Spring源码-ClassPathXmlApplicationContext的refresh()都做了什么?

AbstractApplicationContext的refresh方法

	/*** 用给定的父类创建一个新的ClassPathXmlApplicationContext* Create a new ClassPathXmlApplicationContext with the given parent,* 从给定的XML文件加载定义* loading the definitions from the given XML files.* @param configLocations 配置位置 array of resource locations 资源位置数组* @param refresh whether to automatically refresh the context,是否自动刷新上下文;* 加载所有bean定义并创建所有单例* loading all bean definitions and creating all singletons.* Alternatively, 另外 call refresh manually 手动 after further进一步 configuring the context.在进一步配置上下文之后，手动调用refresh* @param parent the parent context* @throws BeansException if context creation failed* @see #refresh()*/public ClassPathXmlApplicationContext(String[] configLocations, boolean refresh, @Nullable ApplicationContext parent)throws BeansException {// 调用父类构造方法，进行相关的对象创建等操作,包含属性的赋值操作super(parent);setConfigLocations(configLocations);if (refresh) {refresh();}}

接下来开始讲解这个方法内部的方法都做了什么？

prepareRefresh();

  	/**

		 * 前戏，做容器刷新前的准备工作* 1、设置容器的启动时间* 2、设置活跃状态为true* 3、设置关闭状态为false* 4、获取Environment对象，并加载当前系统的属性值到Environment对象中* 5、准备监听器和事件的集合对象，默认为空的集合*/

	/*** 准备此上下文以进行刷新，设置其启动日期和活动标志，以及* Prepare this context for refreshing, setting its startup date and* active flag as well as* 执行属性源的任何初始化。* performing any initialization of property sources.*/protected void prepareRefresh() {// Switch to active.// 设置容器启动的时间this.startupDate = System.currentTimeMillis();// 容器的关闭标志位this.closed.set(false);// 容器的激活标志位this.active.set(true);// 记录日志if (logger.isDebugEnabled()) {if (logger.isTraceEnabled()) {logger.trace("Refreshing " + this);}else {logger.debug("Refreshing " + getDisplayName());}}// Initialize any placeholder property sources in the context environment.// 留给子类覆盖，初始化属性资源initPropertySources();// Validate that all properties marked as required are resolvable:// see ConfigurablePropertyResolver#setRequiredProperties// 创建并获取环境对象，验证需要的属性文件是否都已经放入环境中getEnvironment().validateRequiredProperties();// Store pre-refresh ApplicationListeners...// 判断刷新前的应用程序监听器集合是否为空，如果为空，则将监听器添加到此集合中if (this.earlyApplicationListeners == null) {this.earlyApplicationListeners = new LinkedHashSet<>(this.applicationListeners);}else {// Reset local application listeners to pre-refresh state.// 如果不等于空，则清空集合元素对象this.applicationListeners.clear();this.applicationListeners.addAll(this.earlyApplicationListeners);}// 允许收集早期的ApplicationEvents，一旦组播器可用就发布…// Allow for the collection of early ApplicationEvents,// to be published once the multicaster is available...// 创建刷新前的监听事件集合this.earlyApplicationEvents = new LinkedHashSet<>();}

obtainFreshBeanFactory

// Tell the subclass to refresh the internal bean factory. 告诉子类刷新内部bean工厂。
// 创建容器对象：DefaultListableBeanFactory
// 加载xml配置文件的属性值到当前工厂中，最重要的就是BeanDefinition
ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory();

加载xml文件生成bean定义信息就是在这里的

	/*** 告诉子类刷新内部bean工厂。* Tell the subclass to refresh the internal bean factory.* @return the fresh BeanFactory instance  新的BeanFactory实例* @see #refreshBeanFactory()* @see #getBeanFactory()*/protected ConfigurableListableBeanFactory obtainFreshBeanFactory() {// 初始化BeanFactory,并进行XML文件读取，并将得到的BeanFactory记录在当前实体的属性中refreshBeanFactory();// 返回当前实体的beanFactory属性return getBeanFactory();}

prepareBeanFactory(beanFactory)

  	// Prepare the bean factory for use in this context.

