k8s常见的资源对象使用
目录
一、kubernetes内置资源对象
1.1、kubernetes内置资源对象介绍
1.2、kubernetes资源对象操作命令
二、job与cronjob计划任务
2.1、job计划任务
2.2、cronjob计划任务
三、RC/RS副本控制器
3.1、RC副本控制器
3.2、RS副本控制器
3.3、RS更新pod
四、Deployment副本控制器
4.1、Deployment副本控制器
五、Kubernetes之Service
5.1、Kubernetes Service介绍
5.2、service类型
六、Kubernetes之configmap
七、Kubernetes之Secret
7.1、Secret简介
7.2、Secret简介类型
7.3、Secret类型-Opaque格式
7.4、Secret类型-kubernetes.io/tls-为nginx提供证书
7.5、Secret-kubernetes.io/dockerconfigjson类型
一、kubernetes内置资源对象
1.1、kubernetes内置资源对象介绍
1.2、kubernetes资源对象操作命令
官网介绍：https://kubernetes.io/zh-cn/docs/concepts/workloads/controllers/deployment/
二、job与cronjob计划任务
2.1、job计划任务
job属于一次性任务，常用于环境初始化例如mysql/elasticsearch。
root@easzlab-deploy:~/jiege-k8s/pod-test# cat 1.job.yaml apiVersion: batch/v1
kind: Job
metadata:name: job-mysql-init
spec:template:spec:containers:- name: job-mysql-init-containerimage: centos:7.9.2009command: ["/bin/sh"]args: ["-c", "echo data init job at `date +%Y-%m-%d_%H-%M-%S` >> /cache/data.log"]volumeMounts:- mountPath: /cachename: cache-volumevolumes:- name: cache-volumehostPath:path: /tmp/jobdatarestartPolicy: Never
root@easzlab-deploy:~/pod-test# kubectl apply -f 1.job.yaml
job.batch/job-mysql-init created
root@easzlab-deploy:~/pod-test# kubectl get pod -A
NAMESPACE NAME READY STATUS RESTARTS AGE
default job-mysql-init-n29g9 0/1 ContainerCreating 0 14s
kube-system calico-kube-controllers-5c8bb696bb-fxbmr 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-2qtfm 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-8l78t 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-9b75m 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-k75jh 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-kmbhs 1/1 Running 1 (3d7h ago) 7d18h
kube-system calico-node-lxfk9 1/1 Running 1 (3d7h ago) 7d18h
kube-system coredns-69548bdd5f-6df7j 1/1 Running 1 (3d7h ago) 7d6h
kube-system coredns-69548bdd5f-nl5qc 1/1 Running 1 (3d7h ago) 7d6h
kubernetes-dashboard dashboard-metrics-scraper-8c47d4b5d-2d275 1/1 Running 1 (3d7h ago) 7d6h
kubernetes-dashboard kubernetes-dashboard-5676d8b865-6l8n8 1/1 Running 1 (3d7h ago) 7d6h
linux70 linux70-tomcat-app1-deployment-5d666575cc-kbjhk 1/1 Running 1 (3d7h ago) 5d7h
myserver linux70-nginx-deployment-55dc5fdcf9-58ll2 1/1 Running 0 20h
myserver linux70-nginx-deployment-55dc5fdcf9-6xcjk 1/1 Running 0 20h
myserver linux70-nginx-deployment-55dc5fdcf9-cxg5m 1/1 Running 0 20h
myserver linux70-nginx-deployment-55dc5fdcf9-gv2gk 1/1 Running 0 20h
velero-system velero-858b9459f9-5mxxx 1/1 Running 0 21h
root@easzlab-deploy:~/pod-test#
2.2、cronjob计划任务
cronjob属于周期性任务，cronjob广泛用于数据库计划备份场景。
root@easzlab-deploy:~/jiege-k8s/pod-test# cat 2.cronjob.yaml
apiVersion: batch/v1
kind: CronJob
metadata:name: cronjob-mysql-databackup
spec:schedule: "*/2 * * * *"jobTemplate:spec:template:spec:containers:- name: cronjob-mysql-databackup-podimage: centos:7.9.2009command: ["/bin/sh"]args: ["-c", "echo mysql databackup cronjob at `date +%Y-%m-%d_%H-%M-%S` >> /cache/data.log"]volumeMounts:- mountPath: /cachename: cache-volumevolumes:- name: cache-volumehostPath:path: /tmp/cronjobdatarestartPolicy: OnFailure
root@easzlab-deploy:~/pod-test# kubectl apply -f 2.cronjob.yaml
root@easzlab-deploy:~/pod-test#
root@easzlab-deploy:~/pod-test# kubectl get pod -A -owide
NAMESPACE NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
default cronjob-mysql-databackup-27661544-wntbb 0/1 Completed 0 4m3s 10.200.2.13 172.16.88.159 <none> <none>
default cronjob-mysql-databackup-27661546-lbf2t 0/1 Completed 0 2m3s 10.200.2.14 172.16.88.159 <none> <none>
default cronjob-mysql-databackup-27661548-8p9j6 0/1 Completed 0 3s 10.200.2.15 172.16.88.159 <none> <none>
kube-system calico-kube-controllers-5c8bb696bb-fxbmr 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.159 172.16.88.159 <none> <none>
kube-system calico-node-2qtfm 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.158 172.16.88.158 <none> <none>
kube-system calico-node-8l78t 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.154 172.16.88.154 <none> <none>
kube-system calico-node-9b75m 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.156 172.16.88.156 <none> <none>
kube-system calico-node-k75jh 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.157 172.16.88.157 <none> <none>
kube-system calico-node-kmbhs 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.159 172.16.88.159 <none> <none>
kube-system calico-node-lxfk9 1/1 Running 1 (3d7h ago) 7d18h 172.16.88.155 172.16.88.155 <none> <none>
kube-system coredns-69548bdd5f-6df7j 1/1 Running 1 (3d7h ago) 7d6h 10.200.2.6 172.16.88.159 <none> <none>
kube-system coredns-69548bdd5f-nl5qc 1/1 Running 1 (3d7h ago) 7d6h 10.200.40.199 172.16.88.157 <none> <none>
kubernetes-dashboard dashboard-metrics-scraper-8c47d4b5d-2d275 1/1 Running 1 (3d7h ago) 7d6h 10.200.40.197 172.16.88.157 <none> <none>
kubernetes-dashboard kubernetes-dashboard-5676d8b865-6l8n8 1/1 Running 1 (3d7h ago) 7d6h 10.200.40.198 172.16.88.157 <none> <none>
linux70 linux70-tomcat-app1-deployment-5d666575cc-kbjhk 1/1 Running 1 (3d7h ago) 5d7h 10.200.233.67 172.16.88.158 <none> <none>
myserver linux70-nginx-deployment-55dc5fdcf9-58ll2 1/1 Running 0 21h 10.200.2.10 172.16.88.159 <none> <none>
myserver linux70-nginx-deployment-55dc5fdcf9-6xcjk 1/1 Running 0 21h 10.200.2.9 172.16.88.159 <none> <none>
myserver linux70-nginx-deployment-55dc5fdcf9-cxg5m 1/1 Running 0 21h 10.200.2.11 172.16.88.159 <none> <none>
myserver linux70-nginx-deployment-55dc5fdcf9-gv2gk 1/1 Running 0 21h 10.200.233.69 172.16.88.158 <none> <none>
velero-system velero-858b9459f9-5mxxx 1/1 Running 0 21h 10.200.40.202 172.16.88.157 <none> <none>
