Kubernetes 企业级高可用部署
目录
1、Kubernetes高可用项目介绍
2、项目架构设计
2.1、项目主机信息
2.2、项目架构图
2.3、项目实施思路
3、项目实施过程
3.1、系统初始化
3.2、配置部署keepalived服务
3.3、配置部署haproxy服务
3.4、配置部署Docker服务
3.5、部署kubelet kubeadm kubectl工具
3.6、部署Kubernetes Master
3.7、安装集群网络
3.8、添加master节点
3.9、加入Kubernetes Node
3.10、测试Kubernetes集群
1、Kubernetes高可用项目介绍
单master节点的可靠性不高，并不适合实际的生产环境。Kubernetes 高可用集群是保证 Master 节点中 API Server 服务的高可用。API Server 提供了 Kubernetes 各类资源对象增删改查的唯一访问入口，是整个 Kubernetes 系统的数据总线和数据中心。采用负载均衡（Load Balance）连接多个 Master 节点可以提供稳定容器云业务。
2、项目架构设计
2.1、项目主机信息
准备6台虚拟机，3台master节点，3台node节点，保证master节点数为>=3的奇数。
硬件：2核CPU+、2G内存+、硬盘20G+
网络：所有机器网络互通、可以访问外网
| 操作系统 | IP地址 | 角色 | 主机名 |
| CentOS7-x86-64 | 192.168.2.111 | master | k8s-master1 |
| CentOS7-x86-64 | 192.168.2.112 | master | k8s-master2 |
| CentOS7-x86-64 | 192.168.2.115 | master | k8s-master3 |
| CentOS7-x86-64 | 192.168.2.116 | node | k8s-node1 |
| CentOS7-x86-64 | 192.168.2.117 | node | k8s-node2 |
| CentOS7-x86-64 | 192.168.2.118 | node | k8s-node3 |
| 192.168.2.154 | VIP | master.k8s.io |
2.2、项目架构图
多master节点负载均衡的kubernetes集群。官网给出了两种拓扑结构：堆叠control plane node和external etcd node，本文基于第一种拓扑结构进行搭建。
（堆叠control plane node）
（external etcd node）
2.3、项目实施思路
master节点需要部署etcd、apiserver、controller-manager、scheduler这4种服务，其中etcd、controller-manager、scheduler这三种服务kubernetes自身已经实现了高可用，在多master节点的情况下，每个master节点都会启动这三种服务，同一时间只有一个生效。因此要实现kubernetes的高可用，只需要apiserver服务高可用。
keepalived是一种高性能的服务器高可用或热备解决方案，可以用来防止服务器单点故障导致服务中断的问题。keepalived使用主备模式，至少需要两台服务器才能正常工作。比如keepalived将三台服务器搭建成一个集群，对外提供一个唯一IP，正常情况下只有一台服务器上可以看到这个IP的虚拟网卡。如果这台服务异常，那么keepalived会立即将IP移动到剩下的两台服务器中的一台上，使得IP可以正常使用。
haproxy是一款提供高可用性、负载均衡以及基于TCP（第四层）和HTTP（第七层）应用的代理软件，支持虚拟主机，它是免费、快速并且可靠的一种解决方案。使用haproxy负载均衡后端的apiserver服务，达到apiserver服务高可用的目的。
本文使用的keepalived+haproxy方案，使用keepalived对外提供稳定的入口，使用haproxy对内均衡负载。因为haproxy运行在master节点上，当master节点异常后，haproxy服务也会停止，为了避免这种情况，我们在每一台master节点都部署haproxy服务，达到haproxy服务高可用的目的。由于多master节点会出现投票竞选的问题，因此master节点的数据最好是单数，避免票数相同的情况。
3、项目实施过程
3.1、系统初始化
修改主机名（根据主机角色不同，做相应修改）所有机器
[root@localhost ~]# hostname k8s-master1
[root@localhost ~]# bash
关闭防火墙（所有机器）
[root@k8s-master1 ~]# systemctl stop firewalld
[root@k8s-master1 ~]# systemctl disable firewalld
关闭selinux（所有机器）
[root@k8s-master1 ~]# sed -i 's/enforcing/disabled/' /etc/selinux/config
[root@k8s-master1 ~]# setenforce 0
关闭swap（所有机器）
[root@k8s-master1 ~]# swapoff -a
[root@k8s-master1 ~]# sed -ri 's/.*swap.*/#&/' /etc/fstab
主机名映射（所有机器）
[root@k8s-master1 ~]# cat >> /etc/hosts << EOF
192.168.2.111 master1.k8s.io k8s-master1
192.168.2.112 master2.k8s.io k8s-master2
192.168.2.115 master3.k8s.io k8s-master3
192.168.2.116 node1.k8s.io k8s-node1
192.168.2.117 node2.k8s.io k8s-node2
192.168.2.118 node3.k8s.io k8s-node3
192.168.2.154 master.k8s.io k8s-vip
EOF将桥接的IPv4流量传递到iptables的链（所有机器）
[root@k8s-master1 ~]# cat << EOF >> /etc/sysctl.conf
> net.bridge.bridge-nf-call-ip6tables = 1
> net.bridge.bridge-nf-call-iptables = 1
> EOF[root@k8s-master1 ~]# modprobe br_netfilter[root@k8s-master1 ~]# sysctl -p
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
时间同步（所有机器）
[root@k8s-master1 ~]# yum install ntpdate -y
[root@k8s-master1 ~]# ntpdate time.windows.com3.2、配置部署keepalived服务
安装Keepalived（所有master主机）
[root@k8s-master1 ~]# yum install -y keepalivedk8s-master1节点配置
[root@k8s-master1 ~]# cat > /etc/keepalived/keepalived.conf <<EOF
! Configuration File for keepalived
global_defs {router_id k8s
}
vrrp_script check_haproxy {script "killall -0 haproxy"interval 3weight -2fall 10rise 2
}
vrrp_instance VI_1 {state BACKUPinterface ens33virtual_router_id 51priority 80advert_int 1authentication {auth_type PASSauth_pass 1111}
virtual_ipaddress {192.168.2.154
}
track_script {check_haproxy
}
}
EOFk8s-master2节点配置
[root@k8s-master2 ~]# cat > /etc/keepalived/keepalived.conf <<EOF
! Configuration File for keepalived
global_defs {router_id k8s
}
vrrp_script check_haproxy {script "killall -0 haproxy"interval 3weight -2fall 10rise 2
}
vrrp_instance VI_1 {state BACKUPinterface ens33virtual_router_id 51priority 90advert_int 1authentication {auth_type PASSauth_pass 1111}
virtual_ipaddress {192.168.2.154
