MM-Camera架构-Preview 流程分析

目录

1 log开的好，问题都能搞

• 22/12/01

在看preview流程的时候(mm-camera2/media-controller/modules/pproc-new/cpp/cpp_module.c )，上来有一句：
CPP_HIGH("name=%s", name);
查看定义在：mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_log.h

#define CPP_LOW(fmt, args…) CLOGL(CAM_CPP_MODULE, fmt, ##args)
#define CPP_HIGH(fmt, args…) CLOGH(CAM_CPP_MODULE, fmt, ##args)
#define CPP_ERR(fmt, args…) CLOGE(CAM_CPP_MODULE, fmt, ##args)
#define CPP_DBG(fmt, args…) CLOGD(CAM_CPP_MODULE, fmt, ##args)
#define CPP_INFO(fmt, args…) CLOGI(CAM_CPP_MODULE, fmt, ##args)
#define CPP_WARN(fmt, args…) CLOGW(CAM_CPP_MODULE, fmt, ##args)

看起来是针对mm-camera2/media-controller/modules/pproc-new/cpp/目录下的文件单独定义的log level。
CAM_CPP_MODULE是一个枚举值，同类型的还有以下这些。这些枚举值代表着不同模块的

typedef enum {CAM_NO_MODULE,CAM_MCT_MODULE,CAM_SENSOR_MODULE,CAM_IFACE_MODULE,CAM_ISP_MODULE,CAM_PPROC_MODULE,CAM_IMGLIB_MODULE,CAM_CPP_MODULE,CAM_HAL_MODULE,CAM_JPEG_MODULE,CAM_C2D_MODULE,CAM_STATS_MODULE,CAM_STATS_AF_MODULE,CAM_STATS_AEC_MODULE,CAM_STATS_AWB_MODULE,CAM_STATS_ASD_MODULE,CAM_STATS_AFD_MODULE,CAM_STATS_Q3A_MODULE,CAM_STATS_IS_MODULE,CAM_STATS_HAF_MODULE,CAM_STATS_CAF_SCAN_MODULE,CAM_SHIM_LAYER,CAM_LAST_MODULE
} cam_modules_t;

而像CLOGI，CLOGD，CLOGL等等也都有定义：

#undef CLOGI
#define CLOGI(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_INFO, fmt, ##args)
#undef CLOGD
#define CLOGD(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_DEBUG, fmt, ##args)
#undef CLOGL
#define CLOGL(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_LOW, fmt, ##args)
#undef CLOGW
#define CLOGW(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_WARN, fmt, ##args)
#undef CLOGH
#define CLOGH(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_HIGH, fmt, ##args)
#undef CLOGE
#define CLOGE(module, fmt, args...)                \CLOGx(module, CAM_GLBL_DBG_ERR, fmt, ##args)

CLOGx的定义如下，如果g_cam_log数组的元素存在，就可以打印log。

/* logging macros */
#undef CLOGx
#define CLOGx(module, level, fmt, args...)                         \if (g_cam_log[module][level]) {                                  \cam_debug_log(module, level, __func__, __LINE__, fmt, ##args); \}

g_cam_log是一个二维数组，代表当前跟踪日志记录配置。

/* current trace logging configuration */
/* g_cam_log[cam_modules_t][cam_global_debug_level_t] */
extern int g_cam_log[CAM_LAST_MODULE][CAM_GLBL_DBG_INFO + 1];
//CAM_LAST_MODULE和CAM_GLBL_DBG_INFO + 1代表两个enum的最大值

其中module代表的是组别，也就是上面的enum cam_modules_t。level代表的是log的等级，有如下等级：

/* values that persist.vendor.camera.global.debug can be set to */
/* all camera modules need to map their internal debug levels to this range */
typedef enum {CAM_GLBL_DBG_NONE  = 0,CAM_GLBL_DBG_ERR   = 1,CAM_GLBL_DBG_WARN  = 2,CAM_GLBL_DBG_HIGH  = 3,CAM_GLBL_DBG_DEBUG = 4,CAM_GLBL_DBG_LOW   = 5,CAM_GLBL_DBG_INFO  = 6
} cam_global_debug_level_t;

• 22/12/02
  突然发现，HIGH等级的log貌似不打印，于是在文件里加上这几个debug的语句：

CPP_LOW(“sunmy_ low\n”);
CPP_HIGH(“sunmy_ HIGH\n”);
CPP_ERR(“sunmy_ ERR\n”);
CPP_DBG(“sunmy_ DBG\n”);
CPP_INFO(“sunmy_ INFO\n”);
CPP_WARN(“sunmy_ WARN\n”);

发现只有CPP_ERR，CPP_INFO，CPP_WARN等级的log默认打印，其余的默认不打印。
在camx-chi架构中，确实有很多log等级(比如verbose)需要setprop才能打开。这个的原理应该一样。
在文件mm-camera2/media-controller/modules/pproc-new/cpp/cpp_module.c 发现一个函数：

static void cpp_module_loglevel()
{char cpp_prop[PROPERTY_VALUE_MAX];memset(cpp_prop, 0, sizeof(cpp_prop));property_get("persist.vendor.camera.cpp.debug.mask", cpp_prop, "1");gcam_cpp_loglevel = atoi(cpp_prop);/* Keep the deafault modules enabled  */property_get("persist.vendor.camera.cpp.mod.mask", cpp_prop, "2097407");g_cpp_log_featureMask = atoi(cpp_prop);
}

