem;HGDIOBJ hOldObj;HDC hDC = ::GetDC(GetSafeHwnd());CRect rcItem;GetClientRect(&rcItem);if (hDC){bmpMem = CreateCompatibleBitmap(hDC, rcItem.Width(), rcItem.Height());if (!bmpMem){::ReleaseDC(GetSafeHwnd(), hDC);return;}hMemDC = CreateCompatibleDC(hDC);if (!hMemDC){if (bmpMem){::DeleteObject(bmpMem);bmpMem = NULL;}::ReleaseDC(GetSafeHwnd(), hDC);return;}hOldObj = ::SelectObject(hMemDC, bmpMem);RECT rectTmp = { 0 };rectTmp = rcItem;MapWindowPoints(GetParent(), &rectTmp);if (m_BkImg.IsNull() == false)m_BkImg.Draw(hMemDC, 0, 0, rectTmp.right - rectTmp.left, rectTmp.bottom - rectTmp.top, rectTmp.left, rectTmp.top, rectTmp.right - rectTmp.left, rectTmp.bottom - rectTmp.top);int nW = rcItem.right - rcItem.left;int nH = rcItem.bottom - rcItem.top;m_imgFloat.AlphaBlend(hMemDC, 0, 0, nW, nH, 0, 0,nW,nH);::BitBlt(hDC, 0, 0, nW, nH, hMemDC, 0, 0, SRCCOPY);SelectObject(hMemDC, hOldObj);if (bmpMem){::DeleteObject(bmpMem);bmpMem = NULL;}if (hMemDC){::DeleteDC(hMemDC);hMemDC = NULL;}::ReleaseDC(GetSafeHwnd(), hDC);}CButton::OnMouseHover(nFlags, point);
}void CMyButton::OnMouseLeave()
{// TODO:  在此添加消息处理程序代码和/或调用默认值CButton::OnMouseLeave();InvalidateRect(NULL);m_bIsInWnd = FALSE;
}