		// beanFactory的准备工作，对各种属性进行填充 prepareBeanFactory(beanFactory)

/*** 配置工厂的标准上下文特征* Configure the factory's standard context characteristics,* 比如上下文的ClassLoader和后置处理器。* such as the context's ClassLoader and post-processors.* @param beanFactory the BeanFactory to configure 要配置的BeanFactory*/protected void prepareBeanFactory(ConfigurableListableBeanFactory beanFactory) {//  告诉内部bean工厂使用上下文的类装入器等// Tell the internal bean factory to use the context's class loader etc.// 设置beanFactory的classloader为当前context的classloaderbeanFactory.setBeanClassLoader(getClassLoader());// 设置beanfactory的表达式语言处理器 处理解析#{}类似这样的占位符beanFactory.setBeanExpressionResolver(new StandardBeanExpressionResolver(beanFactory.getBeanClassLoader()));// 为beanFactory增加一个默认的propertyEditor，这个主要是对bean的属性等设置管理的一个工具类 实体类的参数解析工具类放在spring 后续可以按需使用的beanFactory.addPropertyEditorRegistrar(new ResourceEditorRegistrar(this, getEnvironment()));// Configure the bean factory with context callbacks.// 添加beanPostProcessor,ApplicationContextAwareProcessor此类用来完成某些Aware对象的注入beanFactory.addBeanPostProcessor(new ApplicationContextAwareProcessor(this));// 设置要忽略自动装配的接口，很多同学理解不了为什么此处要对这些接口进行忽略，原因非常简单，这些接口的实现是由容器通过set方法进行注入的，// 所以在使用autowire进行注入的时候需要将这些接口进行忽略beanFactory.ignoreDependencyInterface(EnvironmentAware.class);beanFactory.ignoreDependencyInterface(EmbeddedValueResolverAware.class);beanFactory.ignoreDependencyInterface(ResourceLoaderAware.class);beanFactory.ignoreDependencyInterface(ApplicationEventPublisherAware.class);beanFactory.ignoreDependencyInterface(MessageSourceAware.class);beanFactory.ignoreDependencyInterface(ApplicationContextAware.class);// BeanFactory interface not registered as resolvable type in a plain factory.  BeanFactory接口未在普通工厂中注册为可解析类型。// MessageSource registered (and found for autowiring) as a bean.   MessageSource作为bean注册(并自动查找)。// 设置几个自动装配的特殊规则,当在进行ioc初始化的如果有多个实现，那么就使用指定的对象进行注入beanFactory.registerResolvableDependency(BeanFactory.class, beanFactory);beanFactory.registerResolvableDependency(ResourceLoader.class, this);beanFactory.registerResolvableDependency(ApplicationEventPublisher.class, this);beanFactory.registerResolvableDependency(ApplicationContext.class, this);//寄存器可解析依赖// Register early post-processor for detecting inner beans as ApplicationListeners.// 注册BPPbeanFactory.addBeanPostProcessor(new ApplicationListenerDetector(this));// 应用程序侦听器检测器// Detect a LoadTimeWeaver and prepare for weaving, if found.// 增加对AspectJ的支持，在java中织入分为三种方式，分为编译器织入，类加载器织入，运行期织入，编译器织入是指在java编译器，采用特殊的编译器，将切面织入到java类中，// 而类加载期织入则指通过特殊的类加载器，在类字节码加载到JVM时，织入切面，运行期织入则是采用cglib和jdk进行切面的织入// aspectj提供了两种织入方式，第一种是通过特殊编译器，在编译器，将aspectj语言编写的切面类织入到java类中，第二种是类加载期织入，就是下面的load time weaving，此处后续讲if (beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) {beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory));// Set a temporary ClassLoader for type matching.beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader()));}// Register default environment beans.// 注册默认的系统环境bean到一级缓存中if (!beanFactory.containsLocalBean(ENVIRONMENT_BEAN_NAME)) {beanFactory.registerSingleton(ENVIRONMENT_BEAN_NAME, getEnvironment());}if (!beanFactory.containsLocalBean(SYSTEM_PROPERTIES_BEAN_NAME)) {beanFactory.registerSingleton(SYSTEM_PROPERTIES_BEAN_NAME, getEnvironment().getSystemProperties());}if (!beanFactory.containsLocalBean(SYSTEM_ENVIRONMENT_BEAN_NAME)) {beanFactory.registerSingleton(SYSTEM_ENVIRONMENT_BEAN_NAME, getEnvironment().getSystemEnvironment());}}

postProcessBeanFactory(beanFactory);