root@easzlab-deploy:~/pod-test#
三、RC/RS副本控制器
3.1、RC副本控制器
Replication Controller： 副本控制器（ selector = !=） #第一代pod副本控制器
https://kubernetes.io/zh/docs/concepts/workloads/controllers/replicationcontroller/
https://kubernetes.io/zh/docs/concepts/overview/working-with-objects/labels/
root@easzlab-deploy:~/jiege-k8s/pod-test# cat 1.rc.yaml
apiVersion: v1
kind: ReplicationController
metadata:name: ng-rc
spec:replicas: 2selector:app: ng-rc-80template:metadata:labels:app: ng-rc-80spec:containers:- name: ng-rc-80image: nginxports:- containerPort: 80
root@easzlab-deploy:~/pod-test# kubectl apply -f 1.rc.yaml
replicationcontroller/ng-rc created
root@easzlab-deploy:~/pod-test#
root@easzlab-deploy:~/pod-test# kubectl get pod -A
NAMESPACE NAME READY STATUS RESTARTS AGE
default ng-rc-528fl 1/1 Running 0 2m8s
default ng-rc-d6zqx 1/1 Running 0 2m8s
kube-system calico-kube-controllers-5c8bb696bb-fxbmr 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-2qtfm 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-8l78t 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-9b75m 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-k75jh 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-kmbhs 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-lxfk9 1/1 Running 1 (3d10h ago) 7d21h
kube-system coredns-69548bdd5f-6df7j 1/1 Running 1 (3d10h ago) 7d9h
kube-system coredns-69548bdd5f-nl5qc 1/1 Running 1 (3d10h ago) 7d9h
kubernetes-dashboard dashboard-metrics-scraper-8c47d4b5d-2d275 1/1 Running 1 (3d10h ago) 7d9h
kubernetes-dashboard kubernetes-dashboard-5676d8b865-6l8n8 1/1 Running 1 (3d10h ago) 7d9h
linux70 linux70-tomcat-app1-deployment-5d666575cc-kbjhk 1/1 Running 1 (3d10h ago) 5d9h
myserver linux70-nginx-deployment-55dc5fdcf9-58ll2 1/1 Running 0 23h
myserver linux70-nginx-deployment-55dc5fdcf9-6xcjk 1/1 Running 0 23h
myserver linux70-nginx-deployment-55dc5fdcf9-cxg5m 1/1 Running 0 23h
myserver linux70-nginx-deployment-55dc5fdcf9-gv2gk 1/1 Running 0 23h
velero-system velero-858b9459f9-5mxxx 1/1 Running 0 24h
root@easzlab-deploy:~/pod-test# 3.2、RS副本控制器
ReplicaSet：副本控制器，和副本控制器的区别是：对选择器的支持（ selector 还支持in notin） #第二代pod副本控制器
https://kubernetes.io/zh/docs/concepts/workloads/controllers/replicaset/
root@easzlab-deploy:~/jiege-k8s/pod-test# cat 2.rs.yaml
apiVersion: apps/v1
kind: ReplicaSet
metadata:name: frontend
spec:replicas: 2selector:matchExpressions:- {key: app, operator: In, values: [ng-rs-80,ng-rs-81]}template:metadata:labels:app: ng-rs-80spec:containers:- name: ng-rs-80image: nginxports:- containerPort: 80
root@easzlab-deploy:~/pod-test# kubectl apply -f 2.rs.yaml
replicaset.apps/frontend created
root@easzlab-deploy:~/pod-test# kubectl get pod -A
NAMESPACE NAME READY STATUS RESTARTS AGE
default frontend-jl67s 1/1 Running 0 97s
default frontend-w7rb5 1/1 Running 0 97s
kube-system calico-kube-controllers-5c8bb696bb-fxbmr 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-2qtfm 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-8l78t 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-9b75m 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-k75jh 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-kmbhs 1/1 Running 1 (3d10h ago) 7d21h
kube-system calico-node-lxfk9 1/1 Running 1 (3d10h ago) 7d21h
kube-system coredns-69548bdd5f-6df7j 1/1 Running 1 (3d10h ago) 7d10h
kube-system coredns-69548bdd5f-nl5qc 1/1 Running 1 (3d10h ago) 7d10h
kubernetes-dashboard dashboard-metrics-scraper-8c47d4b5d-2d275 1/1 Running 1 (3d10h ago) 7d10h
kubernetes-dashboard kubernetes-dashboard-5676d8b865-6l8n8 1/1 Running 1 (3d10h ago) 7d10h
linux70 linux70-tomcat-app1-deployment-5d666575cc-kbjhk 1/1 Running 1 (3d10h ago) 5d10h
myserver linux70-nginx-deployment-55dc5fdcf9-58ll2 1/1 Running 0 24h
myserver linux70-nginx-deployment-55dc5fdcf9-6xcjk 1/1 Running 0 24h
myserver linux70-nginx-deployment-55dc5fdcf9-cxg5m 1/1 Running 0 24h
myserver linux70-nginx-deployment-55dc5fdcf9-gv2gk 1/1 Running 0 24h
velero-system velero-858b9459f9-5mxxx 1/1 Running 0 24h
root@easzlab-deploy:~/pod-test# 3.3、RS更新pod
如需要手动指定镜像进行更新
kubectl set image replicaset/fronted ng-rs-80=nginx:1.18.2
四、Deployment副本控制器
4.1、Deployment副本控制器
Deployment 为 Pod 和 ReplicaSet 提供声明式的更新能力，Deployment比rs更高一级的控制器，除了有rs的功能之外，还有滚动升级、回滚、策略清理、金丝雀部署等等。
官网文档：https://kubernetes.io/zh-cn/docs/concepts/workloads/controllers/deployment/
root@easzlab-deploy:~/jiege-k8s/pod-test# cat 1.deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:name: nginx-deploymentlabels:app: nginx
spec:replicas: 3 #设置副本数selector:matchLabels:app: nginxtemplate:metadata:labels:app: nginxspec:containers:- name: nginximage: nginx:1.14.2ports:- containerPort: 80
root@easzlab-deploy:~/jiege-k8s/pod-test# kubectl apply -f 1.deployment.yaml
deployment.apps/nginx-deployment created
root@easzlab-deploy:~/jiege-k8s/pod-test# kubectl get pod
NAME READY STATUS RESTARTS AGE
mysql-77d55bfdd8-cbtcz 1/1 Running 2 (16h ago) 39h
nginx-deployment-6595874d85-hm5gx 1/1 Running 0 19m
nginx-deployment-6595874d85-wdwx9 1/1 Running 0 19m
nginx-deployment-6595874d85-z8dsf 1/1 Running 0 19m
root@easzlab-deploy:~/jiege-k8s/pod-test#五、Kubernetes之Service
5.1、Kubernetes Service介绍
由于pod重建之后ip就变了， 因此pod之间使用pod的IP直接访问会出现无法访问的问题， 而service则解耦了服务和应用， service的实现方式就是通过label标签动态匹配后端endpoint。
kube-proxy监听着k8s-apiserver，一旦service资源发生变化（调k8sapi修改service信息） ， kubeproxy就会生成对应的负载调度的调整， 这样就保证service的最新状态。
kube-proxy有三种调度模型
- userspace： k8s1.1之前
- iptables： 1.2-k8s1.11之前
- ipvs： k8s 1.11之后， 如果没有开启ipvs， 则自动降级为iptables
5.2、service类型
- ClusterIP： 用于内部服务基于service name的访问。
- NodePort： 用于kubernetes集群以外的服务主动访问运行在kubernetes集群内部的服务。
- LoadBalancer： 用于公有云环境的服务暴露。