发现setprop persist.vendor.camera.cpp.debug.mask为不同的值就可以打印不同level的log。

这个结构体数组可以打印所有组别的log：

/* current trace logging configuration */
typedef struct {cam_global_debug_level_t  level;int                       initialized;const char               *name;const char               *prop;
} module_debug_t;static module_debug_t cam_loginfo[(int)CAM_LAST_MODULE] = {{CAM_GLBL_DBG_ERR, 1,"",         "persist.vendor.camera.global.debug"     }, /* CAM_NO_MODULE     */{CAM_GLBL_DBG_ERR, 1,"<MCT   >", "persist.vendor.camera.mct.debug"        }, /* CAM_MCT_MODULE    */{CAM_GLBL_DBG_ERR, 1,"<SENSOR>", "persist.vendor.camera.sensor.debug"     }, /* CAM_SENSOR_MODULE */{CAM_GLBL_DBG_WARN, 1,"<IFACE >", "persist.vendor.camera.iface.logs"       }, /* CAM_IFACE_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<ISP   >", "persist.vendor.camera.isp.debug"        }, /* CAM_ISP_MODULE    */{CAM_GLBL_DBG_ERR, 1,"<PPROC >", "persist.vendor.camera.pproc.debug.mask" }, /* CAM_PPROC_MODULE  */{CAM_GLBL_DBG_WARN, 1,"<IMGLIB>", "persist.vendor.camera.imglib.logs"      }, /* CAM_IMGLIB_MODULE */{CAM_GLBL_DBG_WARN, 1,"<CPP   >", "persist.vendor.camera.cpp.debug.mask"   }, /* CAM_CPP_MODULE    */{CAM_GLBL_DBG_ERR, 1,"<HAL   >", "persist.vendor.camera.hal.debug"        }, /* CAM_HAL_MODULE    */{CAM_GLBL_DBG_ERR, 1,"<JPEG  >", "persist.vendor.camera.mmstill.logs"     }, /* CAM_JPEG_MODULE   */{CAM_GLBL_DBG_WARN, 1,"<C2D   >", "persist.vendor.camera.c2d.debug.mask"   }, /* CAM_C2D_MODULE    */{CAM_GLBL_DBG_ERR, 1,"<STATS >", "persist.vendor.camera.stats.debug" }, /* CAM_STATS_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_AF >", "persist.vendor.camera.stats.af.debug"    }, /* CAM_STATS_AF_MODULE   */{CAM_GLBL_DBG_ERR, 1,"<STATS_AEC >", "persist.vendor.camera.stats.aec.debug"  }, /* CAM_STATS_AEC_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_AWB >", "persist.vendor.camera.stats.awb.debug"  }, /* CAM_STATS_AWB_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_ASD >", "persist.vendor.camera.stats.asd.debug"  }, /* CAM_STATS_ASD_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_AFD >", "persist.vendor.camera.stats.afd.debug"  }, /* CAM_STATS_AFD_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_Q3A >", "persist.vendor.camera.stats.q3a.debug"  }, /* CAM_STATS_Q3A_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_AIS >", "persist.vendor.camera.stats.is.debug"   }, /* CAM_STATS_IS_MODULE   */{CAM_GLBL_DBG_ERR, 1,"<STATS_HAF >", "persist.vendor.camera.stats.haf.debug"  }, /* CAM_STATS_HAF_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<STATS_CAFSCAN >", "persist.vendor.camera.stats.cafscan"  }, /* CAM_STATS_CAFSCAN_MODULE  */{CAM_GLBL_DBG_ERR, 1,"<SHIM  >", "persist.vendor.camera.shim.debug"          }, /* CAM_SHIM_LAYER    */
};

2 lib

frameworks/av/services/camera/libcameraservice/ /system/lib/libcameraservice.so

hardware/qcom/camera/QCamera2/ /vendor/lib/hw/camera.sdm660.so
hardware/qcom/camera/QCamera2/stack/mm-camera-interface/ /vendor/lib/libmmcamera_interface.so

hardware/interfaces/camera/device/1.0/ /system/lib/[e-mail]

hardware/interfaces/camera/device/3.2/default/ /vendor/lib/[e-mail]

mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/ /vendor/lib/libmmcamera2_cpp_module.so

mm-camera/mm-camera2/media-controller/mct_shim_layer/ /vendor/lib/libmmcamera2_mct_shimlayer.so

mm-camera/mm-camera2/media-controller/mct/ /vendor/lib/libmmcamera2_mct.so

3 preview

framework preview

3.1 打开视频流

3.1.1 cpp_module_start_session

打开摄像头preview时，会调用到cpp_module_start_session方法： vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_module.c

boolean cpp_module_start_session(mct_module_t *module, uint32_t sessionid)
{cpp_module_ctrl_t *ctrl = (cpp_module_ctrl_t *) MCT_OBJECT_PRIVATE(module);if(ctrl->session_params[i] == NULL) {//初始化ctrl->session_params[]的内容//1.申请空间ctrl->session_params[i] = (cpp_module_session_params_t*) CAM_MALLOC(sizeof(cpp_module_session_params_t))//2.清零memset(ctrl->session_params[i], 0x00, sizeof(cpp_module_session_params_t));//3.初始化session_params 参考struct _cpp_module_session_params_t的成员}/* start the thread only when first session starts */if(ctrl->session_count == 0) {/* spawn the cpp thread */rc = cpp_thread_create(module);}
}

3.1.2 cpp_thread_create

将cpp_module_start_session的参数（mct_module_t *module）透传到cpp_thread_create中创建线程： vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_thread.c

int32_t cpp_thread_create(mct_module_t *module)
{...//设置cpp_thread_started的标志ctrl->cpp_thread_started = FALSE;//创建线程  cpp_thread_func  线程函数的入口地址rc = pthread_create(&(ctrl->cpp_thread), NULL, cpp_thread_func, module);//修改线程名pthread_setname_np(ctrl->cpp_thread, "CAM_cpp");/* wait to confirm if the thread is started */    //PTHREAD_COND_WAIT_TIME即pthread_cond_timedwait 当在指定时间内有信号传过来时，pthread_cond_timedwait()返回0，否则返回一个非0数，rc就是返回值PTHREAD_COND_WAIT_TIME(&(ctrl->th_start_cond), &(ctrl->cpp_mutex),&timeout, CPP_WAIT_TIMEOUT, rc);
}

3.1.3 cpp_thread_func

vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_thread.c

void* cpp_thread_func(void* data)
{mct_module_t *module = (mct_module_t *) data;cpp_module_ctrl_t *ctrl = (cpp_module_ctrl_t *) MCT_OBJECT_PRIVATE(module);PTHREAD_MUTEX_LOCK(&(ctrl->cpp_mutex));//设置cpp_thread_started状态，代表cpp_thread已经跑起来了ctrl->cpp_thread_started = TRUE;//用于唤醒th_start_condpthread_cond_signal(&(ctrl->th_start_cond));//------------------sundp-3.1--------------/* open the cpp hardware */rc = cpp_hardware_open_subdev(ctrl->cpphw);     /* subscribe for event on subdev fd *///注意cpp_hardware_cmd_t里的联合体cpp_hardware_cmd_t cmd;//cmd.type代表此命令的类型，除了这里的订阅事件，还有像CPP_HW_CMD_STREAMON，CPP_HW_CMD_STREAMON等等cmd.type = CPP_HW_CMD_SUBSCRIBE_EVENT;    //------------------sundp-3.2--------------rc = cpp_hardware_process_command(ctrl->cpphw, cmd);   /* poll on the pipe readfd and subdev fd */struct pollfd pollfds[2];uint32_t num_fds = 2;int ready = 0;uint32_t i = 0;pollfds[PIPE_FD_IDX].fd = ctrl->pfd[READ_FD];pollfds[PIPE_FD_IDX].events = POLLIN|POLLPRI;pollfds[SUBDEV_FD_IDX].fd = ctrl->cpphw->subdev_fd;pollfds[SUBDEV_FD_IDX].events = POLLIN|POLLPRI;while(1) {/* poll on the fds with no timeout *///------------------sundp-3.3--------------ready = poll(pollfds, (nfds_t)num_fds, -1);    if(ready > 0) {/* loop through the fds to see if any event has occured */for(i=0; i<num_fds; i++) {if(pollfds[i].revents & (POLLIN|POLLPRI)) {//pollfds[0].revents = 1//pollfds[1].revents = 0//pollfds[0].revents = 0//pollfds[1].revents = 2switch(i) {case PIPE_FD_IDX: {int num_read=0;cpp_thread_msg_t pipe_msg;num_read = read(pollfds[i].fd, &(pipe_msg),sizeof(cpp_thread_msg_t));//------------------sundp-3.4--------------rc = cpp_thread_process_pipe_message(ctrl, pipe_msg);    break;}case SUBDEV_FD_IDX: {//------------------sundp-3.5--------------rc = cpp_thread_process_hardware_event(ctrl);  //读到dev fd消息，处理内核事件  break;}}}}}
}

sundp-3.1 cpp_hardware_open_subdev(ctrl->cpphw)