}
track_script {check_haproxy
}
}
EOFk8s-master3节点配置
[root@k8s-master3 ~]# cat > /etc/keepalived/keepalived.conf <<EOF
! Configuration File for keepalived
global_defs {router_id k8s
}
vrrp_script check_haproxy {script "killall -0 haproxy"interval 3weight -2fall 10rise 2
}
vrrp_instance VI_1 {state BACKUPinterface ens33virtual_router_id 51priority 80advert_int 1authentication {auth_type PASSauth_pass 1111}
virtual_ipaddress {192.168.2.154
}
track_script {check_haproxy
}
}
EOF启动和检查
所有master节点都要执行
[root@k8s-master1 ~]# systemctl start keepalived[root@k8s-master1 ~]# systemctl enable keepalivedCreated symlink from /etc/systemd/system/multi-user.target.wants/keepalived.service to /usr/lib/systemd/system/keepalived.service.
查看启动状态
[root@k8s-master1 ~]# systemctl status keepalived● keepalived.service - LVS and VRRP High Availability MonitorLoaded: loaded (/usr/lib/systemd/system/keepalived.service; enabled; vendor preset: disabled)Active: active (running) since 二 2023-08-15 14:17:36 CST; 58s agoMain PID: 8425 (keepalived)CGroup: /system.slice/keepalived.service├─8425 /usr/sbin/keepalived -D├─8426 /usr/sbin/keepalived -D└─8427 /usr/sbin/keepalived -D8月 15 14:17:38 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:38 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:38 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:38 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: VRRP_Instance(VI_1) Sending/queueing g...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
8月 15 14:17:43 k8s-master1 Keepalived_vrrp[8427]: Sending gratuitous ARP on ens33 for 19...54
Hint: Some lines were ellipsized, use -l to show in full.
启动完成后在master1查看网络信息
[root@k8s-master1 ~]# ip a s ens332: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000link/ether 00:0c:29:14:f4:48 brd ff:ff:ff:ff:ff:ffinet 192.168.2.111/24 brd 192.168.2.255 scope global noprefixroute ens33valid_lft forever preferred_lft foreverinet 192.168.2.154/32 scope global ens33valid_lft forever preferred_lft foreverinet6 fe80::eeab:8168:d2bb:9c/64 scope link noprefixroute valid_lft forever preferred_lft forever
3.3、配置部署haproxy服务
所有master主机安装haproxy
[root@k8s-master1 ~]# yum install -y haproxy每台master节点中的配置均相同，配置中声明了后端代理的每个master节点服务器，指定了haproxy的端口为16443，因此16443端口为集群的入口。
[root@k8s-master1 ~]# cat > /etc/haproxy/haproxy.cfg << EOF#-------------------------------
# Global settings
#-------------------------------
globallog 127.0.0.1 local2chroot /var/lib/haproxypidfile /var/run/haproxy.pidmaxconn 4000user haproxygroup haproxydaemonstats socket /var/lib/haproxy/stats
#--------------------------------
# common defaults that all the 'listen' and 'backend' sections will
# usr if not designated in their block
#--------------------------------
defaultsmode httplog globaloption httplogoption dontlognulloption http-server-closeoption forwardfor except 127.0.0.0/8option redispatchretries 3timeout http-request 10stimeout queue 1m timeout connect 10stimeout client 1mtimeout server 1mtimeout http-keep-alive 10stimeout check 10smaxconn 3000
#--------------------------------
# kubernetes apiserver frontend which proxys to the backends
#--------------------------------
frontend kubernetes-apiservermode tcpbind *:16443option tcplogdefault_backend kubernetes-apiserver
#---------------------------------
#round robin balancing between the various backends
#---------------------------------
backend kubernetes-apiservermode tcpbalance roundrobinserver master1.k8s.io 192.168.2.111:6443 checkserver master2.k8s.io 192.168.2.112:6443 checkserver master3.k8s.io 192.168.2.115:6443 check
#---------------------------------
# collection haproxy statistics message
#---------------------------------
listen statsbind *:1080stats auth admin:awesomePasswordstats refresh 5sstats realm HAProxy\ Statisticsstats uri /admin?stats
EOF启动和检查
所有master节点都要执行
[root@k8s-master1 ~]# systemctl start haproxy[root@k8s-master1 ~]# systemctl enable haproxyCreated symlink from /etc/systemd/system/multi-user.target.wants/haproxy.service to /usr/lib/systemd/system/haproxy.service.