- ExternalName： 用于将k8s集群外部的服务映射至k8s集群内部访问， 从而让集群内部的pod能够通过固定的service name访问集群外部的服务， 有时候也用于将不同namespace之间的pod通过ExternalName进行访问。
应用案例
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2# cat 1-deploy_node.yml
#apiVersion: extensions/v1beta1
apiVersion: apps/v1
kind: Deployment
metadata:name: nginx-deployment
spec:replicas: 1selector:#matchLabels: #rs or deployment# app: ng-deploy3-80matchExpressions:- {key: app, operator: In, values: [ng-deploy-80,ng-rs-81]}template:metadata:labels:app: ng-deploy-80spec:containers:- name: ng-deploy-80image: nginx:1.16.1ports:- containerPort: 80#nodeSelector:# env: group1
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2# cat 2-svc_service.yml
apiVersion: v1
kind: Service
metadata:name: ng-deploy-80
spec:ports:- name: httpport: 88targetPort: 80protocol: TCPtype: ClusterIPselector:app: ng-deploy-80
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2# cat 3-svc_NodePort.yml
apiVersion: v1
kind: Service
metadata:name: ng-deploy-80
spec:ports:- name: httpport: 90targetPort: 80nodePort: 30012protocol: TCPtype: NodePortselector:app: ng-deploy-80
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case2#
六、Kubernetes之configmap
Configmap配置信息和镜像解耦, 实现方式为将配置信息放到configmap对象中， 然后在pod的中作为Volume挂载到pod中， 从而实现导入配置的目的。
使用场景：
- 通过Configmap给pod定义全局环境变量
- 通过Configmap给pod传递命令行参数， 如mysql -u -p中的账户名密码可以通过Configmap传递。
- 通过Configmap给pod中的容器服务提供配置文件， 配置文件以挂载到容器的形式使用。
注意事项：
- Configmap需要在pod使用它之前创建。
- pod只能使用位于同一个namespace的Configmap， 及Configmap不能夸namespace使用。
- 通常用于非安全加密的配置场景。
- Configmap通常是小于1MB的配置。
应用案例
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# cat deploy_configmap.yml
apiVersion: v1
kind: ConfigMap
metadata:name: nginx-config
data:default: |server {listen 80;server_name www.mysite.com;index index.html;location / {root /data/nginx/html;if (!-e $request_filename) {rewrite ^/(.*) /index.html last;}}}---
#apiVersion: extensions/v1beta1
apiVersion: apps/v1
kind: Deployment
metadata:name: nginx-deployment
spec:replicas: 1selector:matchLabels:app: ng-deploy-80template:metadata:labels:app: ng-deploy-80spec:containers:- name: ng-deploy-8080image: tomcatports:- containerPort: 8080volumeMounts:- name: nginx-configmountPath: /data- name: ng-deploy-80image: nginx ports:- containerPort: 80volumeMounts:- mountPath: /data/nginx/htmlname: nginx-static-dir- name: nginx-configmountPath: /etc/nginx/conf.dvolumes:- name: nginx-static-dirhostPath:path: /data/nginx/linux70- name: nginx-configconfigMap:name: nginx-configitems:- key: defaultpath: mysite.conf---
apiVersion: v1
kind: Service
metadata:name: ng-deploy-80
spec:ports:- name: httpport: 81targetPort: 80nodePort: 30019protocol: TCPtype: NodePortselector:app: ng-deploy-80安装并验证
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get pod
NAME READY STATUS RESTARTS AGE
mysql-77d55bfdd8-cbtcz 1/1 Running 2 (18h ago) 41h
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get configmap
NAME DATA AGE
istio-ca-root-cert 1 40h
kube-root-ca.crt 1 47h
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl apply -f deploy_configmap.yml
configmap/nginx-config created
deployment.apps/nginx-deployment created
service/ng-deploy-80 created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get pod -owide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
mysql-77d55bfdd8-cbtcz 1/1 Running 2 (18h ago) 41h 10.200.104.212 172.16.88.163 <none> <none>
nginx-deployment-5699c4696d-gr4gm 2/2 Running 0 27s 10.200.104.216 172.16.88.163 <none> <none>
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get configmap
NAME DATA AGE
istio-ca-root-cert 1 40h
kube-root-ca.crt 1 47h
nginx-config 1 32s
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get configmap nginx-config -oyaml
apiVersion: v1
data:default: |server {listen 80;server_name www.mysite.com;index index.html;location / {root /data/nginx/html;if (!-e $request_filename) {rewrite ^/(.*) /index.html last;}}}
kind: ConfigMap
metadata:annotations:kubectl.kubernetes.io/last-applied-configuration: |{"apiVersion":"v1","data":{"default":"server {\n listen 80;\n server_name www.mysite.com;\n index index.html;\n\n location / {\n root /data/nginx/html;\n if (!-e $request_filename) {\n rewrite ^/(.*) /index.html last;\n }\n }\n}\n"},"kind":"ConfigMap","metadata":{"annotations":{},"name":"nginx-config","namespace":"default"}}creationTimestamp: "2022-10-20T08:29:50Z"name: nginx-confignamespace: defaultresourceVersion: "388823"uid: 1a04f3c2-bc33-4ddc-ac0a-f726c9fa33f6
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6#
root@easzlab-deploy:~# kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.100.0.1 <none> 443/TCP 47h
mysql-service NodePort 10.100.125.186 <none> 3306:33306/TCP 41h
ng-deploy-80 NodePort 10.100.80.101 <none> 81:30019/TCP 2m16s
root@easzlab-deploy:~# root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# cat deploy_configmapenv.yml #带value值
apiVersion: v1
kind: ConfigMapmetadata:name: nginx-config
data:username: user1---
#apiVersion: extensions/v1beta1
apiVersion: apps/v1
kind: Deployment
metadata:name: nginx-deployment
spec:replicas: 1selector:matchLabels:app: ng-deploy-80template:metadata:labels:app: ng-deploy-80spec:containers:- name: ng-deploy-80image: nginx env:- name: "magedu"value: "n70"- name: MY_USERNAMEvalueFrom:configMapKeyRef:name: nginx-configkey: usernameports:- containerPort: 80安装并验证
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl apply -f deploy_configmapenv.yml
configmap/nginx-config configured
deployment.apps/nginx-deployment configured
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# kubectl get configmap -oyaml
apiVersion: v1
items:
- apiVersion: v1data:root-cert.pem: |-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----kind: ConfigMapmetadata:creationTimestamp: "2022-10-18T16:22:39Z"labels:istio.io/config: "true"name: istio-ca-root-certnamespace: defaultresourceVersion: "65285"uid: 76575e18-c8b2-4dd9-b1d7-ffef0f43c640
- apiVersion: v1data:ca.crt: |-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----kind: ConfigMapmetadata:annotations:kubernetes.io/description: Contains a CA bundle that can be used to verify thekube-apiserver when using internal endpoints such as the internal serviceIP or kubernetes.default.svc. No other usage is guaranteed across distributionsof Kubernetes clusters.creationTimestamp: "2022-10-18T09:07:42Z"name: kube-root-ca.crtnamespace: defaultresourceVersion: "271"uid: f63b2e93-d94f-4c2c-831f-49863f82e3e5
- apiVersion: v1data:username: user1kind: ConfigMapmetadata:annotations:kubectl.kubernetes.io/last-applied-configuration: |{"apiVersion":"v1","data":{"username":"user1"},"kind":"ConfigMap","metadata":{"annotations":{},"name":"nginx-config","namespace":"default"}}creationTimestamp: "2022-10-20T08:37:17Z"name: nginx-confignamespace: defaultresourceVersion: "390419"uid: 0136af36-4a7f-407a-a61c-bea7ef19497c
kind: List
metadata:resourceVersion: ""
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case6# 七、Kubernetes之Secret
7.1、Secret简介
- Secret 的功能类似于 ConfigMap给pod提供额外的配置信息，但是Secret是一种包含少量敏感信息例如密码、 令牌或密钥的对象。
- Secret 的名称必须是合法的 DNS 子域名。
- 每个Secret的大小最多为1MiB， 主要是为了避免用户创建非常大的Secret进而导致API服务器和kubelet内存耗尽， 不过创建很多小的Secret也可能耗尽内存， 可以使用资源配额来约束每个名字空间中Secret的个数。
- 在通过yaml文件创建secret时， 可以设置data或stringData字段，data和stringData字段都是可选的， data字段中所有键值都必须是base64编码的字符串， 如果不希望执行这种 base64字符串的转换操作， 也可以选择设置stringData字段， 其中可以使用任何非加密的字符串作为其取值。
Pod 可以用三种方式的任意一种来使用 Secret：
- 作为挂载到一个或多个容器上的卷 中的文件(crt文件、 key文件)。
- 作为容器的环境变量。
- 由 kubelet 在为 Pod 拉取镜像时使用(与镜像仓库的认证)。
7.2、Secret简介类型
Kubernetes默认支持多种不同类型的secret， 用于一不同的使用场景， 不同类型的secret的配置参数也不一样。
7.3、Secret类型-Opaque格式
Opaque格式-data类型数据-事先使用base64加密
#echo admin |base64
#echo 123456 |base64
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# echo admin |base64
YWRtaW4K
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# echo 123456 |base64
MTIzNDU2Cg==
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# cat 1-secret-Opaque-data.yaml
apiVersion: v1
kind: Secret
metadata:name: mysecret-datanamespace: myserver
type: Opaque
data:user: YWRtaW4Kpassword: MTIzNDU2Cg==
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# kubectl apply -f 1-secret-Opaque-data.yaml
secret/mysecret-data created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# kubectl get secrets mysecret-data -n myserver -o yaml
apiVersion: v1
data:password: MTIzNDU2Cg==user: YWRtaW4K
kind: Secret
metadata:annotations:kubectl.kubernetes.io/last-applied-configuration: |{"apiVersion":"v1","data":{"password":"MTIzNDU2Cg==","user":"YWRtaW4K"},"kind":"Secret","metadata":{"annotations":{},"name":"mysecret-data","namespace":"myserver"},"type":"Opaque"}creationTimestamp: "2022-10-20T09:03:33Z"name: mysecret-datanamespace: myserverresourceVersion: "394995"uid: b0788df4-0195-429f-bda5-eafb5d51bd6a
type: Opaque
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# Opaque格式stringData类型数据-不用事先加密-上传到k8s会加密
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# cat 2-secret-Opaque-stringData.yaml
apiVersion: v1
kind: Secret
metadata:name: mysecret-stringdatanamespace: myserver
type: Opaque
stringData:superuser: 'admin'password: '123456'
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# kubectl apply -f 2-secret-Opaque-stringData.yaml
secret/mysecret-stringdata created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# kubectl get secrets mysecret-stringdata -n myserver -o yaml
apiVersion: v1
data:password: MTIzNDU2superuser: YWRtaW4=
kind: Secret
metadata:annotations:kubectl.kubernetes.io/last-applied-configuration: |{"apiVersion":"v1","kind":"Secret","metadata":{"annotations":{},"name":"mysecret-stringdata","namespace":"myserver"},"stringData":{"password":"123456","superuser":"admin"},"type":"Opaque"}creationTimestamp: "2022-10-20T09:07:15Z"name: mysecret-stringdatanamespace: myserverresourceVersion: "395636"uid: 4134fe69-389d-47d0-b870-f83dd34fa537
type: Opaque
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case8# 7.4、Secret类型-kubernetes.io/tls-为nginx提供证书
自签名证书：
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# mkdir certs
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# ls
4-secret-tls.yaml certs
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# cd certs/
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# ls
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# openssl req -x509 -sha256 -newkey rsa:4096 -keyout ca.key -out ca.crt -days 3560 -nodes -subj '/CN=www.ca.com'
Generating a RSA private key
..............................................++++
....................................................................++++
writing new private key to 'ca.key'
-----
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# openssl req -new -newkey rsa:4096 -keyout server.key -out server.csr -nodes -subj '/CN=www.mysite.com'
Generating a RSA private key
.......................................................................................................................................................................................++++
................................................++++
writing new private key to 'server.key'
-----
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# openssl x509 -req -sha256 -days 3650 -in server.csr -CA ca.crt -CAkey ca.key -set_serial 01 -out server.crt
Signature ok
subject=CN = www.mysite.com
Getting CA Private Key
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# ll -h