这里打开v4l的subdev。
ctrl->cpphw 是struct cpp_hardware_t定义的，结构体成员subdev_ids[MAX_CPP_DEVICES]代表的是：/dev/v4l-sundev*:

sdm660_64:/dev # ls v4l
v4l-subdev0 v4l-subdev11 v4l-subdev14 v4l-subdev17 v4l-subdev2 v4l-subdev22 v4l-subdev4 v4l-subdev7
v4l-subdev1 v4l-subdev12 v4l-subdev15 v4l-subdev18 v4l-subdev20 v4l-subdev23 v4l-subdev5 v4l-subdev8
v4l-subdev10 v4l-subdev13 v4l-subdev16 v4l-subdev19 v4l-subdev21 v4l-subdev3 v4l-subdev6 v4l-subdev9

这里前后置 打开的都是v4l-subdev17

代码路径：
vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_hardware.c

int32_t cpp_hardware_open_subdev(cpp_hardware_t *cpphw)
{int fd;char dev_name[SUBDEV_NAME_SIZE_MAX];snprintf(dev_name, sizeof(dev_name), "/dev/v4l-subdev%d",cpphw->subdev_ids[0]);//打开v4l-subdevXX设备fd = open(dev_name, O_RDWR | O_NONBLOCK);cpphw->subdev_fd = fd;//flag已经打开设备cpphw->subdev_opened = TRUE;//通过ioctl，获取设备参数rc = ioctl(cpphw->subdev_fd, VIDIOC_MSM_CPP_GET_INST_INFO, &v4l2_ioctl);//填充ctrl->cpphw的信息：
}

open设备节点操作，对应到内核，kernel/msm-4.14/drivers/media/platform/msm/camera_v2/pproc/cpp/msm_cpp.c
cpp_open_node 主要做了两件事：1、初始化mem， 2、初始化硬件

cpp_init_mem() ： 其实就是获取cpp_dev->iommu_hdl，这个东西是在msm_cam_smmu设备driver中统一管理的，vfe中有记录过这里。
cpp_init_hardware()：设置一些硬件参数、时钟、注册中断以及buf管理接口：msm_cam_buf_mgr_register_ops()

static int cpp_open_node(struct v4l2_subdev *sd, struct v4l2_subdev_fh *fh)
{cpp_dev = v4l2_get_subdevdata(sd);if (cpp_dev->cpp_open_cnt == 1) {rc = cpp_init_mem(cpp_dev);rc = cpp_init_hardware(cpp_dev);cpp_dev->state = CPP_STATE_IDLE;}
}

VIDIOC_MSM_CPP_GET_INST_INFO不重要，简单记录：

static long msm_cpp_subdev_do_ioctl(struct file *file, unsigned int cmd, void *arg)
{switch (cmd) {case VIDIOC_DQEVENT:return v4l2_event_dequeue(vfh, arg, file->f_flags & O_NONBLOCK);case VIDIOC_SUBSCRIBE_EVENT:return v4l2_subdev_call(sd, core, subscribe_event, vfh, arg);case VIDIOC_MSM_CPP_GET_INST_INFO: {uint32_t i;struct cpp_device *cpp_dev = v4l2_get_subdevdata(sd);struct msm_camera_v4l2_ioctl_t *ioctl_ptr = arg;struct msm_cpp_frame_info_t inst_info;memset(&inst_info, 0, sizeof(struct msm_cpp_frame_info_t));for (i = 0; i < MAX_ACTIVE_CPP_INSTANCE; i++) {if (cpp_dev->cpp_subscribe_list[i].vfh == vfh) {inst_info.inst_id = i;break;}}}break;default:return v4l2_subdev_call(sd, core, ioctl, cmd, arg);}
}

sundp-3.2 cpp_hardware_process_command(ctrl->cpphw, cmd)

cpp_hardware_process_command 用于处理给硬件的命令。在此过程中更新硬件状态。

代码路径：vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_hardware.c

int32_t cpp_hardware_process_command(cpp_hardware_t *cpphw,cpp_hardware_cmd_t cmd)
{...switch (cmd.type) {case CPP_HW_CMD_GET_CAPABILITIES:    rc = cpp_hardware_get_capabilities(cpphw);     break;case CPP_HW_CMD_SUBSCRIBE_EVENT:     rc = cpp_hardware_subcribe_v4l2_event(cpphw);  break;case CPP_HW_CMD_UNSUBSCRIBE_EVENT:   rc = cpp_hardware_unsubcribe_v4l2_event(cpphw);break;case CPP_HW_CMD_NOTIFY_EVENT:        rc = cpp_hardware_notify_event_get_data(cpphw, cmd.u.event_data); break;case CPP_HW_CMD_STREAMON:            rc = cpp_hardware_process_streamon(cpphw, cmd.u.buff_update);break;case CPP_HW_CMD_STREAMOFF:           rc = cpp_hardware_process_streamoff(cpphw, cmd.u.streamoff_data);  break;case CPP_HW_CMD_LOAD_FIRMWARE:       rc = cpp_hardware_load_firmware(cpphw);  break;case CPP_HW_CMD_PROCESS_FRAME:       rc = cpp_hardware_process_frame(cpphw, &cmd);  break;case CPP_HW_CMD_PROCESS_PARTIAL_FRAME:rc = cpp_hardware_process_partial_frame(cpphw, cmd.u.partial_frame);  break;case CPP_HW_CMD_QUEUE_BUF:           rc = cpp_hardware_send_buf_done(cpphw, cmd.u.event_data);  break;case CPP_HW_CMD_SET_CLK:             rc = cpp_hardware_set_clock(cpphw, &cmd.u.clock_settings);  break;case CPP_HW_CMD_BUF_UPDATE:          rc = cpp_hardware_update_buffer_list(cpphw, cmd.u.buff_update);  break;case CPP_HW_CMD_POP_STREAM_BUFFER:   rc = cpp_hardware_pop_stream_buffer(cpphw, cmd.u.event_data);  break;case CPP_HW_CMD_NOTIFY_BUF_DONE:     rc = cpp_hardware_notify_buf_done(cpphw, cmd.u.buf_done_identity);  break;case CPP_HW_CMD_UPDATE_PENDING_BUF:  rc = cpp_hardware_update_pending_buffer(cpphw, cmd.u.status); break;default:                             CPP_ERR("bad command type=%d", cmd.type); }...
}

这里的是CPP_HW_CMD_SUBSCRIBE_EVENT即cpp_hardware_subcribe_v4l2_event
订阅subdevfd上的事件,通知硬件打开preview.
v4l2_event_subscription定义在：kernel/msm-4.14/include/uapi/linux/videodev2.h

struct v4l2_event_subscription {
—__u32>–>—>—>—type;
—__u32>–>—>—>—id;
—__u32>–>—>—>—flags;
—__u32>–>—>—>—reserved[5];
};