查看启动状态
[root@k8s-master1 ~]# systemctl status haproxy● haproxy.service - HAProxy Load BalancerLoaded: loaded (/usr/lib/systemd/system/haproxy.service; enabled; vendor preset: disabled)Active: active (running) since 二 2023-08-15 14:25:01 CST; 40s agoMain PID: 8522 (haproxy-systemd)CGroup: /system.slice/haproxy.service├─8522 /usr/sbin/haproxy-systemd-wrapper -f /etc/haproxy/haproxy.cfg -p /run/haproxy.pid├─8523 /usr/sbin/haproxy -f /etc/haproxy/haproxy.cfg -p /run/haproxy.pid -Ds└─8524 /usr/sbin/haproxy -f /etc/haproxy/haproxy.cfg -p /run/haproxy.pid -Ds8月 15 14:25:01 k8s-master1 systemd[1]: Started HAProxy Load Balancer.
8月 15 14:25:01 k8s-master1 haproxy-systemd-wrapper[8522]: haproxy-systemd-wrapper: executing /usr/s...Ds
8月 15 14:25:01 k8s-master1 haproxy-systemd-wrapper[8522]: [WARNING] 226/142501 (8523) : config : 'o...e.
8月 15 14:25:01 k8s-master1 haproxy-systemd-wrapper[8522]: [WARNING] 226/142501 (8523) : config : 'o...e.
Hint: Some lines were ellipsized, use -l to show in full.
检查端口
[root@k8s-master1 ~]# netstat -lntup|grep haproxy
tcp 0 0 0.0.0.0:1080 0.0.0.0:* LISTEN 8524/haproxy
tcp 0 0 0.0.0.0:16443 0.0.0.0:* LISTEN 8524/haproxy
udp 0 0 0.0.0.0:35139 0.0.0.0:* 8523/haproxy
3.4、配置部署Docker服务
所有主机上分别部署 Docker 环境，因为 Kubernetes 对容器的编排需要 Docker 的支持。
[root@k8s-master1 ~]# wget -O /etc/yum.repos.d/CentOS-Base.repo http://mirrors.aliyun.com/repo/Centos-7.repo[root@k8s-master1 ~]# yum install -y yum-utils device-mapper-persistent-data lvm2使用 YUM 方式安装 Docker 时，推荐使用阿里的 YUM 源。
[root@k8s-master1 ~]# yum-config-manager --add-repo https://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo
[root@k8s-master1 ~]# yum clean all && yum makecache fast [root@k8s-master1 ~]# yum -y install docker-ce
[root@k8s-master1 ~]# systemctl start docker
[root@k8s-master1 ~]# systemctl enable docker镜像加速器（所有主机配置）
[root@k8s-master1 ~]# cat << END > /etc/docker/daemon.json
> {
> "registry-mirrors":[ "https://nyakyfun.mirror.aliyuncs.com" ]
> }
> END[root@k8s-master1 ~]# systemctl daemon-reload
[root@k8s-master1 ~]# systemctl restart docker
3.5、部署kubelet kubeadm kubectl工具
使用 YUM 方式安装Kubernetes时，推荐使用阿里的yum。
所有主机配置
[root@k8s-master1 ~]# cat <<EOF > /etc/yum.repos.d/kubernetes.repo
> [kubernetes]
> name=Kubernetes
> baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64/
> enabled=1
> gpgcheck=1
> repo_gpgcheck=1
> gpgkey=https://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg
> https://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
> EOF[root@k8s-master1 ~]# ls /etc/yum.repos.d/
CentOS-Base.repo docker-ce.repo kubernetes.repo test
安装kubelet kubeadm kubectl
所有主机配置
[root@k8s-master1 ~]# yum install -y kubelet-1.20.0 kubeadm-1.20.0 kubectl-1.20.0
[root@k8s-master1 ~]# systemctl enable kubelet3.6、部署Kubernetes Master
在具有vip的master上操作。此处的vip节点为k8s-master1。
创建kubeadm-config.yaml文件
[root@k8s-master1 ~]# cat > kubeadm-config.yaml << EOF
apiServer:certSANs:- k8s-master1- k8s-master2- k8s-master3- master.k8s.io- 192.168.2.111- 192.168.2.112- 192.168.2.115- 192.168.2.154- 127.0.0.1extraArgs:authorization-mode: Node,RBACtimeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta1
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controlPlaneEndpoint: "master.k8s.io:6443"
controllerManager: {}
dns:type: CoreDNS
etcd:local:dataDir: /var/lib/etcd
imageRepository: registry.aliyuncs.com/google_containers
kind: ClusterConfiguration
kubernetesVersion: v1.20.0
networking:dnsDomain: cluster.localpodSubnet: 10.244.0.0/16serviceSubnet: 10.1.0.0/16
scheduler: {}
EOF
查看所需镜像信息
[root@k8s-master1 ~]# kubeadm config images list --config kubeadm-config.yamlW0815 15:10:40.624162 16024 common.go:77] your configuration file uses a deprecated API spec: "kubeadm.k8s.io/v1beta1". Please use 'kubeadm config migrate --old-config old.yaml --new-config new.yaml', which will write the new, similar spec using a newer API version.
