linux驱动开发环境搭建

使用的是parallel 创建的ubuntu 16.04 ubuntu20.04虚拟机

源码准备

# 先查看本机版本
$ uname -r
5.15.0-86-generic# 搜索相关源码
$ sudo apt-cache search linux-source
[sudo] password for showme:
linux-source - Linux kernel source with Ubuntu patches
linux-source-5.4.0 - Linux kernel source for version 5.4.0 with Ubuntu patches
linux-gkeop-source-5.4.0 - Linux kernel source for version 5.4.0 with Ubuntu patches
linux-hwe-5.11-source-5.11.0 - Linux kernel source for version 5.11.0 with Ubuntu patches
linux-hwe-5.13-source-5.13.0 - Linux kernel source for version 5.13.0 with Ubuntu patches
linux-hwe-5.15-source-5.15.0 - Linux kernel source for version 5.15.0 with Ubuntu patches
linux-hwe-5.8-source-5.8.0 - Linux kernel source for version 5.8.0 with Ubuntu patches
linux-intel-5.13-source-5.13.0 - Linux kernel source for version 5.13.0 with Ubuntu patches# 下载源码，源码会下载到/usr/src目录下
$ sudo apt install linux-source-5.4.0showme@showme:/usr/src/linux-source-5.4.0$ ls -l
total 131816
drwxr-xr-x 15 root root      4096 10月 31 03:28 debian
drwxr-xr-x  9 root root      4096 10月 31 03:28 debian.master
-rw-r--r--  1 root root 134966876 10月  3 02:13 linux-source-5.4.0.tar.bz2# 复制linux-source-5.4.0.tar.bz2，编译两份，一份用于内核安装，一份用于clion驱动开发代码提示
# 用于内核安装的，会编译很多驱动，用clion打开会很卡，需要大概16G内存，才能不卡
# 用于开发环境的，编译会很快，用clion打开也会很快，代码提示时，也不会卡

安装编译依赖

# 安装所需要依赖的库
sudo apt-get install libncurses5-dev gcc make bc g++ vim git bc flex bison libssl-dev dwarves libelf-dev automake autoconf cvs subversion ruby
# 安装 bear 用于clion打开内核源码
sudo apt install bear
# 下载kernel-grok用于clion打开内核源码
git clone https://github.com/habemus-papadum/kernel-grok

编译内核

在编译的时候把虚拟机分配8核，8G内存，开发的时候2核，4G内存就够了

编译用于clion打开的内核

# 解压linux-source-5.4.0.tar.bz2源码，进入到linux-source-5.4.0目录
# 配置
make menuconfig# 修改配置文件 .config
# 搜索debian关键字,如果存在如下内容
CONFIG_SYSTEM_TRUSTED_KEYS="debian/canonical-certs.pem"
CONFIG_SYSTEM_REVOCATION_KEYS="debian/canonical-revoked-certs.pem"
# 将其清空
CONFIG_SYSTEM_TRUSTED_KEYS=""
CONFIG_SYSTEM_REVOCATION_KEYS=""# 使用bear编译内核，只生成bzImage和vmlinux编译很快
bear make bzImage vmlinux -j16# 生成内核源码的 CMakeLists.txt，需要进入内核源码目录下，执行
~/kernel-grok/generate_cmake# clion打开 CMakeLists.txt ，并添加如下内容
cmake_minimum_required(VERSION 2.8.8)
project(kernel)set(SYSROOT sysroot)
SET(CMAKE_C_COMPILER "gcc")
set(CMAKE_C_STANDARD 90)
set(CMAKE_C_FLAGS  ${CMAKE_C_FLAGS} " --sysroot=${SYSROOT}" )include_directories("include")
include_directories("include/uapi")
include_directories("include/generated")
include_directories("arch/x86/include")
include_directories("arch/x86/include/uapi")
include_directories("arch/x86/include/generated")
include_directories("arch/x86/include/generated/uapi")add_definitions(-D__KERNEL__)

编译用于安装的内核

# 解压linux-source-5.4.0.tar.bz2源码，进入到linux-source-5.4.0目录
sudo make oldconfig #按原有kernel配置配置kernel
sudo make #编译内核，时间较长，可能会长达1小时及以上，如5.4.0用时约3-5个小时
sudo make modules_install #安装内核模块
sudo make install # 安装内核
