SSM整合RabbitMQ，Spring4.x整合RabbitMQ

前言

SSM框架整合RabbitMQ【比较简单，复制粘贴可用】
本人使用的Spring版本是4.x

版本

RabbitMQ相关
erl10.0.1
RabbitMQ3.7.9
安装步骤参考：https://www.cnblogs.com/saryli/p/9729591.html

相关依赖
spring4.0.2.RELEASE
spring-rabbit1.3.5.RELEASE

实现

目录参考

这是我整合时的项目结构
关键：rabbitmq文件包和rabbitmq.properties、spring-rabbitmq.xml、spring-mvc.xml

pom.xml依赖

在现成的SSM项目中整合

	<!--rabbitmq依赖 --><dependency><groupId>org.springframework.amqp</groupId><artifactId>spring-rabbit</artifactId><version>1.3.5.RELEASE</version></dependency>

rabbitmq.properties配置文件

将 rabbitmq.properties配置文件添加到resources目录下

mq.host=127.0.0.1
mq.username=guest
mq.password=guest
mq.port=5672
mq.virtual-host=/

spring-rabbitmq.xml

将spring-rabbitmq.xml添加到resources目录下

<?xml version="1.0" encoding="UTF-8"?>
<beans 	xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:context="http://www.springframework.org/schema/context" xmlns:rabbit="http://www.springframework.org/schema/rabbit"xsi:schemaLocation="http://www.springframework.org/schema/beanshttp://www.springframework.org/schema/beans/spring-beans-4.0.xsdhttp://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-4.0.xsdhttp://www.springframework.org/schema/rabbithttp://www.springframework.org/schema/rabbit/spring-rabbit-1.3.xsd"><!-- 引入连接配置文件 --><bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer">    <property name="location" value="classpath:rabbitmq.properties" /></bean> <!-- 定义rabbitmq connectionFactory连接工厂 --><rabbit:connection-factory id="connectionFactory"username="${mq.username}"password="${mq.password}" host="${mq.host}" port="${mq.port}"virtual-host="${mq.virtual-host}" /><!--通过指定下面的admin信息，当前producer中的exchange和queue会在rabbitmq服务器上自动生成 --><rabbit:admin id="connectAdmin" connection-factory="connectionFactory" /><!--定义queue队列 --><rabbit:queue name="queueTest" durable="true" auto-delete="false" exclusive="false" declared-by="connectAdmin" /><rabbit:queue name="queueTest1" durable="true" auto-delete="false" exclusive="false" declared-by="connectAdmin" /><!-- 定义direct exchange（也就是交换机），绑定queueTest队列（queueTest名称可以自定义） --><rabbit:direct-exchange name="exchangeTest" durable="true" auto-delete="false" declared-by="connectAdmin"><rabbit:bindings><rabbit:binding queue="queueTest" key="queueTestKey"></rabbit:binding><rabbit:binding queue="queueTest1" key="queueTestKey1"></rabbit:binding></rabbit:bindings></rabbit:direct-exchange><!--定义rabbit template用于数据的接收和发送 将amqpTemplate对象绑定exchange中交换机--><rabbit:template id="amqpTemplate" connection-factory="connectionFactory" exchange="exchangeTest" /><!-- 消息接收处理 --><bean id="messageReceiver" class="com.rabbitmq.MessageConsumer"></bean><bean id="messageReceiver1" class="com.rabbitmq.MessageConsumer2"></bean><!-- queue litener 观察 监听模式 当有消息到达时会通知监听在对应的队列上的监听对象（监听），acknowledge="manual"设置消息手动确认（手动确认需要配合ack，不设置默认自动确认）  --><rabbit:listener-container connection-factory="connectionFactory" acknowledge="manual"><rabbit:listener queues="queueTest" ref="messageReceiver" /><rabbit:listener queues="queueTest1" ref="messageReceiver1" /></rabbit:listener-container><!-- 扫描注入使用注解实例对象 --><context:component-scan base-package="com.rabbitmq" /></beans>

spring-mvc.xml或applicationContext.xml

我这里使用的spring-mvc.xml，根据自己配置文件使用

<import resource="classpath:spring-rabbitmq.xml" />

将这个import引入添加到 spring-mvc.xml 里的最前面，如果不添加到前面可能会报错

rabbitmq目录下

这个目录下的java文件已在spring-rabbitmq.xml中进行扫描注入

MessageConsumer.java

说明：MessageConsumer和MessageConsumer2其实都可以使用同一个类，修改xml指向即可，但是分开明了些

package com.rabbitmq;import java.nio.charset.Charset;import org.springframework.amqp.core.Message;
import org.springframework.amqp.core.MessageListener;/*** @Title消息消费者* @date 2023/10/8*/
public class MessageConsumer implements MessageListener {@Overridepublic void onMessage(Message message) {// 逻辑处理System.out.println("message------->:" + new String(message.getBody(), Charset.forName("utf-8")));}}