registry.aliyuncs.com/google_containers/kube-apiserver:v1.20.0
registry.aliyuncs.com/google_containers/kube-controller-manager:v1.20.0
registry.aliyuncs.com/google_containers/kube-scheduler:v1.20.0
registry.aliyuncs.com/google_containers/kube-proxy:v1.20.0
registry.aliyuncs.com/google_containers/pause:3.2
registry.aliyuncs.com/google_containers/etcd:3.4.13-0
registry.aliyuncs.com/google_containers/coredns:1.7.0
上传k8s所需的镜像并导入（所有master主机）
所需镜像提取链接：https://pan.baidu.com/s/1Y9WJfINsE-sdkhLuo96llA?pwd=99w6
提取码：99w6
[root@k8s-master1 ~]# mkdir master
[root@k8s-master1 ~]# cd master/
[root@k8s-master1 master]# rz -E
rz waiting to receive.[root@k8s-master1 master]# ls coredns_1.7.0.tar kube-apiserver_v1.20.0.tar kube-proxy_v1.20.0.tar pause_3.2.tar
etcd_3.4.13-0.tar kube-controller-manager_v1.20.0.tar kube-scheduler_v1.20.0.tar[root@k8s-master1 master]# ls | while read line
> do
> docker load < $line
> done
225df95e717c: Loading layer 336.4kB/336.4kB
96d17b0b58a7: Loading layer 45.02MB/45.02MB
Loaded image: registry.aliyuncs.com/google_containers/coredns:1.7.0
d72a74c56330: Loading layer 3.031MB/3.031MB
d61c79b29299: Loading layer 2.13MB/2.13MB
1a4e46412eb0: Loading layer 225.3MB/225.3MB
bfa5849f3d09: Loading layer 2.19MB/2.19MB
bb63b9467928: Loading layer 21.98MB/21.98MB
Loaded image: registry.aliyuncs.com/google_containers/etcd:3.4.13-0
e7ee84ae4d13: Loading layer 3.041MB/3.041MB
597f1090d8e9: Loading layer 1.734MB/1.734MB
52d5280a7533: Loading layer 118.1MB/118.1MB
Loaded image: registry.aliyuncs.com/google_containers/kube-apiserver:v1.20.0
201617abe922: Loading layer 112.3MB/112.3MB
Loaded image: registry.aliyuncs.com/google_containers/kube-controller-manager:v1.20.0
f00bc8568f7b: Loading layer 53.89MB/53.89MB
6ee930b14c6f: Loading layer 22.05MB/22.05MB
2b046f2c8708: Loading layer 4.894MB/4.894MB
f6be8a0f65af: Loading layer 4.608kB/4.608kB
3a90582021f9: Loading layer 8.192kB/8.192kB
94812b0f02ce: Loading layer 8.704kB/8.704kB
3a478f418c9c: Loading layer 39.49MB/39.49MB
Loaded image: registry.aliyuncs.com/google_containers/kube-proxy:v1.20.0
aa679bed73e1: Loading layer 42.85MB/42.85MB
Loaded image: registry.aliyuncs.com/google_containers/kube-scheduler:v1.20.0
ba0dae6243cc: Loading layer 684.5kB/684.5kB
Loaded image: registry.aliyuncs.com/google_containers/pause:3.2
使用kubeadm命令初始化k8s
[root@k8s-master1 ~]# kubeadm init --config kubeadm-config.yaml
W0815 15:23:00.499793 16148 common.go:77] your configuration file uses a deprecated API spec: "kubeadm.k8s.io/v1beta1". Please use 'kubeadm config migrate --old-config old.yaml --new-config new.yaml', which will write the new, similar spec using a newer API version.
[init] Using Kubernetes version: v1.20.0
[preflight] Running pre-flight checks[WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/[WARNING SystemVerification]: this Docker version is not on the list of validated versions: 24.0.5. Latest validated version: 19.03
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [k8s-master1 k8s-master2 k8s-master3 kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local master.k8s.io] and IPs [10.1.0.1 192.168.108.165 192.168.2.111 192.168.2.112 192.168.2.115 192.168.2.154 127.0.0.1]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [k8s-master1 localhost] and IPs [192.168.108.165 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [k8s-master1 localhost] and IPs [192.168.108.165 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 7.002691 seconds
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[kubelet] Creating a ConfigMap "kubelet-config-1.20" in namespace kube-system with the configuration for the kubelets in the cluster
[upload-certs] Skipping phase. Please see --upload-certs
[mark-control-plane] Marking the node k8s-master1 as control-plane by adding the labels "node-role.kubernetes.io/master=''" and "node-role.kubernetes.io/control-plane='' (deprecated)"
[mark-control-plane] Marking the node k8s-master1 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
[bootstrap-token] Using token: s8zd78.koquhvbv0e767uqb
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxyYour Kubernetes control-plane has initialized successfully!To start using your cluster, you need to run the following as a regular user:mkdir -p $HOME/.kubesudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/configsudo chown $(id -u):$(id -g) $HOME/.kube/configAlternatively, if you are the root user, you can run:export KUBECONFIG=/etc/kubernetes/admin.confYou should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:https://kubernetes.io/docs/concepts/cluster-administration/addons/You can now join any number of control-plane nodes by copying certificate authorities
and service account keys on each node and then running the following as root:kubeadm join master.k8s.io:6443 --token s8zd78.koquhvbv0e767uqb \ #加入master时使用--discovery-token-ca-cert-hash sha256:e4fea2471e5bd54b18d703830aa87307f3c586ca882a809bb8e1f2fa335f78e6 \--control-plane Then you can join any number of worker nodes by running the following on each as root:kubeadm join master.k8s.io:6443 --token s8zd78.koquhvbv0e767uqb \ #加入node时使用--discovery-token-ca-cert-hash sha256:e4fea2471e5bd54b18d703830aa87307f3c586ca882a809bb8e1f2fa335f78e6