V4L2_EVENT_CPP_FRAME_DONE的定义：

#define V4L2_EVENT_CPP_FRAME_DONE (V4L2_EVENT_PRIVATE_START + 0)

V4L2_EVENT_PRIVATE_START的定义：

#define V4L2_EVENT_PRIVATE_START>—>—0x08000000

static int32_t cpp_hardware_subcribe_v4l2_event(cpp_hardware_t *cpphw)
{struct v4l2_event_subscription sub;struct msm_camera_v4l2_ioctl_t v4l2_ioctl;sub.id = cpphw->inst_id;sub.type = V4L2_EVENT_CPP_FRAME_DONE;rc = ioctl(cpphw->subdev_fd, VIDIOC_SUBSCRIBE_EVENT, &sub);cpphw->event_subs_info.valid = TRUE;cpphw->event_subs_info.id = sub.id;cpphw->event_subs_info.type = sub.type;return 0;
}

ioctl发送到内核： kernel/msm-4.14/drivers/media/platform/msm/camera_v2/pproc/cpp/msm_cpp.c

static long msm_cpp_subdev_do_ioctl(struct file *file, unsigned int cmd, void *arg)
{//得到video devicestruct video_device *vdev = video_devdata(file);//得到v4l2_subdevstruct v4l2_subdev *sd = vdev_to_v4l2_subdev(vdev);struct v4l2_fh *vfh = file->private_data;switch (cmd) {...case VIDIOC_SUBSCRIBE_EVENT:return v4l2_subdev_call(sd, core, subscribe_event, vfh, arg);...}
}

v4l2_subdev_call(sd, core, subscribe_event, vfh, arg)是一个宏:

#define v4l2_subdev_call(sd, o, f, args...)>            \({                                \int __result;                        \if (!(sd))                        \__result = -ENODEV;>            \else if (!((sd)->ops->o && (sd)->ops->o->f))        \__result = -ENOIOCTLCMD;            \else                            \__result = (sd)->ops->o->f((sd), ##args);    \__result;                        \})

(sd)->ops->o->f((sd), ##args)对应的是函数指针：

int (*subscribe_event)(struct v4l2_subdev *sd, struct v4l2_fh *fh,struct v4l2_event_subscription *sub);

指向的函数是msm_cpp_subscribe_event。

static struct v4l2_subdev_core_ops msm_cpp_subdev_core_ops = {
—.ioctl = msm_cpp_subdev_ioctl,
—.subscribe_event = msm_cpp_subscribe_event,
—.unsubscribe_event = msm_cpp_unsubscribe_event,
};

static int msm_cpp_subscribe_event(struct v4l2_subdev *sd, struct v4l2_fh *fh, struct v4l2_event_subscription *sub)
{return v4l2_event_subscribe(fh, sub, MAX_CPP_V4l2_EVENTS, NULL);
}

V4L2 events 提供一种将event传递到用户空间的通用方式。
v4l2_event_subscribe (fh, sub , elems, ops)
用来订阅事件，ops参数可以让驱动指定一个回调函数：add，del，replace，merge。一共有4个可选的回调函数，如果不需要也可以传入NULL参数。 kernel/msm-4.14/drivers/media/v4l2-core/v4l2-event.c

int v4l2_event_subscribe(struct v4l2_fh *fh, const struct v4l2_event_subscription *sub, unsigned elems,const struct v4l2_subscribed_event_ops *ops)
{struct v4l2_subscribed_event *sev, *found_ev;sev = kvzalloc(sizeof(*sev) + sizeof(struct v4l2_kevent) * elems,GFP_KERNEL);for (i = 0; i < elems; i++) sev->events[i].sev = sev;sev->type = sub->type;	sev->id = sub->id;sev->flags = sub->flags;	sev->fh = fh;sev->ops = ops;found_ev = v4l2_event_subscribed(fh, sub->type, sub->id);if (!found_ev) list_add(&sev->list, &fh->subscribed);if (found_ev) {kvfree(sev);} else if (sev->ops && sev->ops->add) {ret = sev->ops->add(sev, elems);}
}

3.2 sensor视频流buffer队列

3.2.1 cpp_thread_func

上文在函数cpp_thread_func中说了sundp-3.1和sundp-3.2，接下来说一下剩下的：

....
/* poll on the pipe readfd and subdev fd */
struct pollfd pollfds[2];
uint32_t num_fds = 2;
int ready = 0;
uint32_t i = 0;
pollfds[PIPE_FD_IDX].fd = ctrl->pfd[READ_FD];
pollfds[PIPE_FD_IDX].events = POLLIN|POLLPRI;
//POLLIN   有数据可读。
//POLLPRI  有紧迫数据可读。
pollfds[SUBDEV_FD_IDX].fd = ctrl->cpphw->subdev_fd;
pollfds[SUBDEV_FD_IDX].events = POLLIN|POLLPRI;
CPP_HIGH("cpp_thread entering the polling loop...");
while(1) {ready = poll(pollfds, (nfds_t)num_fds, -1);
....

sundp-3.3 poll(pollfds, (nfds_t)num_fds, -1);

sundp-3.1和sundp-3.2启动v4l2设备成功后，cpp_thread线程同时侦听一个pipe fd，和设备节点/dev/v4l-subdevXX

( 注：打开v4l-subdevXX设备
fd = open(dev_name, O_RDWR | O_NONBLOCK);
cpphw->subdev_fd = fd;)。

struct pollfd pollfds[2];

struct pollfd{int fd; /*文件描述符，如建立socket后获取的fd, 此处表示想查询的文件描述符*/short events;	/*等待的事件，就是要监测的感兴趣的事情*/short revents;	/*实际发生了的事情*/
};

这里的ready = poll(pollfds, (nfds_t)num_fds, -1);是将当前的文件指针挂到等待队列中

结构介绍：
int poll(struct pollfd *fds, unsigned int nfds, int timeout)
参数介绍：
pollfd *fds : 指向pollfd结构体数组，用于存放需要检测器状态的Socket 描述符或其它文件描述符。
unsigned int nfds: 指定pollfd 结构体数组的个数，即监控几个pollfd.
timeout:指poll() 函数调用阻塞的时间，单位是ms.如果timeout=0则不阻塞，如timeout=INFTIM 表 示一直阻塞直到感兴趣的事情发生。
返回值：
0 表示数组fds 中准备好读，写或出错状态的那些socket描述符的总数量
==0 表示数组fds 中都没有准备好读写或出错，当poll 阻塞超时timeout 就会返回。
-1 表示poll() 函数调用失败，同时回自动设置全局变量errno.
函数特点：
每当函数调用后，不会清空这个fds指向的数组，适用于大量socket 描述符的情况。而select()函数调用后会清空它所检测的socket描述符集合，因此select()只是用检测一个socket 描述符的情况。
如果待监测的socket 描述符为负值，则这个描述符的检测就会被忽略，poll()函数返回时直接把revents 设置为0
该poll()函数不会受到socket 描述符上的O_NDELAY 标记和O_NONBLOCK 标记的影响。

sundp-3.4 cpp_thread_process_pipe_message

poll函数运行成功后，接下来会循环浏览num_fds(即pipe fd和subdev_fd)
以查看是否发生了任何事件，当pipe fd上有消息时，先读到pipe_msg。

          case PIPE_FD_IDX: {int num_read=0;cpp_thread_msg_t pipe_msg;num_read = read(pollfds[i].fd, &(pipe_msg),sizeof(cpp_thread_msg_t));rc = cpp_thread_process_pipe_message(ctrl, pipe_msg);    break;}