total 28K
drwxr-xr-x 2 root root 4.0K Oct 20 20:09 ./
drwxr-xr-x 3 root root 4.0K Oct 20 20:06 ../
-rw-r--r-- 1 root root 1.8K Oct 20 20:08 ca.crt
-rw------- 1 root root 3.2K Oct 20 20:08 ca.key
-rw-r--r-- 1 root root 1.7K Oct 20 20:09 server.crt
-rw-r--r-- 1 root root 1.6K Oct 20 20:09 server.csr
-rw------- 1 root root 3.2K Oct 20 20:09 server.key
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# kubectl create secret tls myserver-tls-key --cert=./server.crt --key=./server.key -n myserver
secret/myserver-tls-key created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9/certs# 创建web服务nginx并使用证书：
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# cat 4-secret-tls.yaml
apiVersion: v1
kind: ConfigMap
metadata:name: nginx-confignamespace: myserver
data:default: |server {listen 80;listen 443 ssl;server_name www.mysite.com;ssl_certificate /etc/nginx/conf.d/certs/tls.crt;ssl_certificate_key /etc/nginx/conf.d/certs/tls.key;location / {root /usr/share/nginx/html;index index.html;if ($scheme = http){rewrite / https://www.mysite.com permanent;}if (!-e $request_filename){rewrite ^/(.*) /index.html last;}}}---
apiVersion: apps/v1
kind: Deployment
metadata:name: myserver-myapp-frontend-deploymentnamespace: myserver
spec:replicas: 1selector:matchLabels:app: myserver-myapp-frontendtemplate:metadata:labels:app: myserver-myapp-frontendspec:containers:- name: myserver-myapp-frontendimage: nginx:1.20.2-alpineports:- containerPort: 80volumeMounts:- name: nginx-configmountPath: /etc/nginx/conf.d/myserver- name: myserver-tls-keymountPath: /etc/nginx/conf.d/certsvolumes:- name: nginx-configconfigMap:name: nginx-configitems:- key: defaultpath: mysite.conf- name: myserver-tls-keysecret:secretName: myserver-tls-key---
apiVersion: v1
kind: Service
metadata:name: myserver-myapp-frontendnamespace: myserver
spec:type: NodePortports:- name: httpport: 80targetPort: 80nodePort: 30018protocol: TCP- name: httpsport: 443targetPort: 443nodePort: 30019protocol: TCPselector:app: myserver-myapp-frontend
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl apply -f 4-secret-tls.yaml
configmap/nginx-config created
deployment.apps/myserver-myapp-frontend-deployment created
service/myserver-myapp-frontend created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# 验证nginx pod信息
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl get pod -n myserver
NAME READY STATUS RESTARTS AGE
myserver-myapp-frontend-deployment-7694cb4fcb-j9hcq 1/1 Running 0 54m
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl get secret -n myserver
NAME TYPE DATA AGE
myserver-tls-key kubernetes.io/tls 2 71m
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl get secret -n myserver -oyaml
apiVersion: v1
items:
- apiVersion: v1data:tls.crt: LS0tLS1CRUdJTiBDRVJUSUZJQ0FURS0tLS0tCk1JSUVvakNDQW9vQ0FRRXdEUVlKS29aSWh2Y05BUUVMQlFBd0ZURVRNQkVHQTFVRUF3d0tkM2QzTG1OaExtTnYKYlRBZUZ3MHlNakV3TWpBeE1qQTVNakJhRncwek1qRXdNVGN4TWpBNU1qQmFNQmt4RnpBVkJnTlZCQU1NRG5kMwpkeTV0ZVhOcGRHVXVZMjl0TUlJQ0lqQU5CZ2txaGtpRzl3MEJBUUVGQUFPQ0FnOEFNSUlDQ2dLQ0FnRUF5RE9VCmt5UHJMbC9adFRLMk1ZOWxQWU8zQXVXRnExcEJFZG9PT0R2dndtZ3FabUV1VjVNeXNTdnJLcmJBeW1pQnd1d1gKd2JYZU1MZGlxOW1GK0NzTWFkR21tUW9aY0VXNW54MGZZSzNLbVdIY2hrc0JITnlKNnhXV2ZCQk0yRDlzSnM1cQpXVWJnbUFDdGNINW1iSXo5TlV3MGwwZ2pTa3oyNDM2RVNPNjdPOFo5WEVEVGlFUTN5YnM0RTV2azNiVGJ3ZzBYCmthK2Q5Z3RCQTFmQmZFOGFEZkRweWhkZTZ5L0YxTjBlWmladFlNdUp1QTIzYkVxcWR5d1hJemJCUDBjTHdyUEIKUG5vTXY5OUdTWTVzZEZZMkRrdHMxVHdUUjRqdHVWdExTTTY1MXNXeVpVckVUcm53U3RNcXJRT1Q0QUdpcXc1MQpHZTZoQXJxZ0Y1VS96U3BiL29nQjZ1T0IvWThiNDBvazFNNGRKWXRETVhvZFFtYnNtOU9pa3VOc2lRWTVIZUlnCmVpVUdnVVRoRFRGYlB6SW5acWo3TDM5bmMvUlREeWxicGRsRVRNamVTS0o5MHBpMERNM1VOVkxzTEg0WitrWnEKZ282N0hneHFCVlBYb1dTTm54UFFheEI5TkFnTUl3aVVXZ0NoM2pHVlpwMTE5VGpsQXRqYTV0OHZVeFhCWDdUMApkSDVCYUZjTTRGTmwzYmYzMmJRck9vcWlkREFMQ2JrcVZmNjNxNUVsUERNV2p0UGdhd0JtUlZ0V0Vlb2hIV0t3CitKTFVod1o4UUNPYjhBcTYwVHk3bFdvc0JyUlZZRWgwOTJjbFU4clJmOFF1VC9venl5N3BkWHlYVzNYUGZDbHAKVXo1NGF5eVdYOVZXa3pxZHRIby8xRXRtUHpCV1FzcnhSeVNjOTg4Q0F3RUFBVEFOQmdrcWhraUc5dzBCQVFzRgpBQU9DQWdFQXRFUkdPbENCQnFmRTZzODdGcmFReXc5Q0pocUs4TndrajFVa3YwMzFsaFIwakhKSUE1TU1lYlFNCkU2YnBPdm5mS1pOWk82OXJtaVV6S3pJd2IrZjV5THZaWHJzVzdYUU5VQitiRlFJRG14cVp1dGJNbHR5YjdrcWIKaTA1eVpqUWpJNHNSYVFrUnRpZ1JBdkFWRFk4RWl3WSsvb1BFUjg4N0QrbXk2ZlZJZFhFTzNSQUloT1FhNWF1bQphV1o3bVBjL2xkd1ZoNFVicG0yTGZCNDhvb3BvS05pZ1hsZWloNWg5VWc2Mms3NHFLdVB2cnVvdVBvWWtoWGlXCmFuQzBtTXFWalk5bFMzSi9CdXpKdFpwUExlcllLdjJIQ1RiSklYdmhCazNQU3MwbmZlUFoyUDkrNHMzQXhMcSsKVGxhMHlwcXZueWtHMXRyd0g4dXMzZEM1ZEg3ZWNzWC9SRm8wM2NXbUNGZUM2Yzk4YjhiVDBXd0x6Ym1HWUl6bgpWaVk3UTRVSTNya2wrdjBySC91aDZ5OVFkU1FRZS9vaERCeEJtelQxWXVqdDMyMUpiSTIzMklrTEFQSUpWbDBnClo5SktFaCtSRko0djVRK1N6U1BSZyt5ZWJCQjExZUVvc1l3N2lQd2J4a0U1UVpaUzBLY1N4TDB3UGF3R3NXK0MKYkFmZUFpMVhFdG51MFlVMzlOTHkrOWluRFBEcjlyM3Y2N1d0UkxFeldWSzcwS05RUTY1R3VTOUsxbHFMdzdqUApwWE1RclpuQnpDelVDb0VmYkFIN0tmSXd3OGgxWFZhTnJFeXZDWnJRRlNiTjJTUzFwYjZidXFSVmtjald2U2Y3Clp0ejUzYXBDQkFXd3JxUGFSbW1VVHd0RnpZZUIvVmVsNEdJVzlEbkIwRTF1NWdXaHpaQT0KLS0tLS1FTkQgQ0VSVElGSUNBVEUtLS0tLQo=tls.key: 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kind: Secretmetadata:creationTimestamp: "2022-10-20T12:09:46Z"name: myserver-tls-keynamespace: myserverresourceVersion: "427221"uid: cef4b425-8572-44f2-9097-5a1040c9bd03type: kubernetes.io/tls
kind: List
metadata:resourceVersion: ""
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9#
此时发现pod没有监听443端口
解决办法
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl exec -it -n myserver myserver-myapp-frontend-deployment-7694cb4fcb-l449j sh
kubectl exec [POD] [COMMAND] is DEPRECATED and will be removed in a future version. Use kubectl exec [POD] -- [COMMAND] instead.