初始化中的错误：
[ERROR FileContent--proc-sys-net-bridge-bridge-nf-call-iptables]: /proc/sys/net/bridge/bridge-nf-call-iptables contents are not set to 1执行以下命令后重新执行初始化命令
echo "1" >/proc/sys/net/bridge/bridge-nf-call-iptables根据初始化的结果操作
[root@k8s-master1 ~]# mkdir -p $HOME/.kube
[root@k8s-master1 ~]# sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
[root@k8s-master1 ~]# sudo chown $(id -u):$(id -g) $HOME/.kube/config
查看集群状态
[root@k8s-master1 ~]# kubectl get csWarning: v1 ComponentStatus is deprecated in v1.19+
NAME STATUS MESSAGE ERROR
scheduler Unhealthy Get "http://127.0.0.1:10251/healthz": dial tcp 127.0.0.1:10251: connect: connection refused
controller-manager Unhealthy Get "http://127.0.0.1:10252/healthz": dial tcp 127.0.0.1:10252: connect: connection refused
etcd-0 Healthy {"health":"true"} 注意：出现以上错误情况，是因为/etc/kubernetes/manifests/下的kube-controller-manager.yaml和kube-scheduler.yaml设置的默认端口为0导致的，解决方式是注释掉对应的port即可
修改kube-controller-manager.yaml文件
[root@k8s-master1 ~]# vim /etc/kubernetes/manifests/kube-controller-manager.yaml
修改kube-scheduler.yaml文件
[root@k8s-master1 ~]# vim /etc/kubernetes/manifests/kube-scheduler.yaml
查看集群状态
[root@k8s-master1 ~]# kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME STATUS MESSAGE ERROR
scheduler Healthy ok
controller-manager Healthy ok
etcd-0 Healthy {"health":"true"} [root@k8s-master1 ~]# kubectl get pods -n kube-system
NAME READY STATUS RESTARTS AGE
coredns-7f89b7bc75-bzbrr 0/1 Pending 0 29m
coredns-7f89b7bc75-wlx26 0/1 Pending 0 29m
etcd-k8s-master1 1/1 Running 0 30m
kube-apiserver-k8s-master1 1/1 Running 0 30m
kube-controller-manager-k8s-master1 1/1 Running 1 2m30s
kube-proxy-nk87c 1/1 Running 0 29m
kube-scheduler-k8s-master1 1/1 Running 0 3m19s
查看节点信息
[root@k8s-master1 ~]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master1 NotReady control-plane,master 30m v1.20.0
3.7、安装集群网络
在k8s-master1节点执行
flannel所需文件提取链接：https://pan.baidu.com/s/1ywYDndOVFnCdLAqH8eHa3Q?pwd=5t95
提取码：5t95
[root@k8s-master1 ~]# docker load < flannel_v0.12.0-amd64.tar
256a7af3acb1: Loading layer 5.844MB/5.844MB
d572e5d9d39b: Loading layer 10.37MB/10.37MB
57c10be5852f: Loading layer 2.249MB/2.249MB
7412f8eefb77: Loading layer 35.26MB/35.26MB
05116c9ff7bf: Loading layer 5.12kB/5.12kB
Loaded image: quay.io/coreos/flannel:v0.12.0-amd64[root@k8s-master1 ~]# tar xf cni-plugins-linux-amd64-v0.8.6.tgz
[root@k8s-master1 ~]# cp flannel /opt/cni/bin/[root@k8s-master1 ~]# kubectl apply -f kube-flannel.yml
podsecuritypolicy.policy/psp.flannel.unprivileged created
Warning: rbac.authorization.k8s.io/v1beta1 ClusterRole is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 ClusterRole
clusterrole.rbac.authorization.k8s.io/flannel created
Warning: rbac.authorization.k8s.io/v1beta1 ClusterRoleBinding is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 ClusterRoleBinding
clusterrolebinding.rbac.authorization.k8s.io/flannel created
serviceaccount/flannel created
configmap/kube-flannel-cfg created
daemonset.apps/kube-flannel-ds-amd64 created
daemonset.apps/kube-flannel-ds-arm64 created
daemonset.apps/kube-flannel-ds-arm created
daemonset.apps/kube-flannel-ds-ppc64le created
daemonset.apps/kube-flannel-ds-s390x created再次查看节点信息：
[root@k8s-master1 ~]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master1 Ready control-plane,master 9m12s v1.20.0
3.8、添加master节点
在k8s-master2和k8s-master3节点创建文件夹
[root@k8s-master2 ~]# mkdir -p /etc/kubernetes/pki/etcd[root@k8s-master3 ~]# mkdir -p /etc/kubernetes/pki/etcd在k8s-master1节点执行
从k8s-master1复制秘钥和相关文件到k8s-master2和k8s-master3
[root@k8s-master1 ~]# scp /etc/kubernetes/admin.conf 192.168.2.112:/etc/kubernetes/
root@192.168.2.112's password:
admin.conf 100% 5569 8.0MB/s 00:00 [root@k8s-master1 ~]# scp /etc/kubernetes/admin.conf 192.168.2.115:/etc/kubernetes/
root@192.168.2.115's password:
admin.conf 100% 5569 7.9MB/s 00:00[root@k8s-master1 ~]# scp /etc/kubernetes/pki/{ca.*,sa.*,front-proxy-ca.*} 192.168.2.112://etc/kubernetes/pki/
root@192.168.2.112's password:
ca.crt 100% 1066 1.3MB/s 00:00
ca.key 100% 1679 2.2MB/s 00:00
sa.key 100% 1679 2.0MB/s 00:00
sa.pub 100% 451 832.0KB/s 00:00
front-proxy-ca.crt 100% 1078 730.7KB/s 00:00
front-proxy-ca.key 100% 1679 1.8MB/s 00:00 [root@k8s-master1 ~]# scp /etc/kubernetes/pki/{ca.*,sa.*,front-proxy-ca.*} 192.168.2.115://etc/kubernetes/pki/
root@192.168.2.115's password:
ca.crt 100% 1066 1.6MB/s 00:00
ca.key 100% 1679 1.1MB/s 00:00
sa.key 100% 1679 2.7MB/s 00:00
sa.pub 100% 451 591.4KB/s 00:00
front-proxy-ca.crt 100% 1078 1.6MB/s 00:00
front-proxy-ca.key 100% 1679 2.8MB/s 00:00 [root@k8s-master1 ~]# scp /etc/kubernetes/pki/etcd/ca.* 192.168.2.112:/etc/kubernetes/pki/etcd/
root@192.168.2.112's password:
ca.crt 100% 1058 1.6MB/s 00:00
ca.key 100% 1679 1.7MB/s 00:00 [root@k8s-master1 ~]# scp /etc/kubernetes/pki/etcd/ca.* 192.168.2.115:/etc/kubernetes/pki/etcd/
root@192.168.2.115's password:
ca.crt 100% 1058 1.8MB/s 00:00
ca.key 100% 1679 2.0MB/s 00:00 将其他master节点加入集群
注意：kubeadm init生成的token有效期只有1天，生成不过期token