  		// 子类覆盖方法做额外的处理，此处我们自己一般不做任何扩展工作，但是可以查看web中的代码，是有具体实现的

			postProcessBeanFactory(beanFactory);

	/*** 在标准初始化之后修改应用程序上下文的内部bean工厂。所有的bean定义都已加载，但还没有实例化任何bean。这允许注册特殊* Modify the application context's internal bean factory after its standard* initialization. All bean definitions will have been loaded, but no beans* will have been instantiated yet. This allows for registering special* BeanPostProcessors etc in certain ApplicationContext implementations.* 在标准初始化之后修改应用程序上下文的内部bean工厂。所有的bean定义都已加载，但还没有实例化任何bean。* 这允许在特定的ApplicationContext实现中注册特殊的BeanPostProcessors等。* @param beanFactory the bean factory used by the application context*/protected void postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory) {}

invokeBeanFactoryPostProcessors

  		// Invoke factory processors registered as beans in the context.

			// 调用各种beanFactory处理器invokeBeanFactoryPostProcessors(beanFactory);

	/*** 实例化并且调用所有已经注册了的beanFactoryPostProcessor,遵循指明的顺序** Instantiate and invoke all registered BeanFactoryPostProcessor beans,* respecting explicit order if given.* 必须在单例实例化之前调用* <p>Must be called before singleton instantiation.*/protected void invokeBeanFactoryPostProcessors(ConfigurableListableBeanFactory beanFactory) {// 获取到当前应用程序上下文的beanFactoryPostProcessors变量的值，并且实例化调用执行所有已经注册的beanFactoryPostProcessor// 默认情况下，通过getBeanFactoryPostProcessors()来获取已经注册的BFPP，但是默认是空的，那么问题来了，如果你想扩展，怎么进行扩展工作？// MyClassPathXmlApplicationContext 继承 ClassPathXmlApplicationContext 重写 customizeBeanFactory方法 super.addBeanFactoryPostProcessor(new MyBeanFactoryPostProcessor());PostProcessorRegistrationDelegate.invokeBeanFactoryPostProcessors(beanFactory, getBeanFactoryPostProcessors());// Detect a LoadTimeWeaver and prepare for weaving, if found in the meantime// (e.g. through an @Bean method registered by ConfigurationClassPostProcessor)if (beanFactory.getTempClassLoader() == null && beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) {beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory));beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader()));}}

registerBeanPostProcessors

  		// Register bean processors that intercept bean creation.

			// 注册bean处理器，这里只是注册功能，真正调用的是getBean方法registerBeanPostProcessors(beanFactory);

	/*** 实例化并且注册所有的beanPostProcessor** Instantiate and register all BeanPostProcessor beans,* respecting explicit order if given.* <p>Must be called before any instantiation of application beans.*/protected void registerBeanPostProcessors(ConfigurableListableBeanFactory beanFactory) {PostProcessorRegistrationDelegate.registerBeanPostProcessors(beanFactory, this);}

initMessageSource

  		// Initialize message source for this context.

			// 为上下文初始化message源，即不同语言的消息体，国际化处理,在springmvc的时候通过国际化的代码重点讲initMessageSource();