接下来进入cpp_thread_process_pipe_message处理。 vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_thread.c

static int32_t cpp_thread_process_pipe_message(cpp_module_ctrl_t *ctrl,cpp_thread_msg_t msg)
{cpp_hardware_cmd_t cmd;switch(msg.type) {//这里应该是出错才会走。信息中止case CPP_THREAD_MSG_ABORT: ......//有事件case CPP_THREAD_MSG_NEW_EVENT_IN_Q: {cpp_module_event_t* cpp_event;/*当队列进程中有一些有效事件时，处理它 */while(1) {cpp_event = cpp_thread_get_event_from_queue(ctrl);if(!cpp_event) { break; }rc = cpp_thread_process_queue_event(ctrl, cpp_event);}break;}
}

cpp_thread_process_queue_event
cpp_event->type的类型：

typedef enum {
CPP_MODULE_EVENT_PROCESS_BUF,
CPP_MODULE_EVENT_DIVERT_BUF,
CPP_MODULE_EVENT_CLOCK,
CPP_MODULE_EVENT_PARTIAL_FRAME,
CPP_MODULE_EVENT_ISP_BUFFER_DROP
} cpp_module_event_type_t;

static int32_t cpp_thread_process_queue_event(cpp_module_ctrl_t *ctrl, cpp_module_event_t* cpp_event)
{//选择事件类型：预览的时候是CPP_MODULE_EVENT_PROCESS_BUFswitch(cpp_event->type) {case CPP_MODULE_EVENT_DIVERT_BUF:rc = cpp_thread_handle_divert_buf_event(ctrl, cpp_event);break;case CPP_MODULE_EVENT_PROCESS_BUF:rc = cpp_thread_handle_process_buf_event(ctrl, cpp_event);break;case CPP_MODULE_EVENT_CLOCK:rc = cpp_thread_handle_clock_event(ctrl, cpp_event);break;case CPP_MODULE_EVENT_PARTIAL_FRAME:rc = cpp_thread_handle_partial_frame_event(ctrl, cpp_event);break;case CPP_MODULE_EVENT_ISP_BUFFER_DROP:cpp_thread_handle_isp_drop_buffer_event(ctrl, cpp_event);break;
}

cpp_thread_handle_process_buf_event

static int32_t cpp_thread_handle_process_buf_event(cpp_module_ctrl_t* ctrl, cpp_module_event_t* cpp_event)
{cpp_module_stream_params_t  *stream_params = NULL;cpp_module_session_params_t *session_params = NULL;......//填充cookie/*cookie用于将数据附加到内核帧，处理完成后将立即取回？？？*/cpp_module_hw_cookie_t *cookie = NULL;//用cpp_envent填充hw_params的参数cpp_hardware_params_t* hw_params = NULL;hw_params = &(cpp_event->u.process_buf_data.hw_params);hw_params->cookie = cookie;hw_params->frame_id = cpp_event->u.process_buf_data.isp_buf_divert.buffer.sequence; hw_params->timestamp = cpp_event->u.process_buf_data.isp_buf_divert.buffer.timestamp;hw_params->buffer_info.fd = in_frame_fd;....../* get stream parameters based on the event identity */cpp_module_get_params_for_identity(ctrl, hw_params->identity,&session_params, &stream_params);/*Before validation, swap dimensions if 90 or 270 degrees rotation*///画面的旋转角度交换？cpp_hardware_rotation_swap(hw_params,video_type_flag);/* before giving the frame to hw, make sure the parameters are good *///应该是验证当前帧的参数是否正确，不正确就丢弃if(FALSE == cpp_hardware_validate_params(hw_params)){......}//计算裁剪？rc = cpp_params_calculate_crop(hw_params);......cmd.type = CPP_HW_CMD_PROCESS_FRAME;cmd.ctrl = ctrl;cmd.u.hw_params = hw_params;//这里可以dump，可以看一下 第五章 dump
#ifdef _ANDROID_if (session_params->cpp_debug_enable)cpp_thread_dump_frame(hw_params,hw_params->buffer_info.fd,&cmd,1);
#endifrc = cpp_hardware_process_command(ctrl->cpphw, cmd);  ....../* Update and post the current session's diag parameters *///更新并发布当前session的诊断参数cpp_module_util_update_session_diag_params(ctrl->p_module, hw_params);
}

cpp_hardware_process_command
执行到CPP_HW_CMD_PROCESS_FRAME，就是cpp_hardware_process_frame()： vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_hardware.c

static int32_t cpp_hardware_process_frame(cpp_hardware_t *cpphw, cpp_hardware_cmd_t *cmd)
{struct cpp_frame_info_t cpp_frame_infostruct msm_cpp_frame_info_t *msm_cpp_frame_info;......rc = cpp_params_create_frame_info(cpphw, hw_params, &cpp_frame_info);//将sysetm接口参数转换为msm frame cfg参数cpp_frame_info.frame_id = hw_params->frame_id;cpp_frame_info.timestamp = hw_params->timestamp;cpp_frame_info.identity = hw_params->identity;.......msm_cpp_frame_info = cpp_hardware_create_hw_frame(cpphw, &cpp_frame_info);/* send kernel ioctl for processing */struct msm_camera_v4l2_ioctl_t v4l2_ioctl;v4l2_ioctl.ioctl_ptr = (void *)msm_cpp_frame_info;v4l2_ioctl.len = sizeof(struct msm_cpp_frame_info_t);rc = ioctl(cpphw->subdev_fd, VIDIOC_MSM_CPP_CFG, &v4l2_ioctl);.......
}