[root@k8s-master1 ~]# kubeadm token create --ttl 0 --print-join-commandkubeadm join master.k8s.io:6443 --token h5z2qr.n6oeu18sutk0atkj --discovery-token-ca-cert-hash sha256:4464f179679e97286f2b8efcf96a4da6374e2fc6b5e8fb1b9623f4975bf243b7 [root@k8s-master1 ~]# kubeadm token listTOKEN TTL EXPIRES USAGES DESCRIPTION EXTRA GROUPS
c76rob.ye2104dd4splb1cs 23h 2023-08-16T19:13:39+08:00 authentication,signing <none> system:bootstrappers:kubeadm:default-node-token
h5z2qr.n6oeu18sutk0atkj <forever> <never> authentication,signing <none> system:bootstrappers:kubeadm:default-node-token
k8s-master2和k8s-master3都需要加入
[root@k8s-master2 ~]# kubeadm join master.k8s.io:6443 --token h5z2qr.n6oeu18sutk0atkj --discovery-token-ca-cert-hash sha256:4464f179679e97286f2b8efcf96a4da6374e2fc6b5e8fb1b9623f4975bf243b7 --control-plane[preflight] Running pre-flight checks[WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/[WARNING SystemVerification]: this Docker version is not on the list of validated versions: 24.0.5. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[preflight] Running pre-flight checks before initializing the new control plane instance
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [k8s-master1 k8s-master2 k8s-master3 kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local master.k8s.io] and IPs [10.1.0.1 192.168.108.166 192.168.2.111 192.168.2.112 192.168.2.115 192.168.2.154 127.0.0.1]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [k8s-master2 localhost] and IPs [192.168.108.166 127.0.0.1 ::1]
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [k8s-master2 localhost] and IPs [192.168.108.166 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Valid certificates and keys now exist in "/etc/kubernetes/pki"
[certs] Using the existing "sa" key
[kubeconfig] Generating kubeconfig files
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Using existing kubeconfig file: "/etc/kubernetes/admin.conf"
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[check-etcd] Checking that the etcd cluster is healthy
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
[etcd] Announced new etcd member joining to the existing etcd cluster
[etcd] Creating static Pod manifest for "etcd"
[etcd] Waiting for the new etcd member to join the cluster. This can take up to 40s
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[mark-control-plane] Marking the node k8s-master2 as control-plane by adding the labels "node-role.kubernetes.io/master=''" and "node-role.kubernetes.io/control-plane='' (deprecated)"
[mark-control-plane] Marking the node k8s-master2 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]This node has joined the cluster and a new control plane instance was created:* Certificate signing request was sent to apiserver and approval was received.
* The Kubelet was informed of the new secure connection details.
* Control plane (master) label and taint were applied to the new node.
* The Kubernetes control plane instances scaled up.
* A new etcd member was added to the local/stacked etcd cluster.To start administering your cluster from this node, you need to run the following as a regular user:mkdir -p $HOME/.kubesudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/configsudo chown $(id -u):$(id -g) $HOME/.kube/configRun 'kubectl get nodes' to see this node join the cluster.[root@k8s-master2 ~]# mkdir -p $HOME/.kube
[root@k8s-master2 ~]# sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
[root@k8s-master2 ~]# sudo chown $(id -u):$(id -g) $HOME/.kube/config[root@k8s-master2 ~]# docker load < flannel_v0.12.0-amd64.tar
Loaded image: quay.io/coreos/flannel:v0.12.0-amd64[root@k8s-master1 ~]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master1 Ready control-plane,master 31m v1.20.0
k8s-master2 Ready control-plane,master 4m28s v1.20.0
k8s-master3 Ready control-plane,master 3m39s v1.20.0[root@k8s-master1 ~]# kubectl get pods --all-namespaces
NAMESPACE NAME READY STATUS RESTARTS AGE
kube-system coredns-7f89b7bc75-dwqf6 1/1 Running 0 31m
kube-system coredns-7f89b7bc75-ksztn 1/1 Running 0 31m
kube-system etcd-k8s-master1 1/1 Running 0 32m
kube-system etcd-k8s-master2 1/1 Running 0 4m32s
kube-system etcd-k8s-master3 1/1 Running 0 2m34s
kube-system kube-apiserver-k8s-master1 1/1 Running 0 32m
kube-system kube-apiserver-k8s-master2 1/1 Running 0 4m35s
kube-system kube-apiserver-k8s-master3 1/1 Running 0 2m41s
kube-system kube-controller-manager-k8s-master1 1/1 Running 1 30m
kube-system kube-controller-manager-k8s-master2 1/1 Running 0 4m36s
kube-system kube-controller-manager-k8s-master3 1/1 Running 0 2m52s
kube-system kube-flannel-ds-amd64-4zl22 1/1 Running 0 3m48s
kube-system kube-flannel-ds-amd64-lshgp 1/1 Running 0 27m
kube-system kube-flannel-ds-amd64-tsj6h 1/1 Running 0 4m37s
kube-system kube-proxy-b2vl6 1/1 Running 0 4m37s
kube-system kube-proxy-kgbxr 1/1 Running 0 31m
kube-system kube-proxy-t2v2f 1/1 Running 0 3m48s
kube-system kube-scheduler-k8s-master1 1/1 Running 1 30m
kube-system kube-scheduler-k8s-master2 1/1 Running 0 4m35s
kube-system kube-scheduler-k8s-master3 1/1 Running 0 2m55s
3.9、加入Kubernetes Node
直接在node节点服务器上执行k8s-master1初始化成功后的消息即可：