/ #
/etc/nginx/conf.d/myserver # vi /etc/nginx/nginx.conf
/etc/nginx/conf.d/myserver # cat /etc/nginx/nginx.conf user nginx;
worker_processes auto;error_log /var/log/nginx/error.log notice;
pid /var/run/nginx.pid;events {worker_connections 1024;
}http {include /etc/nginx/mime.types;default_type application/octet-stream;log_format main '$remote_addr - $remote_user [$time_local] "$request" ''$status $body_bytes_sent "$http_referer" ''"$http_user_agent" "$http_x_forwarded_for"';access_log /var/log/nginx/access.log main;sendfile on;#tcp_nopush on;keepalive_timeout 65;#gzip on;include /etc/nginx/conf.d/*.conf;include /etc/nginx/conf.d/myserver/*.conf;
}
/etc/nginx/conf.d/myserver # ls /etc/nginx/conf.d/myserver/*.conf
/etc/nginx/conf.d/myserver/mysite.conf
/etc/nginx/conf.d/myserver #
/etc/nginx/conf.d/myserver # nginx -t
nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful
/etc/nginx/conf.d/myserver # nginx -s reload
2022/10/20 13:56:20 [notice] 52#52: signal process started
/etc/nginx/conf.d/myserver # netstat -tnlp
Active Internet connections (only servers)
Proto Recv-Q Send-Q Local Address Foreign Address State PID/Program name
tcp 0 0 0.0.0.0:443 0.0.0.0:* LISTEN 1/nginx: master pro
tcp 0 0 0.0.0.0:80 0.0.0.0:* LISTEN 1/nginx: master pro
tcp 0 0 :::80 :::* LISTEN 1/nginx: master pro
/etc/nginx/conf.d/myserver # 配置负载均衡转发请求到nodeport
root@easzlab-haproxy-keepalive-01:~# vi /etc/haproxy/haproxy.cfg
listen myserer-nginx-80bind 172.16.88.200:80mode tcpserver easzlab-k8s-master-01 172.16.88.157:30018 check inter 2000 fall 3 rise 5server easzlab-k8s-master-02 172.16.88.158:30018 check inter 2000 fall 3 rise 5server easzlab-k8s-master-03 172.16.88.159:30018 check inter 2000 fall 3 rise 5listen myserer-nginx-443bind 172.16.88.200:443mode tcpserver easzlab-k8s-master-01 172.16.88.157:30019 check inter 2000 fall 3 rise 5server easzlab-k8s-master-02 172.16.88.158:30019 check inter 2000 fall 3 rise 5server easzlab-k8s-master-03 172.16.88.159:30019 check inter 2000 fall 3 rise 5root@easzlab-haproxy-keepalive-01:~# systemctl restart haproxy
配置hosts 解析
通过curl命令查看证书来源
root@easzlab-haproxy-keepalive-01:~# curl -lvk https://www.mysite.com
* Trying 172.16.88.200:443...
* TCP_NODELAY set
* Connected to www.mysite.com (172.16.88.200) port 443 (#0)
* ALPN, offering h2
* ALPN, offering http/1.1
* successfully set certificate verify locations:
* CAfile: /etc/ssl/certs/ca-certificates.crtCApath: /etc/ssl/certs
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
* TLSv1.3 (IN), TLS handshake, Server hello (2):
* TLSv1.2 (IN), TLS handshake, Certificate (11):
* TLSv1.2 (IN), TLS handshake, Server key exchange (12):
* TLSv1.2 (IN), TLS handshake, Server finished (14):
* TLSv1.2 (OUT), TLS handshake, Client key exchange (16):
* TLSv1.2 (OUT), TLS change cipher, Change cipher spec (1):
* TLSv1.2 (OUT), TLS handshake, Finished (20):
* TLSv1.2 (IN), TLS handshake, Finished (20):
* SSL connection using TLSv1.2 / ECDHE-RSA-AES256-GCM-SHA384
* ALPN, server accepted to use http/1.1
* Server certificate:
* subject: CN=www.mysite.com
* start date: Oct 20 12:09:20 2022 GMT
* expire date: Oct 17 12:09:20 2032 GMT
* issuer: CN=www.ca.com
* SSL certificate verify result: unable to get local issuer certificate (20), continuing anyway.
> GET / HTTP/1.1
> Host: www.mysite.com
> User-Agent: curl/7.68.0
> Accept: */*
>
* Mark bundle as not supporting multiuse
< HTTP/1.1 200 OK
< Server: nginx/1.20.2
< Date: Thu, 20 Oct 2022 14:06:47 GMT
< Content-Type: text/html
< Content-Length: 612
< Last-Modified: Tue, 16 Nov 2021 15:04:23 GMT
< Connection: keep-alive
< ETag: "6193c877-264"
< Accept-Ranges: bytes
<
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
<style>body {width: 35em;margin: 0 auto;font-family: Tahoma, Verdana, Arial, sans-serif;}
</style>
</head>
<body>
<h1>Welcome to nginx!</h1>
<p>If you see this page, the nginx web server is successfully installed and
working. Further configuration is required.</p><p>For online documentation and support please refer to
<a href="http://nginx.org/">nginx.org</a>.<br/>
Commercial support is available at
<a href="http://nginx.com/">nginx.com</a>.</p><p><em>Thank you for using nginx.</em></p>
</body>
</html>
* Connection #0 to host www.mysite.com left intact
root@easzlab-haproxy-keepalive-01:~#
root@easzlab-haproxy-keepalive-01:~# curl -vvi https://www.mysite.com
* Trying 172.16.88.200:443...
* TCP_NODELAY set
* Connected to www.mysite.com (172.16.88.200) port 443 (#0)
* ALPN, offering h2
* ALPN, offering http/1.1
* successfully set certificate verify locations:
* CAfile: /etc/ssl/certs/ca-certificates.crtCApath: /etc/ssl/certs
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
* TLSv1.3 (IN), TLS handshake, Server hello (2):
* TLSv1.2 (IN), TLS handshake, Certificate (11):
* TLSv1.2 (OUT), TLS alert, unknown CA (560):
* SSL certificate problem: unable to get local issuer certificate
* Closing connection 0
curl: (60) SSL certificate problem: unable to get local issuer certificate
More details here: https://curl.haxx.se/docs/sslcerts.htmlcurl failed to verify the legitimacy of the server and therefore could not
establish a secure connection to it. To learn more about this situation and
how to fix it, please visit the web page mentioned above.