VIDIOC_MSM_CPP_CFG通过ioctl，到了内核： kernel/msm-4.14/drivers/media/platform/msm/camera_v2/pproc/cpp/msm_cpp.c //内核的这部分我没看

static long msm_cpp_subdev_fops_compat_ioctl(struct file *file, unsigned int cmd, unsigned long arg)
{bool is_copytouser_req = truestruct msm_camera_v4l2_ioctl_t kp_ioctlvoid __user *up = (void __user *)arg;copy_from_user(&up32_ioctl, (void __user *)up, sizeof(up32_ioctl));kp_ioctl.id = up32_ioctl.id;kp_ioctl.len = up32_ioctl.len;kp_ioctl.trans_code = up32_ioctl.trans_code;kp_ioctl.ioctl_ptr = compat_ptr(up32_ioctl.ioctl_ptr);switch (cmd) {case VIDIOC_MSM_CPP_CFG32:{   copy_from_user(&k32_frame_info,	(void __user *)kp_ioctl.ioctl_ptr, sizeof(k32_frame_info));cpp_frame = get_64bit_cpp_frame_from_compat(&kp_ioctl);/* Configure the cpp frame */if (cpp_frame) {rc = msm_cpp_cfg_frame(cpp_dev, cpp_frame);/* Cpp_frame can be free'd by cfg_frame in error */if (rc >= 0) {k32_frame_info.output_buffer_info[0] = cpp_frame->output_buffer_info[0];k32_frame_info.output_buffer_info[1] = cpp_frame->output_buffer_info[1];}}kp_ioctl.trans_code = rc;copy_to_user((void __user *)kp_ioctl.ioctl_ptr, &k32_frame_info,	sizeof(k32_frame_info));cmd = VIDIOC_MSM_CPP_CFG;break;}。。。。。。
}

msm_cpp_cfg_frame

static int msm_cpp_cfg_frame(struct cpp_device *cpp_dev, struct msm_cpp_frame_info_t *new_frame)
{in_phyaddr = msm_cpp_fetch_buffer_info(cpp_dev,&new_frame->input_buffer_info,((new_frame->input_buffer_info.identity >> 16) & 0xFFFF),(new_frame->input_buffer_info.identity & 0xFFFF), &in_fd);op_index = new_frame->output_buffer_info[0].index;dup_index = new_frame->duplicate_buffer_info.index;if (new_frame->we_disable == 0) {int32_t iden = new_frame->identity;。。。。。。out_phyaddr0 = msm_cpp_fetch_buffer_info(cpp_dev, &new_frame->output_buffer_info[0],((iden >> 16) & 0xFFFF), (iden & 0xFFFF), &new_frame->output_buffer_info[0].fd);}out_phyaddr1 = out_phyaddr0;if (new_frame->duplicate_output) { 。。。。。。} //这个分支不执行。。。。。。msm_cpp_update_frame_msg_phy_address(cpp_dev, new_frame,in_phyaddr, out_phyaddr0, out_phyaddr1, tnr_scratch_buffer0, tnr_scratch_buffer1);rc = msm_cpp_set_group_buffer(cpp_dev, new_frame, out_phyaddr0, num_output_bufs);frame_qcmd->command = new_frame;rc = msm_cpp_send_frame_to_hardware(cpp_dev, frame_qcmd);  // 将new_frame参数发送到硬件
}

msm_cpp_send_frame_to_hardware()最终会执行对硬件地址的写操作，将frame的参数写入硬件。(TODO)

sundp-3.5 cpp_thread_process_hardware_event

sundp-3.1和sundp-3.2启动v4l2设备成功后，cpp_thread线程侦听设备节点/dev/v4l-subdevXX的节点（sundp-3.3）。当有视频buffer准备好时，会向该节点写入数据，这样sundp-3.3返回。
继续前面代码的sundp-3.4

接下来就是 sundp-3.5
poll函数运行成功后，接下来会循环浏览num_fds(即pipe fd和subdev_fd)以查看是否发生了任何事件，当subdev_fd上有消息时，进入 vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_thread.c

static int32_t cpp_thread_process_hardware_event(cpp_module_ctrl_t *ctrl)
{......./* get the event data from hardware *///从硬件获取event数据cmd.type = CPP_HW_CMD_NOTIFY_EVENT;cmd.u.event_data = &event_data;rc = cpp_hardware_process_command(ctrl->cpphw, cmd);  //sundp-3.6/* get stream parameters based on the event identity *///基于事件标识获取流参数 cpp_module_get_params_for_identity(ctrl, event_data.identity, &session_params, &stream_params);/* update the pending ack for this buffer */cookie = (cpp_module_hw_cookie_t *)event_data.cookie;buffer_access = event_data.input_buffer_access;rc = cpp_module_do_ack(ctrl, cookie->key, buffer_access);  // 发送buf event  sundp-3.9.......
}

sundp-3.6 cpp_hardware_process_command

首先从/dev/v4l-subdevXX节点读取event内容：

int32_t cpp_hardware_process_command(cpp_hardware_t *cpphw, cpp_hardware_cmd_t cmd)
{.......switch (cmd.type) {......case CPP_HW_CMD_NOTIFY_EVENT:rc = cpp_hardware_notify_event_get_data(cpphw, cmd.u.event_data);break;......}
}

cpp_hardware_notify_event_get_data

static int32_t cpp_hardware_notify_event_get_data(cpp_hardware_t *cpphw,cpp_hardware_event_data_t *event_data)
{struct v4l2_event event;//--------------------sundp-3.7----------rc = ioctl(cpphw->subdev_fd, VIDIOC_DQEVENT, &event);  v4l2_ioctl.ioctl_ptr = (void *)&frame;v4l2_ioctl.len = sizeof(struct msm_cpp_frame_info_t);//--------------------sundp-3.8----------rc = ioctl(cpphw->subdev_fd, VIDIOC_MSM_CPP_GET_EVENTPAYLOAD, &v4l2_ioctl); event_data->frame_id = frame.frame_id;event_data->buf_idx = frame.input_buffer_info.index;event_data->out_fd = frame.output_buffer_info[0].fd;event_data->identity = frame.identity;......// 设置event_data的内容
}

首先是sundp-3.7，通过对节点/dev/v4l-subdevXX的ioctl，到了内核： kernel/msm-4.14/drivers/media/platform/msm/camera_v2/pproc/cpp/msm_cpp.c

sundp-3.7 msm_cpp_subdev_do_ioctl

static long msm_cpp_subdev_do_ioctl(struct file *file, unsigned int cmd, void *arg)
{vdev = video_devdata(file);sd = vdev_to_v4l2_subdev(vdev);vfh = file->private_data;switch (cmd) {case VIDIOC_DQEVENT:return v4l2_event_dequeue(vfh, arg, file->f_flags & O_NONBLOCK);......
}

v4l2_event_dequeue就是从v4l设备的avaliable链表中取出第一个event，通过copy_to_user，返回给camera hal。

sundp-3.8 msm_cpp_subdev_fops_compat_ioctl

然后是sundp-3.8，通过对节点/dev/v4l-subdevXX的ioctl，到了内核： kernel/msm-4.14/drivers/media/platform/msm/camera_v2/pproc/cpp/msm_cpp.c

static long msm_cpp_subdev_fops_compat_ioctl(struct file *file, unsigned int cmd, unsigned long arg)
{bool is_copytouser_req = truestruct msm_camera_v4l2_ioctl_t kp_ioctlvoid __user *up = (void __user *)arg;copy_from_user(&up32_ioctl, (void __user *)up, sizeof(up32_ioctl));kp_ioctl.id = up32_ioctl.id;kp_ioctl.len = up32_ioctl.len;kp_ioctl.trans_code = up32_ioctl.trans_code;kp_ioctl.ioctl_ptr = compat_ptr(up32_ioctl.ioctl_ptr);switch (cmd) {.......case VIDIOC_MSM_CPP_GET_EVENTPAYLOAD32:{struct msm_device_queue *queue = &cpp_dev->eventData_q;event_qcmd = msm_dequeue(queue, list_eventdata, POP_FRONT);get_compat_frame_from_64bit(process_frame, &k32_process_frame);copy_to_user((void __user *)kp_ioctl.ioctl_ptr, &k32_process_frame, sizeof(struct msm_cpp_frame_info32_t)));cmd = VIDIOC_MSM_CPP_GET_EVENTPAYLOAD;break;}......}if (is_copytouser_req) {   // == true   //转换为32位(compat)，再copy to userup32_ioctl.id = kp_ioctl.id;up32_ioctl.len = kp_ioctl.len;up32_ioctl.trans_code = kp_ioctl.trans_code;up32_ioctl.ioctl_ptr = ptr_to_compat(kp_ioctl.ioctl_ptr);copy_to_user((void __user *)up, &up32_ioctl, sizeof(up32_ioctl));}
}