[root@k8s-node1 ~]# kubeadm join master.k8s.io:6443 --token h5z2qr.n6oeu18sutk0atkj --discovery-token-ca-cert-hash sha256:4464f179679e97286f2b8efcf96a4da6374e2fc6b5e8fb1b9623f4975bf243b7[preflight] Running pre-flight checks[WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/[WARNING SystemVerification]: this Docker version is not on the list of validated versions: 24.0.5. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
W0815 19:49:01.547785 10847 common.go:148] WARNING: could not obtain a bind address for the API Server: no default routes found in "/proc/net/route" or "/proc/net/ipv6_route"; using: 0.0.0.0
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.Run 'kubectl get nodes' on the control-plane to see this node join the cluster.[root@k8s-node1 ~]# docker load < flannel_v0.12.0-amd64.tar
256a7af3acb1: Loading layer [==================================================>] 5.844MB/5.844MB
d572e5d9d39b: Loading layer [==================================================>] 10.37MB/10.37MB
57c10be5852f: Loading layer [==================================================>] 2.249MB/2.249MB
7412f8eefb77: Loading layer [==================================================>] 35.26MB/35.26MB
05116c9ff7bf: Loading layer [==================================================>] 5.12kB/5.12kB
Loaded image: quay.io/coreos/flannel:v0.12.0-amd64
查看节点信息
[root@k8s-master1 ~]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master1 Ready control-plane,master 40m v1.20.0
k8s-master2 Ready control-plane,master 12m v1.20.0
k8s-master3 Ready control-plane,master 11m v1.20.0
k8s-node1 Ready <none> 4m48s v1.20.0
k8s-node2 Ready <none> 4m48s v1.20.0
k8s-node3 Ready <none> 4m48s v1.20.0
3.10、测试Kubernetes集群
所有node主机导入测试镜像
测试镜像提取链接：https://pan.baidu.com/s/1ebtV-o13GZ0ocOAyYPsvHA?pwd=n0gx
提取码：n0gx
[root@k8s-node1 ~]# docker load < nginx-1.19.tar 87c8a1d8f54f: Loading layer [==================================================>] 72.5MB/72.5MB
5c4e5adc71a8: Loading layer [==================================================>] 64.6MB/64.6MB
7d2b207c2679: Loading layer [==================================================>] 3.072kB/3.072kB
2c7498eef94a: Loading layer [==================================================>] 4.096kB/4.096kB
4eaf0ea085df: Loading layer [==================================================>] 3.584kB/3.584kB
Loaded image: nginx:latest[root@k8s-node1 ~]# docker tag nginx nginx:1.19.6
在Kubernetes集群中创建一个pod，验证是否正常运行。
[root@k8s-master1 ~]# mkdir demo
[root@k8s-master1 ~]# cd demo/
[root@k8s-master1 demo]# vim nginx-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:name: nginx-deploymentlabels:app: nginx
spec:replicas: 3selector: matchLabels:app: nginxtemplate:metadata:labels:app: nginxspec:containers:- name: nginximage: nginx:1.19.6ports:- containerPort: 80创建完 Deployment 的资源清单之后，使用 create 执行资源清单来创建容器。通过 get pods 可以查看到 Pod 容器资源已经自动创建完成。
[root@k8s-master1 demo]# kubectl create -f nginx-deployment.yamldeployment.apps/nginx-deployment created[root@k8s-master1 demo]# kubectl get pods
NAME READY STATUS RESTARTS AGE
nginx-deployment-76ccf9dd9d-cmv2x 1/1 Running 0 3m48s
nginx-deployment-76ccf9dd9d-ld6q9 1/1 Running 0 3m36s
nginx-deployment-76ccf9dd9d-nddmx 1/1 Running 0 114s[root@k8s-master1 ~]# kubectl get pods -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
nginx-deployment-76ccf9dd9d-cmv2x 1/1 Running 0 4m19s 10.244.5.3 k8s-node3 <none> <none>
nginx-deployment-76ccf9dd9d-ld6q9 1/1 Running 0 4m7s 10.244.3.3 k8s-node1 <none> <none>
nginx-deployment-76ccf9dd9d-nddmx 1/1 Running 0 2m25s 10.244.3.4 k8s-node1 <none> <none>
创建Service资源清单
在创建的 nginx-service 资源清单中，定义名称为 nginx-service 的 Service、标签选择器为 app: nginx、type 为 NodePort 指明外部流量可以访问内部容器。在 ports 中定义暴露的端口库号列表，对外暴露访问的端口是 80，容器内部的端口也是 80。
[root@k8s-master1 demo]# vim nginx-service.yaml
kind: Service
apiVersion: v1
metadata:name: nginx-service
spec:selector:app: nginxtype: NodePortports:- protocol: TCPport: 80targetPort: 80[root@k8s-master1 demo]# kubectl create -f nginx-service.yamlservice/nginx-service created[root@k8s-master1 demo]# kubectl get svcNAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 60m
nginx-service NodePort 10.1.117.38 <none> 80:31280/TCP 13s
通过浏览器访问nginx：http://master.k8s.io:31280 域名或者VIP地址
[root@k8s-master1 demo]# elinks --dump http://master.k8s.io:31280Welcome to nginx!If you see this page, the nginx web server is successfully installed andworking. Further configuration is required.For online documentation and support please refer to [1]nginx.org.Commercial support is available at [2]nginx.com.Thank you for using nginx.ReferencesVisible links1. http://nginx.org/2. http://nginx.com/
挂起k8s-master1节点，刷新页面还是能访问nginx，说明高可用集群部署成功。
检查会发现VIP已经转移到k8s-master2节点上
[root@k8s-master2 ~]# ip a s ens33
2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000link/ether 00:0c:29:e2:cd:b7 brd ff:ff:ff:ff:ff:ffinet 192.168.2.112/24 brd 192.168.2.255 scope global noprefixroute ens33valid_lft forever preferred_lft foreverinet 192.168.2.154/32 scope global ens33valid_lft forever preferred_lft foreverinet6 fe80::5a1c:3be9:c4a:453d/64 scope link noprefixroute valid_lft forever preferred_lft forever
至此Kubernetes企业级高可用环境完美实现。
相关文章：
Kubernetes 企业级高可用部署
目录 1、Kubernetes高可用项目介绍 2、项目架构设计 2.1、项目主机信息 2.2、项目架构图 2.3、项目实施思路 3、项目实施过程 3.1、系统初始化 3.2、配置部署keepalived服务 3.3、配置部署haproxy服务 3.4、配置部署Docker服务 3.5、部署kubelet kubeadm kubectl工具…...