	/*** Initialize the MessageSource.* Use parent's if none defined in this context.*/protected void initMessageSource() {// 获取bean工厂，一般是DefaultListableBeanFactoryConfigurableListableBeanFactory beanFactory = getBeanFactory();// 首先判断是否已有xml文件定义了id为messageSource的bean对象if (beanFactory.containsLocalBean(MESSAGE_SOURCE_BEAN_NAME)) {// 如果有，则从BeanFactory中获取这个对象this.messageSource = beanFactory.getBean(MESSAGE_SOURCE_BEAN_NAME, MessageSource.class);// Make MessageSource aware of parent MessageSource.// 当父类bean工厂不为空，并且这个bean对象是HierarchicalMessageSource类型if (this.parent != null && this.messageSource instanceof HierarchicalMessageSource) {// 类型强制转换，转换为HierarchicalMessageSource的类型HierarchicalMessageSource hms = (HierarchicalMessageSource) this.messageSource;// 判断父类的messageSource是否为空，如果等于空，则设置父类的messageSourceif (hms.getParentMessageSource() == null) {// Only set parent context as parent MessageSource if no parent MessageSource// registered already.hms.setParentMessageSource(getInternalParentMessageSource());}}if (logger.isTraceEnabled()) {logger.trace("Using MessageSource [" + this.messageSource + "]");}}else {// Use empty MessageSource to be able to accept getMessage calls.// 如果没有xml文件定义信息源对象，新建DelegatingMessageSource类作为messageSource的beanDelegatingMessageSource dms = new DelegatingMessageSource();// 给这个DelegatingMessageSource添加父类消息源dms.setParentMessageSource(getInternalParentMessageSource());this.messageSource = dms;// 将这个messageSource实例注册到bean工厂中beanFactory.registerSingleton(MESSAGE_SOURCE_BEAN_NAME, this.messageSource);if (logger.isTraceEnabled()) {logger.trace("No '" + MESSAGE_SOURCE_BEAN_NAME + "' bean, using [" + this.messageSource + "]");}}}

initApplicationEventMulticaster

  			// Initialize event multicaster for this context.

			// 初始化事件监听多路广播器initApplicationEventMulticaster();

	/*** Initialize the ApplicationEventMulticaster.* Uses SimpleApplicationEventMulticaster if none defined in the context.* @see org.springframework.context.event.SimpleApplicationEventMulticaster*/protected void initApplicationEventMulticaster() {// 获取当前bean工厂,一般是DefaultListableBeanFactoryConfigurableListableBeanFactory beanFactory = getBeanFactory();// 判断容器中是否存在bdName为applicationEventMulticaster的bd，也就是说自定义的事件监听多路广播器，必须实现ApplicationEventMulticaster接口if (beanFactory.containsLocalBean(APPLICATION_EVENT_MULTICASTER_BEAN_NAME)) {// 如果有，则从bean工厂得到这个bean对象this.applicationEventMulticaster =beanFactory.getBean(APPLICATION_EVENT_MULTICASTER_BEAN_NAME, ApplicationEventMulticaster.class);if (logger.isTraceEnabled()) {logger.trace("Using ApplicationEventMulticaster [" + this.applicationEventMulticaster + "]");}}else {// 如果没有，则默认采用SimpleApplicationEventMulticasterthis.applicationEventMulticaster = new SimpleApplicationEventMulticaster(beanFactory);beanFactory.registerSingleton(APPLICATION_EVENT_MULTICASTER_BEAN_NAME, this.applicationEventMulticaster);if (logger.isTraceEnabled()) {logger.trace("No '" + APPLICATION_EVENT_MULTICASTER_BEAN_NAME + "' bean, using " +"[" + this.applicationEventMulticaster.getClass().getSimpleName() + "]");}}}

onRefresh

  		// Initialize other special beans in specific context subclasses.

			// 留给子类来初始化其他的beanonRefresh();

/*** 此方式是模板方法，没有添加任何实现，在springmvc中会有对应的实现** Template method which can be overridden to add context-specific refresh work.* Called on initialization of special beans, before instantiation of singletons.* <p>This implementation is empty.* @throws BeansException in case of errors* @see #refresh()*/protected void onRefresh() throws BeansException {// For subclasses: do nothing by default.}

registerListeners

  		// Check for listener beans and register them.

			// 在所有注册的bean中查找listener bean,注册到消息广播器中registerListeners();

	/*** 注册监听器** Add beans that implement ApplicationListener as listeners.* Doesn't affect other listeners, which can be added without being beans.*/protected void registerListeners() {// Register statically specified listeners first.// 遍历应用程序中存在的监听器集合，并将对应的监听器添加到监听器的多路广播器中for (ApplicationListener<?> listener : getApplicationListeners()) {getApplicationEventMulticaster().addApplicationListener(listener);}// Do not initialize FactoryBeans here: We need to leave all regular beans// uninitialized to let post-processors apply to them!// 从容器中获取所有实现了ApplicationListener接口的bd的bdName// 放入ApplicationListenerBeans集合中String[] listenerBeanNames = getBeanNamesForType(ApplicationListener.class, true, false);for (String listenerBeanName : listenerBeanNames) {getApplicationEventMulticaster().addApplicationListenerBean(listenerBeanName);
//			getApplicationEventMulticaster().addApplicationListener(this.getBean(listenerBeanName,ApplicationListener.class));}// Publish early application events now that we finally have a multicaster...// 此处先发布早期的监听器集合Set<ApplicationEvent> earlyEventsToProcess = this.earlyApplicationEvents;this.earlyApplicationEvents = null;if (!CollectionUtils.isEmpty(earlyEventsToProcess)) {for (ApplicationEvent earlyEvent : earlyEventsToProcess) {getApplicationEventMulticaster().multicastEvent(earlyEvent);}}}

