全志A133 android10 LVDS幅值调节

一，问题现象

系统使用LVDS接口屏幕，进入系统有些界面会闪，图像抖动；

---

二，解决办法：

1.调试

调节LCD0的LVDS电压幅度，寄存器地址是0x06511220（具体是在User Manual中的LCD LVDS Analog Register 0），bit19:bit17控制差模电压大小，bit10:bit8控制共模电压大小。

kernel调试命令：

echo 0x06511220 >/sys/class/sunxi_dump/dump&&cat /sys/class/sunxi_dump/dump
echo 0x06511220 0xc1fe0320 > /sys/class/sunxi_dump/write

2.代码固化

参考如下,uboot和kernel都需要修改，然后读取寄存器检查是否设置成功。

diff --git a/longan/kernel/linux-4.9/drivers/video/fbdev/sunxi/disp2/disp/de/lowlevel_v2x/de_lcd.c b/longan/kernel/linux-4.9/drivers/video/fbdev/sunxi/disp2/disp/de/lowlevel_v2x/de_lcd.c
index a8335b8072..493e654c64 100644
--- a/longan/kernel/linux-4.9/drivers/video/fbdev/sunxi/disp2/disp/de/lowlevel_v2x/de_lcd.c
+++ b/longan/kernel/linux-4.9/drivers/video/fbdev/sunxi/disp2/disp/de/lowlevel_v2x/de_lcd.c
@@ -380,10 +380,10 @@ s32 lvds_open(u32 sel, struct disp_panel_para *panel)if (sel == 0)lvds_combphy_open(sel, panel);
#endif
-               lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 2;
+               lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 3;lcd_dev[sel]->tcon0_lvds_ana[0].bits.v = 3;lcd_dev[sel]->tcon0_lvds_ana[0].bits.pd = 2;
-               lcd_dev[sel]->tcon0_lvds_ana[1].bits.c = 2;
+               lcd_dev[sel]->tcon0_lvds_ana[1].bits.c = 3;lcd_dev[sel]->tcon0_lvds_ana[1].bits.v = 3;lcd_dev[sel]->tcon0_lvds_ana[1].bits.pd = 2;
@@ -414,10 +414,10 @@ s32 lvds_open(u32 sel, struct disp_panel_para *panel)if (sel == 0)lvds_combphy_open(sel, panel);
#endif
-               lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 2;
+               lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 3;lcd_dev[sel]->tcon0_lvds_ana[0].bits.v = 3;lcd_dev[sel]->tcon0_lvds_ana[0].bits.pd = 2;
-               lcd_dev[sel]->tcon0_lvds_ana[1].bits.c = 2;
+               lcd_dev[sel]->tcon0_lvds_ana[1].bits.c = 3;lcd_dev[sel]->tcon0_lvds_ana[1].bits.v = 3;lcd_dev[sel]->tcon0_lvds_ana[1].bits.pd = 2;@@ -445,6 +445,7 @@ s32 lvds_open(u32 sel, struct disp_panel_para *panel)
#if defined(SUPPORT_COMBO_DPHY)if (sel == 0) {lvds_combphy_open(sel, panel);
+                       lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 3;} else {lcd_dev[sel]->tcon0_lvds_ana[0].bits.c = 2;lcd_dev[sel]->tcon0_lvds_ana[0].bits.v = 3;
@@ -467,7 +468,7 @@ s32 lvds_open(u32 sel, struct disp_panel_para *panel)}
#else{
-                       lcd_dev[sel]->tcon0_lvds_ana[sel].bits.c = 2;
+                       lcd_dev[sel]->tcon0_lvds_ana[sel].bits.c = 3;lcd_dev[sel]->tcon0_lvds_ana[sel].bits.v = 3;lcd_dev[sel]->tcon0_lvds_ana[sel].bits.pd = 2;

3. 检查

读取寄存器检查值是否为所设值

echo 0x06511220 >/sys/class/sunxi_dump/dump&&cat /sys/class/sunxi_dump/dump