root@easzlab-haproxy-keepalive-01:~# 7.5、Secret-kubernetes.io/dockerconfigjson类型
存储docker registry的认证信息， 在下载镜像的时候使用， 这样每一个node节点就可以不登录也可以下载私有级别的镜像了。
root@easzlab-deploy:~# docker login --username=c******2 registry.cn-shenzhen.aliyuncs.com
Password:
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-storeLogin Succeeded
root@easzlab-deploy:~# cat /root/.docker/config.json
{"auths": {"harbor.magedu.net": {"auth": "YWRtaW46SGFyYm9yMTIzNDU="},"registry.cn-shenzhen.aliyuncs.com": {"auth": "Y*********************==" #此处这里显示脱敏}}
}
root@easzlab-deploy:~#
root@easzlab-deploy:~# kubectl create secret generic aliyun-registry-image-pull-key \
> --from-file=.dockerconfigjson=/root/.docker/config.json \
> --type=kubernetes.io/dockerconfigjson \
> -n myserver #将本地登录阿里云私有仓库信息存储起来，共享给k8s集群节点使用
secret/aliyun-registry-image-pull-key created
root@easzlab-deploy:~#
root@easzlab-deploy:~# kubectl get secret -n myserver
NAME TYPE DATA AGE
aliyun-registry-image-pull-key kubernetes.io/dockerconfigjson 1 9m24s
myserver-tls-key kubernetes.io/tls 2 150m
root@easzlab-deploy:~#
root@easzlab-deploy:~# kubectl get secret -n myserver aliyun-registry-image-pull-key -oyaml
apiVersion: v1
data:.dockerconfigjson: ewoJImF1dGhzIjogewoJCSJoYXJib3IubWFnZWR1Lm5ldCI6IHsKCQkJImF1dGgiOiAiWVdSdGFXNDZTR0Z5WW05eU1USXpORFU9IgoJCX0sCgkJInJlZ2lzdHJ5LmNuLXNoZW56aGVuLmFsaXl1bmNzLmNvbSI6IHsKCQkJImF1d*************************n0=
kind: Secret
metadata:creationTimestamp: "2022-10-20T14:30:23Z"name: aliyun-registry-image-pull-keynamespace: myserverresourceVersion: "451590"uid: f084175a-6260-4435-acfb-bcec9095e5a6
type: kubernetes.io/dockerconfigjson
root@easzlab-deploy:~#
root@easzlab-deploy:~# cd jiege-k8s/pod-test/case-yaml/case9/
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# vi 6-secret-imagePull.yaml
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# cat 6-secret-imagePull.yaml
apiVersion: apps/v1
kind: Deployment
metadata:name: myserver-myapp-frontend-deployment-2namespace: myserver
spec:replicas: 1selector:matchLabels:app: myserver-myapp-frontend-2template:metadata:labels:app: myserver-myapp-frontend-2spec:containers:- name: myserver-myapp-frontend-2image: registry.cn-shenzhen.aliyuncs.com/cyh01/nginx:1.22.0 #指向阿里云公有私仓镜像ports:- containerPort: 80imagePullSecrets:- name: aliyun-registry-image-pull-key---
apiVersion: v1
kind: Service
metadata:name: myserver-myapp-frontend-2namespace: myserver
spec:ports:- name: httpport: 80targetPort: 80nodePort: 30033protocol: TCPtype: NodePortselector:app: myserver-myapp-frontend-2
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl apply -f 6-secret-imagePull.yaml
deployment.apps/myserver-myapp-frontend-deployment-2 created
service/myserver-myapp-frontend-2 created
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9#
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl get pod -n myserver -owide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
myserver-myapp-frontend-deployment-2-6d96b76bb-bgmzf 1/1 Running 0 30s 10.200.104.226 172.16.88.163 <none> <none>
myserver-myapp-frontend-deployment-6f48755cbd-k2dbs 1/1 Running 0 28m 10.200.105.158 172.16.88.164 <none> <none>
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9#
#验证pod信息
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# kubectl describe pod -n myserver myserver-myapp-frontend-deployment-2-6d96b76bb-bgmzf
Name: myserver-myapp-frontend-deployment-2-6d96b76bb-bgmzf
Namespace: myserver
Priority: 0
Node: 172.16.88.163/172.16.88.163
Start Time: Thu, 20 Oct 2022 23:01:25 +0800
Labels: app=myserver-myapp-frontend-2pod-template-hash=6d96b76bb
Annotations: <none>
Status: Running
IP: 10.200.104.226
IPs:IP: 10.200.104.226
Controlled By: ReplicaSet/myserver-myapp-frontend-deployment-2-6d96b76bb
Containers:myserver-myapp-frontend-2:Container ID: containerd://20d2061b0eaa8e21748fed2559ba0fe35e7271730097809f210e50d650ad20f9Image: registry.cn-shenzhen.aliyuncs.com/cyh01/nginx:1.22.0Image ID: registry.cn-shenzhen.aliyuncs.com/cyh01/nginx@sha256:b3a676a9145dc005062d5e79b92d90574fb3bf2396f4913dc1732f9065f55c4bPort: 80/TCPHost Port: 0/TCPState: RunningStarted: Thu, 20 Oct 2022 23:01:27 +0800Ready: TrueRestart Count: 0Environment: <none>Mounts:/var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-j7wtn (ro)
Conditions:Type StatusInitialized True Ready True ContainersReady True PodScheduled True
Volumes:kube-api-access-j7wtn:Type: Projected (a volume that contains injected data from multiple sources)TokenExpirationSeconds: 3607ConfigMapName: kube-root-ca.crtConfigMapOptional: <nil>DownwardAPI: true
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300snode.kubernetes.io/unreachable:NoExecute op=Exists for 300s
Events:Type Reason Age From Message---- ------ ---- ---- -------Normal Scheduled 105s default-scheduler Successfully assigned myserver/myserver-myapp-frontend-deployment-2-6d96b76bb-bgmzf to 172.16.88.163Normal Pulled 103s kubelet Container image "registry.cn-shenzhen.aliyuncs.com/cyh01/nginx:1.22.0" already present on machineNormal Created 103s kubelet Created container myserver-myapp-frontend-2Normal Started 103s kubelet Started container myserver-myapp-frontend-2
root@easzlab-deploy:~/jiege-k8s/pod-test/case-yaml/case9# 相关文章：
k8s常见的资源对象使用
目录 一、kubernetes内置资源对象 1.1、kubernetes内置资源对象介绍 1.2、kubernetes资源对象操作命令 二、job与cronjob计划任务 2.1、job计划任务 2.2、cronjob计划任务 三、RC/RS副本控制器 3.1、RC副本控制器 3.2、RS副本控制器 3.3、RS更新pod 四、Deployment副…...
JavaScript 简单实现观察者模式和发布订阅模式
JavaScript 简单实现观察者模式和发布订阅模式 1. 观察者模式1.1 如何理解1.2 代码实现 2. 发布订阅模式2.1 如何理解2.2 代码实现 1. 观察者模式 1.1 如何理解 概念：观察者模式定义对象间的一种一对多的依赖关系，当一个对象的状态发生改变时ÿ…...
高通WLAN框架学习（37）-- TDLS（Tunneled Direct Link Setup）通道直接链路建立
一 TDLS概述 隧道直连设置(TDLS)基于IEEE 802.11z-2010IEEE标准802.11z标准(无线局域网介质访问控制(MAC)和物理层(PHY)规范。 TDLS允许与同一AP关联的设备之间建立直接链路。Wi-Fi Direct允许设备之间直接连接，而不需要AP。Wi-Fi联盟认证可用于IEEE 802.11a和802.11g设备的T…...
高算力AI模组前沿应用：基于ARM架构的SoC阵列式服务器
本期我们带来高算力AI模组前沿应用，基于ARM架构的SoC阵列式服务器相关内容。澎湃算力、创新架构、异构计算，有望成为未来信息化社会的智能算力底座。 ▌性能优势AI驱动，ARM架构服务器加速渗透 一直以来，基于ARM架构的各类处理器…...
老年公寓人员定位管理系统：提升安全与关怀的智能解决方案
老年公寓作为提供安全居住环境和关怀服务的重要场所，面临着人员管理和安全控制的挑战。为了解决这些问题，老年公寓人员定位管理系统应运而生。基于为提供全面的安全管理和个性化关怀服务，华安联大便通过老年公寓人员定位管理系统的技术原理、…...
每日一题之两个字符串的删除操作
题目链接 给定两个单词 word1 和 word2 ，返回使得 word1 和 word2 **相同所需的最小步数。 每步 可以删除任意一个字符串中的一个字符。 示例 1： 输入: word1 "sea", word2 "eat" 输出: 2 解释: 第一步将 "sea" 变…...
nacos安装与基础配置
源码 https://github.com/alibaba/nacos https://gitee.com/mirrors/Nacos 编译 git clone https://github.com/alibaba/nacos.git cd nacos/ mvn -Prelease-nacos -Dmaven.test.skiptrue clean install -U ls -al distribution/target/// change the $version to your ac…...
GitHub Copilot：让开发编程变得像说话一样简单
引用： 人类天生就梦想、创造、创新。但今天，我们花太多时间被繁重的工作所消耗，花在消耗我们时间、创造力和精力的任务上。为了重新连接我们工作的灵魂，我们不仅需要一种更好的方式来做同样的事情，更需要一种全新的工…...
并发编程中锁的优化
在 Java 并发编程中，锁是一种常用的同步机制，用于控制对共享资源的访问。使用锁可以确保多个线程之间的互斥访问，避免数据竞争和并发问题。 然而，锁的使用可能会带来一定的性能开销，特别是在高并发场景下。 为了优化…...
