MFC用List Control 和Picture控件实现界面切换效果

添加List Control 和Picture控件

添加 3个子窗体

把子窗体边框设置为None, 样式设为Child

声明

	CListCtrl m_listPageForm;void ShowForm(int nIndex);void CreatFormList();

void CMFCApplication3Dlg::DoDataExchange(CDataExchange* pDX)
{CDialogEx::DoDataExchange(pDX);DDX_Control(pDX, IDC_LIST_PAGE, m_listPageForm);
}

List控件和子窗体初始化

void CMFCApplication3Dlg::CreatFormList()
{CImageList imgList;imgList.Create(16, 16, ILC_COLOR8 | ILC_MASK, 0, 0);m_listPageForm.SetImageList(&imgList, LVSIL_SMALL);imgList.Add(::AfxGetApp()->LoadIcon(IDR_MAINFRAME));imgList.Detach();CRect rect;GetDlgItem(IDC_STATIC_RECT)->GetWindowRect(rect);rect.DeflateRect(1, 1);ScreenToClient(&rect);page1* pHang = new page1;pHang->Create(IDD_DIALOG1, this);pHang->MoveWindow(rect);pHang->ShowWindow(SW_SHOW);m_listPageForm.InsertItem(0, TEXT("界面1"), 0);m_listPageForm.SetItemData(0, (DWORD_PTR)pHang);page2* pSkill = new page2;pSkill->Create(IDD_DIALOG2, this);pSkill->MoveWindow(rect);m_listPageForm.InsertItem(1, TEXT("界面2"), 0);m_listPageForm.SetItemData(1, (DWORD_PTR)pSkill);page3* pbag = new page3;pbag->Create(IDD_DIALOG3, this);pbag->MoveWindow(rect);m_listPageForm.InsertItem(2, TEXT("界面3"), 0);m_listPageForm.SetItemData(2, (DWORD_PTR)pbag);
}

BOOL CMFCApplication3Dlg::OnInitDialog()
{......SetIcon(m_hIcon, TRUE);			// 设置大图标SetIcon(m_hIcon, FALSE);		// 设置小图标CreatFormList();return TRUE;
}

List控件的左键点击

void CMFCApplication3Dlg::OnNMClickListPage(NMHDR* pNMHDR, LRESULT* pResult)
{LPNMITEMACTIVATE pNMItemActivate = reinterpret_cast<LPNMITEMACTIVATE>(pNMHDR);// TODO: 在此添加控件通知处理程序代码	if (-1 == pNMItemActivate->iItem) return;ShowForm(pNMItemActivate->iItem);*pResult = 0;
}

void CMFCApplication3Dlg::ShowForm(int nIndex)
{ CDialog* pForm = NULL; for (int i = 0; i < m_listPageForm.GetItemCount(); ++i){ pForm = (CDialog*)(DWORD_PTR)m_listPageForm.GetItemData(i);//获取所有的窗口页面if (pForm) pForm->ShowWindow(SW_HIDE);//如果pform为空，都隐藏掉 pForm = (CDialog*)(DWORD_PTR)m_listPageForm.GetItemData(nIndex);//根据索引把选中的要显示的窗口拿出来if (pForm) pForm->ShowWindow(SW_SHOW);//如果pform为空，显示选中的窗口}
}

运行效果