finishBeanFactoryInitialization

  		// Instantiate all remaining (non-lazy-init) singletons.

			// 初始化剩下的单实例（非懒加载的）finishBeanFactoryInitialization(beanFactory);

/*** Finish the initialization of this context's bean factory,* initializing all remaining singleton beans.*/protected void finishBeanFactoryInitialization(ConfigurableListableBeanFactory beanFactory) {// Initialize conversion service for this context.// 为上下文初始化类型转换器if (beanFactory.containsBean(CONVERSION_SERVICE_BEAN_NAME) &&beanFactory.isTypeMatch(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class)) {beanFactory.setConversionService(//后续在创建实例对象 set转换服务调getConversionServicebeanFactory.getBean(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class));}// Register a default embedded value resolver if no bean post-processor// (such as a PropertyPlaceholderConfigurer bean) registered any before:// at this point, primarily for resolution in annotation attribute values.// 如果beanFactory之前没有注册嵌入值解析器，则注册默认的嵌入值解析器，主要用于注解属性值的解析if (!beanFactory.hasEmbeddedValueResolver()) {beanFactory.addEmbeddedValueResolver(strVal -> getEnvironment().resolvePlaceholders(strVal));}// Initialize LoadTimeWeaverAware beans early to allow for registering their transformers early.// 尽早初始化loadTimeWeaverAware bean,以便尽早注册它们的转换器String[] weaverAwareNames = beanFactory.getBeanNamesForType(LoadTimeWeaverAware.class, false, false);for (String weaverAwareName : weaverAwareNames) {getBean(weaverAwareName);}// Stop using the temporary ClassLoader for type matching.// 禁止使用临时类加载器进行类型匹配beanFactory.setTempClassLoader(null);// Allow for caching all bean definition metadata, not expecting further changes.// 冻结所有的bean定义，说明注册的bean定义将不被修改或任何进一步的处理beanFactory.freezeConfiguration();// Instantiate all remaining (non-lazy-init) singletons.// 实例化剩下的单例对象beanFactory.preInstantiateSingletons();}

finishRefresh

  		// Last step: publish corresponding event.

			// 完成刷新过程，通知生命周期处理器lifecycleProcessor刷新过程，同时发出ContextRefreshEvent通知别人finishRefresh();

	/*** 完成刷新* Finish the refresh of this context, invoking the LifecycleProcessor's* onRefresh() method and publishing the* {@link org.springframework.context.event.ContextRefreshedEvent}.*/protected void finishRefresh() {// Clear context-level resource caches (such as ASM metadata from scanning).// 清除上下文级别的资源缓存(如扫描的ASM元数据)// 清空在资源加载器中的所有资源缓存clearResourceCaches();// Initialize lifecycle processor for this context.// 为这个上下文初始化生命周期处理器// 初始化LifecycleProcessor.如果上下文中找到'lifecycleProcessor'的LifecycleProcessor Bean对象，// 则使用DefaultLifecycleProcessorinitLifecycleProcessor();// Propagate refresh to lifecycle processor first.// 首先将刷新传播到生命周期处理器// 上下文刷新的通知，例如自动启动的组件getLifecycleProcessor().onRefresh();// Publish the final event.// 发布最终事件// 新建ContextRefreshedEvent事件对象，将其发布到所有监听器。publishEvent(new ContextRefreshedEvent(this));// Participate in LiveBeansView MBean, if active.// 参与LiveBeansView MBean，如果是活动的// LiveBeansView:Sping用于支持JMX 服务的类// 注册当前上下文到LiveBeansView，以支持JMX服务LiveBeansView.registerApplicationContext(this);}