笔试题：统计字符串中某字符串在其出现的字符个数
笔试题：统计字符串中某一子串的字符个数：例如字符串aabbcd,有aabb:4,ab:2 哈哈，这道题是小编面试音视频龙头企业的笔试题，以下是我写的代码：如果有错误，希望可以指正!!! 解题思路：利用双指针i和…...
Java NIO Files类读取文件流方式详解
Java NIO Files类读取文件流方式详解 Files类原理概述 java.nio.file.Files是Java标准库提供的一个工具类，用于操作文件和目录。它提供了一系列静态方法，可以用于创建、复制、删除、移动、重命名、读取、写入文件和目录等常见的文件系统操作。同时&…...
Mybatis快速入门,Mybatis的核心配置文件
Mybatis快速入门 一、Mybatis简介1.1Mybatis简化JDBC 二、Mybatis快速入门2.1创建user表，添加数据2.2创建模块，导入坐标2.3编写Mybatis核心配置文件 --> 替换连接信息，解决硬编码问题2.4编写SQL映射文件 --> 统一管理sql语句࿰…...
go语言中defer执行顺序
defer 执行顺序和调用顺序相反，类似于栈后进先出。 defer在 return 之后执行，但在函数推出之前，defer可以修改返回值。 func test() int {i : 0defer func() {fmt.Println("defer1")}()defer func() {i 1fmt.Println("defe…...
webpack xxx is not a constructor
环境 webpack5.88.2 vue-router 按需引入 原因 模块循环引用导致 有A B C三个模块 A B模块import C 中导出的class c又依赖B 中Class 的方法 B 又依赖C中的class 此时会导致import 的 C 为undefined...
安装支持vs2019的MFC（解决MSBuild 错误 MSB8041、MSB8042）
安装支持MFC的vs2019（解决MSBuild 错误 MSB8041、MSB8042） 常用安装选项解决MSBuild 错误 常用安装选项 解决MSBuild 错误 安装上述勾选内容后，即可解决MSBuild 错误 MSB8041 MSB8041：此项目需要 MFC/ATL 库。 https://learn.mic…...
校园电气安全风险分析及预防措施 安科瑞 许敏
摘要:校园属于人员密集场所，若安全风险排查、管控不到位，可能导致安全事故发生，造成严重事故后果。校园电气设备设施引起的电气火灾和触电等事故，是构成校园安全威胁之一，笔者通过对校园发生的电气安全事故案例原因分析…...
机器学习之十大经典算法
机器学习算法是计算机科学和人工智能领域的关键组成部分，它们用于从数据中学习模式并作出预测或做出决策。本文将为大家介绍十大经典机器学习算法，其中包括了线性回归、逻辑回归、支持向量机、朴素贝叶斯、决策树等算法，每种算法都在特定的领…...
系统架构设计师 11：未来信息综合技术
本章花了很多笔墨来写各项技术的发展历程，可以了解一下。 一、信息物理系统 信息物理系统（Cyber-Physical Systems，CPS）是控制系统、嵌入式系统的扩展与延伸。 CPS典型的应用场景有：健康管理、智能维护、远程征兆性…...
Docker 数据管理[文件互访] 端口映射[暴露端口提供服务] 容器互联[指定容器名防止IP变动]
Docker 的数据管理 管理 Docker 容器中数据主要有两种方式：数据卷（Data Volumes）和数据卷容器（DataVolumes Containers）。 1．数据卷（宿主机与容器间传输 防止删除容器后数据丢失） 数…...
【stable diffusion】保姆级入门课程04-Stable diffusion（SD）图生图-局部重绘的用法
目录 0.本章素材 1.什么是局部重绘 2.局部重绘和涂鸦有什么不同 3.操作界面讲解 3.1.蒙版模糊 3.2.蒙版模式 3.3.蒙版蒙住的内容 3.4.重绘区域 4.局部重绘的应用（面部修复） 5.课后训练 0.本章素材 chilloutmix模型(真人模型)百度地址…...
制作Java8环境Docker镜像
制作Java8环境Docker镜像 这里介绍如何制作一个java8环境的镜像，用于运行java应用程序。 1.安装包 这里采用OpenJDK，不会涉及版本问题。 同样思源中文字体也是开源的，没有版权问题。 OpenJDK8：OpenJDK8U-jdk_x64_linux_hotsp…...
抖音SEO源码开发指南：介绍如何开发抖音SEO源码的基本步骤和要点。
一、 抖音SEO源码开发指南： 确定目标：首先要明确开发抖音SEO源码的目标是什么，是提高搜索排名还是增加用户量等。根据不同的目标来制定开发策略和思路。 分析竞争：对于同类产品，要进行竞争分析，了解对手的…...
【SDOF振荡器的非线性-非弹性多轴时间响应分析】用于SDOF振荡器非线性非弹性时程分析的鲁棒性分析研究（Matlab代码实现）
目录 💥1 概述 📚2 运行结果 🎉3 参考文献 🌈4 Matlab代码实现 💥1 概述 进行SDOF振荡器的非线性非弹性时程分析的鲁棒性分析研究，旨在探究该方法对不同系统参数和分析条件变化的稳定性和可靠性。以下是一…...
VMPWN的入门系列-1
5.1 实验一 VMPWN1 5.1.1 题目简介 这是一道基础的VM相关题目，VMPWN的入门级别题目。前面提到VMPWN一般都是接收字节码然后对字节码进行解析，但是这道题目不接受字节码，它接收字节码的更高一级语言：汇编。程序直接接收类似”mov…...
将标签中某一个类别添加到另一个标签中
现在有两张CItyscapes数据集的标签，假设我想把第二张图骑车的人添加到第一张图，暂且不考虑添加位置的变换，那么该如何操作呢？ 1：将骑车的人和车作为两个类别独立于其他的类别出来。 2：将这两个类别作为一个…...
将指定图片控件中的图片闪烁
/// <summary> /// 将指定图片控件中的图片闪烁 /// </summary> /// <param name"pic">需要闪烁的图片控件</param> public static void FlashImage(object picBox) { try …...
【MySQL】表的增删查改
目录 一、Create创建 1、单行数据全列插入 2、多行数据指定列插入 3、插入更新 4、替换 二、Retrieve查询 1、SELECT 列 1.1、 全列查询 1.2、指定列查询 1.3、查询字段为表达式 1.4、结果去重 2、where条件 2.1、英语不及格的同学及英语成绩 ( < 60 ) 2.2、语…...
Python 爬虫的学习 day01 ，爬虫的基本知识， requests 和 charde模块， get函数的使用
1.Python 爬虫 1.1什么是网络爬虫 网络爬虫，又称为网页蜘蛛，网络机器人，是一种按照一定的规则，自动地抓取万维网信息的程序或者脚本，另外一些不常使用的名字还有蚂蚁、自动索引、模拟程序或者蠕虫。 1.2 网络爬虫的特…...
【数据挖掘】时间序列的傅里叶变换：用numpy解释的快速卷积
一、说明 本篇告诉大家一个高级数学模型，即傅里叶模型的使用； 当今，傅里叶变换及其所有变体构成了我们现代世界的基础，为压缩、通信、图像处理等技术提供了动力。我们从根源上理解，从根本上应用，这是值得付…...
Chatgpt Web API 创建对话，免费，不计token数量，模仿网页提交对话
Chatgpt API 是收费的，按token使用量计费 Chatgpt Web API 免费的，只要有账号就可以使用。 curl https://chat.openai.com/backend-api/conversation \-H authority: chat.openai.com \-H accept: text/event-stream \-H accept-language: zh-CN,zh;q…...