这里，将一个视频帧（frame）参数通过ioctl，返回给camera hal。
hal拿到帧参数后，将帧参数也填充到event_data中。最后,sundp-3.6返回，参数返回到event_data中。
接下来到了sundp-3.9

sundp-3.9 cpp_module_do_ack

vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/pproc-new/cpp/cpp_module.c

int32_t cpp_module_do_ack(cpp_module_ctrl_t *ctrl,  cpp_module_ack_key_t key, uint32_t buffer_access)
{......cpp_ack = cpp_module_find_ack_from_list(ctrl, key);cpp_ack->ref_count--;if(cpp_ack->ref_count == 0) {......cpp_module_send_buf_divert_ack(ctrl, cpp_ack->isp_buf_divert_ack);}
}static int32_t cpp_module_send_buf_divert_ack(cpp_module_ctrl_t *ctrl, isp_buf_divert_ack_t isp_ack)
{//创建eventmct_event_t event;  // sundp-3.10event.type = MCT_EVENT_MODULE_EVENT;event.direction = MCT_EVENT_UPSTREAM;event.identity = isp_ack.identity;//sundp-3.11event.u.module_event.type = MCT_EVENT_MODULE_BUF_DIVERT_ACK;event.u.module_event.module_event_data = &isp_ack;rc = cpp_module_send_event_upstream(ctrl->p_module, &event);return 0;
}

sundp-3.10 MCT_EVENT_MODULE_EVENT

接下来到了这儿：
vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/iface2/port_iface.c

static boolean port_iface_event_func(mct_port_t *mct_port, mct_event_t *event)
{switch (event->type) {case MCT_EVENT_CONTROL_CMD:/* MCT ctrl event */rc = port_iface_proc_mct_ctrl_cmd(mct_port, event);break;case MCT_EVENT_MODULE_EVENT: //对应了前面的event.type/* Event among modules */rc = port_iface_proc_module_event(mct_port, event);break;return rc;
}

vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/iface2/iface_util.c

int iface_util_divert_ack(iface_t *iface, iface_session_t *session,uint32_t user_stream_id, uint32_t buf_idx, uint32_t is_dirty, boolean bayerdata, uint32_t buffer_access)
{if (hw_stream->isp_split_output_info.is_split == TRUE && hw_stream->stream_info.cam_stream_type != CAM_STREAM_TYPE_OFFLINE_PROC) {/*if hw stream split, only enqueue once since its shared buf*/rc = iface_axi_divert_ack( iface->isp_axi_data.axi_data[VFE0].axi_hw_ops->ctrl,&axi_divert_ack, sizeof(axi_divert_ack));......
}

vendor/qcom/proprietary/mm-camera/mm-camera2/media-controller/modules/iface2/axi/iface_axi.c：

static boolean port_iface_proc_module_event(mct_port_t *mct_iface_port, mct_event_t *event)
{switch (mod_event->type) {//对应了前面的event.u.module_event.typecase MCT_EVENT_MODULE_BUF_DIVERT_ACK: {  isp_buf_divert_ack_t *buf_divert_ack = (isp_buf_divert_ack_t*) mod_event->module_event_data;ret = iface_util_divert_ack(iface, session, UNPACK_STREAM_ID(event->identity),buf_divert_ack->buf_idx, buf_divert_ack->is_buf_dirty,buf_divert_ack->bayerdata, buf_divert_ack->buffer_access);}break;
}

这里，iface_quque_buf，将视频buf加入队列，送去显示。

int iface_axi_divert_ack( iface_axi_hw_t *axi_hw, iface_axi_buf_divert_ack_t *ack, uint32_t data_size __unused)
{stream = iface_axi_util_find_stream(axi_hw, ack->session_id, ack->stream_id);buf_handle = iface_find_matched_bufq_handle(axi_hw->buf_mgr,stream->hw_stream_info.session_id, ack->stream_id);rc = iface_queue_buf(axi_hw->buf_mgr,buf_handle, ack->buf_idx, ack->is_buf_dirty, axi_hw->fd,ack->buffer_access);
}

---

4 dump image

这里说一下怎么dump图像：

static int32_t cpp_thread_handle_process_buf_event(cpp_module_ctrl_t* ctrl,cpp_module_event_t* cpp_event)
{......
#ifdef _ANDROID_if (session_params->cpp_debug_enable)//1  表示dump输入，有另外的函数dump输出cpp_thread_dump_frame(hw_params,hw_params->buffer_info.fd,&cmd,1);
#endif.......
}

可见有两个条件：

1.#ifdef ANDROID
2.session_params->cpp_debug_enable为ture

第一个条件好说，第二个赋值为ture的地方是：

property_get("persist.vendor.camera.pproc.debug.en", value, "0");
enabled = atoi(value);
if (enabled)ctrl->session_params[i]->cpp_debug_enable = TRUE;

所以需要setprop persist.vendor.camera.pproc.debug.en 1

cpp_thread_dump_frame函数实现：

参数：
cpp_hardware_params_t hw_params：
int fd：
void *user：
bool ip_op：1 dump Input ； 0 dump Output

int cpp_thread_dump_frame(cpp_hardware_params_t *hw_params, int fd,void *user,bool ip_op)
{......//1.检查是否开启dump//这里也需要设置一下property_get("persist.vendor.camera.pproc.framedump", value, "0");enabled = atoi(value);if (!enabled) {  CPPFrameCnt = 0;  return 0; }//2.设置需要dump的frame数，默认20property_get("persist.vendor.camera.pproc.dump_cnt", value, "20");count = atoi(value);//3.dump输入or输出if(ip_op) { /* Input */cookie = (cpp_module_hw_cookie_t *)hw_params->cookie;memcpy(&dim_info,&hw_params->input_info,sizeof(cpp_params_dim_info_t));strlcpy(io,"Input",sizeof(io));} else { /* Output */cookie = cmd->u.event_data->cookie;memcpy(&dim_info,&hw_params->output_info,sizeof(cpp_params_dim_info_t));strlcpy(io,"Output",sizeof(io));hw_params->frame_id = cmd->u.event_data->frame_id;}//根据stream_type组包（即dump 图像的的文件名）switch(hw_params->stream_type) {//以preview举例：case CAM_STREAM_TYPE_PREVIEW: {snprintf(name, sizeof(name), QCAMERA_DUMP_FRM_LOCATION"%s_CPP_%s_Preview_%dx%d_%d.yuv",timeBuf,io,width[0],height[0],hw_params->frame_id);break;}.......}//openfile_fd = open(name, O_RDWR | O_CREAT, 0777);//writewritten_len += write(file_fd, data, (size_t)(dim_info.plane_info[i].plane_len));......
}