MessageConsumer2.java

package com.rabbitmq;import java.nio.charset.Charset;import org.springframework.amqp.core.Message;
import org.springframework.amqp.core.MessageListener;/*** @Title消息消费者2* @date 2023/10/8*/
public class MessageConsumer2 implements MessageListener {@Overridepublic void onMessage(Message message) {// 逻辑处理System.out.println("message2------->:" + new String(message.getBody(), Charset.forName("utf-8")));}}

MessageProducer.java

package com.rabbitmq;import javax.annotation.Resource;import org.springframework.amqp.core.AmqpTemplate;
import org.springframework.stereotype.Service;/*** @Title 消息生产者* @date 2023/10/8*/
@Service
public class MessageProducer {@Resourceprivate AmqpTemplate amqpTemplate;public void sendMessage(String key, Object message){amqpTemplate.convertAndSend(key, message);}}

MessageConstant.java

package com.rabbitmq;/*** @Title 消息队列常量* @date 2023/10/8*/
public class MessageConstant{public static String queueTestKey = "queueTestKey";public static String queueTestKey1 = "queueTestKey1";}

测试调用

比如这个下面在某个类里作为接口调用测试

	@Autowiredprivate MessageProducer messageProducer;@RequestMapping(value = "/testMq")@ResponseBodypublic Result testMq(HttpServletRequest request) throws IOException {messageProducer.sendMessage(MessageConstant.queueTestKey, "登录");messageProducer.sendMessage(MessageConstant.queueTestKey1, "退出");return Result.success("测试成功");}

调用接口后打印结果

连接结果

以上即可！

扩展

包括消息手动确认，消息失败重新加入队列处理

消息重发

SpringBoot版可在配置文件中设置，且异常后直接抛出即可

方式一

package com.rabbitmq;import java.nio.charset.Charset;import org.springframework.amqp.core.Message;
import org.springframework.amqp.rabbit.core.ChannelAwareMessageListener;import com.rabbitmq.client.Channel;/*** @Title 消息消费者* @date 2023/10/8*/
public class MessageConsumer2 implements ChannelAwareMessageListener {private int aa = 1;@Overridepublic void onMessage(Message message, Channel channel) throws Exception {try {// 逻辑处理if(aa == 1) {aa = 2;int a = 1/0;}System.out.println("成功处理确认message2------->:" + new String(message.getBody(), Charset.forName("utf-8")));// 消费者ack确认【消息处理成功确认】channel.basicAck(message.getMessageProperties().getDeliveryTag(), false);}catch (Exception e) {System.out.println("失败重新入队message2------->:" + new String(message.getBody(), Charset.forName("utf-8")));// 消费者reject确认【消息失败重新加入队列-重发】channel.basicReject(message.getMessageProperties().getDeliveryTag(), true);}}}

方式二

MessageConstant.java中加入

	/** 重试次数 3 */public static Integer RETRY_COUNT = 3;

消息接收处理类

package com.rabbitmq;import java.nio.charset.Charset;import org.apache.log4j.Logger;
import org.springframework.amqp.core.Message;
import org.springframework.amqp.rabbit.core.ChannelAwareMessageListener;
import org.springframework.beans.factory.annotation.Autowired;import com.alibaba.fastjson.JSONObject;
import com.bean.ConsumptionRequest;
import com.rabbitmq.client.Channel;
import com.service.ReceiveDormitoryService;/*** 宿舍mq消息处理* * @author Administrator*/
public class MessageConsumerSuShe implements ChannelAwareMessageListener {private final Logger logger = Logger.getLogger(MessageConsumerSuShe.class);@Autowiredprivate ReceiveDormitoryService service;@Overridepublic void onMessage(Message message, Channel channel) throws Exception {int retryCount = 0; // 重试机制long deliveryTag = message.getMessageProperties().getDeliveryTag();while(retryCount < MessageConstant.RETRY_COUNT) {retryCount ++;try {// 逻辑处理String s = new String(message.getBody(), Charset.forName("utf-8"));ConsumptionRequest bean = JSONObject.parseObject(s, ConsumptionRequest.class);//service.uploadData(bean, bean.getPath());//logger.info("【SUSHE_QUEUE_KEY宿舍队列成功】：" + new String(message.getBody(), Charset.forName("utf-8")));// 消费者ack确认【消息处理成功确认】channel.basicAck(deliveryTag, false);return;}catch (Exception e) {logger.error("【SUSHE_QUEUE_KEY宿舍队列错误，重试"+retryCount+"】：" + new String(message.getBody(), Charset.forName("utf-8")));// 0.5s重试一次Thread.sleep(500);}}// 重试3次后直接处理（这里设置为死信消息）if(retryCount >= MessageConstant.RETRY_COUNT) {channel.basicNack(deliveryTag, false, false);}}}

多部署Tomcat下问题

本人使用单个RabbitMQ服务
测试两个Tomcat服务连接同一个交换机和队列进行发送消息，并没有造成两个Tomcat服务都推送处理这条消息，而是单个Tomcat处理了这条消息
所以未造成多部署下一条消息多服务处理问题

其他
参考类似博客1：https://blog.csdn.net/u012988901/article/details/89499634
参考类似博客2：https://blog.csdn.net/weixin_42654295/article/details/109006276