---

struct

struct _cpp_module_ctrl_t

struct _cpp_module_ctrl_t {mct_module_t                *p_module;mct_module_t                *parent_module;mct_queue_t                 *realtime_queue;mct_queue_t                 *partial_frame_queue;mct_queue_t                 *offline_queue;cpp_module_ack_list_t       ack_list;pthread_t                   cpp_thread;pthread_cond_t              th_start_cond;boolean                     cpp_thread_started;pthread_mutex_t             cpp_mutex;int                         pfd[2];int32_t                     session_count;cpp_hardware_t              *cpphw;cpp_module_clk_rate_list_t  clk_rate_list;unsigned long               clk_rate;boolean                     runtime_clk_update;pp_native_buf_mgr_t         pp_buf_mgr;pp_native_buf_mgr_t         pp_tnr_buf_mgr;cpp_module_session_params_t *session_params[CPP_MODULE_MAX_SESSIONS];cpp_submodule_func_tbl_t    tnr_module_func_tbl;cpp_submodule_func_tbl_t    pbf_module_func_tbl;mct_port_t                  *port_map[CPP_MODULE_MAX_SESSIONS][CPP_MODULE_MAX_STREAMS][2];/* last updated clock and bandwidth */int64_t                     clk;int64_t                     bw;/* current state for a clock update */cpp_clock_state             clk_state;/* threshold count to trigger a clock bump down */int32_t                     clock_threshold;int32_t                     clock_dcvs;int32_t                     turbo_caps;volatile bool               is_hw_error;uint32_t                    rtb_status;uint32_t                    sat_status;uint32_t                    soc_id;
};

struct _cpp_hardware_t

struct _cpp_hardware_t {uint32_t                            subdev_ids[MAX_CPP_DEVICES];int                                 num_subdev;int                                 subdev_fd;boolean                             subdev_opened;uint32_t                            inst_id;cpp_hardware_caps_t                 caps;cpp_hardware_info_t                 hwinfo;cpp_hardware_status_t               status;cpp_firmware_version_t              fw_version;cpp_hardware_event_subscribe_info_t event_subs_info;cpp_hardware_stream_status_t        stream_status[CPP_HARDWARE_MAX_STREAMS];pthread_cond_t                      subdev_cond;pthread_mutex_t                     mutex;int                                 num_iommu_cnt;int                                 max_pending_buffer;uint32_t                            dump_preview_cnt;uint32_t                            dump_video_cnt;uint32_t                            dump_snapshot_cnt;int32_t                             max_supported_padding;void                                *private_data;uint32_t                            preview_frame_counter;uint32_t                            video_frame_counter;uint32_t                            offline_frame_counter;uint32_t                            snapshot_frame_counter;uint32_t                            postview_frame_counter;uint32_t                            analysis_frame_counter;
} ;

_cpp_thread_msg_t

typedef enum {CPP_THREAD_MSG_NEW_EVENT_IN_Q,CPP_THREAD_MSG_ABORT
} cpp_thread_msg_type_t;typedef struct _cpp_thread_msg_t {cpp_thread_msg_type_t type;void *data;
} cpp_thread_msg_t;

_cpp_hardware_cmd_t

typedef struct _cpp_hardware_cmd_t {cpp_hardware_cmd_type_t type;void                   *ctrl;void                   *return_payload;/* CPP_HW_CMD_PROCESS_FRAME - Partial frame, after the first payload is sent,the remainder is saved here and then split into more partial_framesin the thread */union {cpp_hardware_streamoff_event_t streamoff_data;cpp_hardware_event_data_t       *event_data;cpp_hardware_params_t           *hw_params;cpp_hardware_buff_update_t      *buff_update;struct msm_cpp_frame_info_t     *partial_frame;cpp_hardware_clock_settings_t   clock_settings;uint32_t                        buf_done_identity;uint32_t                        status;} u;
} cpp_hardware_cmd_t;

enum cpp_hardware_cmd_type_t

typedef enum {CPP_HW_CMD_GET_CAPABILITIES,CPP_HW_CMD_SUBSCRIBE_EVENT,CPP_HW_CMD_UNSUBSCRIBE_EVENT,CPP_HW_CMD_NOTIFY_EVENT,CPP_HW_CMD_STREAMON,CPP_HW_CMD_STREAMOFF,CPP_HW_CMD_LOAD_FIRMWARE,CPP_HW_CMD_PROCESS_FRAME,CPP_HW_CMD_QUEUE_BUF,CPP_HW_CMD_GET_CUR_DIAG,CPP_HW_CMD_SET_CLK,CPP_HW_CMD_POP_STREAM_BUFFER,CPP_HW_CMD_BUF_UPDATE,CPP_HW_CMD_PROCESS_PARTIAL_FRAME,CPP_HW_CMD_NOTIFY_BUF_DONE,CPP_HW_CMD_UPDATE_PENDING_BUF,
} cpp_hardware_cmd_type_t;

struct _cpp_module_session_params_t

/* session specific parameters */
typedef struct _cpp_module_session_params_t {cpp_module_stream_params_t   *stream_params[CPP_MODULE_MAX_STREAMS];int32_t                       stream_count;cpp_hardware_params_t         hw_params;uint32_t                      session_id;cam_hfr_mode_t                hfr_mode;cpp_params_aec_trigger_info_t aec_trigger;/* DIS enable flag to be used for frame hold */int32_t                       dis_enable;/* Latest frame id received from DIS crop event */cpp_module_dis_hold_t         dis_hold;/* Hold frame until DIS crop is received for this frame */cpp_module_frame_hold_t       frame_hold;ez_pp_params_t                diag_params;cam_hal_version_t             hal_version;cpp_per_frame_params_t        per_frame_params;boolean                       is_stream_on;uint32_t                      stream_on_count;cam_fps_range_t               fps_range;cam_stream_ID_t               valid_stream_ids[FRAME_CTRL_SIZE];cam_stream_ID_t               verify_proc_stream_ids[FRAME_CTRL_SIZE];pthread_mutex_t               dis_mutex;modulesChromatix_t            module_chromatix;chromatix_cpp_stripped_type   *def_chromatix_stripped;boolean                       runtime_clk_update;cam_dimension_t               camif_dim;uint32_t                      turbo_frame_count;int32_t                       clk_ref_threshold_idx;/* for Dual Cam: Primary or Secondary */bool                          is_slave;/* for Dual Cam: Main or Aux */cam_sync_type_t               cam_type;int32_t                       link_session_id;int32_t                       native_buf_ref;cam_dual_camera_perf_control_t dualcam_perf;cpp_module_session_set_parm   sticky_set_parm;cam_dual_camera_role_t        cam_role;bool                          force_slave_process;boolean                       cpp_debug_enable;
} cpp_module_session_params_t;