8.1 C++ STL 变易拷贝算法
C STL中的变易算法（Modifying Algorithms）是指那些能够修改容器内容的算法，主要用于修改容器中的数据，例如插入、删除、替换等操作。这些算法同样定义在头文件 <algorithm> 中，它们允许在容器之间进行元素的复制…...
攻击LNMP架构Web应用
环境配置(centos7) 1.php56 php56-fpm //配置epel yum install epel-release rpm -ivh http://rpms.famillecollet.com/enterprise/remi-release-7.rpm//安装php56，php56-fpm及其依赖 yum --enablereporemi install php56-php yum --enablereporemi install php…...
深度学习入门-3-计算机视觉-图像分类
1.概述 图像分类是根据图像的语义信息对不同类别图像进行区分，是计算机视觉的核心，是物体检测、图像分割、物体跟踪、行为分析、人脸识别等其他高层次视觉任务的基础。图像分类在许多领域都有着广泛的应用，如：安防领域的人脸识别…...
shopee运营新手入门教程！Shopee运营技巧！
随着跨境电商行业的蓬勃发展，越来越多的人开始关注Shopee这个平台。短视频等渠道也成为了人们了解Shopee的途径。因此，对于许多新手来说，在Shopee上开店成为了一种吸引人的选择。为了帮助这些新手更好地入门，下面将介绍一下Shop…...
Python Web框架：Django、Flask和FastAPI巅峰对决
今天，我们将深入探讨Python Web框架的三巨头：Django、Flask和FastAPI。无论你是Python小白还是老司机，本文都会为你解惑，带你领略这三者的魅力。废话不多说，让我们开始这场终极对比！ Django：百…...
机器学习线性代数基础
本文是斯坦福大学CS 229机器学习课程的基础材料，原始文件下载 原文作者：Zico Kolter，修改：Chuong Do， Tengyu Ma 翻译：黄海广 备注：请关注github的更新，线性代数和概率论已经更新完毕…...
PyQt5组件之QLabel显示图像和视频
目录 一、显示图像和视频 1、显示图像 2、显示视频 二、QtDesigner 窗口简单介绍 三、相关函数 1、打开本地图片 2、保存图片到本地 3、打开文件夹 4、打开本地文本文件并显示 5、保存文本到本地 6、关联函数 7、图片 “.png” | “.jpn” Label 自适应显示 8、Q…...
微信程序 自定义遮罩层遮不住底部tabbar解决
一、先上效果 二 方法 1、自定义底部tabbar 实现： https://developers.weixin.qq.com/miniprogram/dev/framework/ability/custom-tabbar.html 官网去抄 简单写下：在代码根目录下添加入口文件 除了js 文件的list 需要调整 其他原封不动 代码…...
Python简易部署方法
一.安装Python解释器和vscode或者其他开发工具 下载地址： 1.下载vscode 链接: https://code.visualstudio.com/. 2.下载python解释器 链接: https://www.python.org/downloads/. 二.安装包 打开cmd，输入命令：pip install 包名 三.配置…...
Spring Boot单元测试与Mybatis单表增删改查
目录 1. Spring Boot单元测试 1.1 什么是单元测试? 1.2 单元测试有哪些好处? 1.3 Spring Boot 单元测试使用 单元测试的实现步骤 1. 生成单元测试类 2. 添加单元测试代码 简单的断言说明 2. Mybatis 单表增删改查 2.1 单表查询 2.2 参数占位符 ${} 和 #{} ${} 和 …...
机器学习样本数据划分的典型Python方法
机器学习样本数据划分的典型Python方法 DateAuthorVersionNote2023.08.16Dog TaoV1.0完成文档撰写。 文章目录 机器学习样本数据划分的典型Python方法样本数据的分类Training DataValidation DataTest Data numpy.ndarray类型数据直接划分交叉验证基于KFold基于RepeatedKFold基…...
重建与突破，探讨全链游戏的现在与未来
全链游戏（On-Chain Game）是指将游戏内资产通过虚拟货币或 NFT 形式记录上链的游戏类型。除此以外，游戏的状态存储、计算与执行等皆被部署在链上，目的是为用户打造沉浸式、全方位的游戏体验，超越传统游戏玩家被动控制的…...
[C++] 模板template
目录 1、函数模板 1.1 函数模板概念 1.2 函数模板格式 1.3 函数模板的原理 1.4 函数模板的实例化 1.4.1 隐式实例化 1.4.2 显式实例化 1.5 模板参数的匹配原则 2、类模板 2.1 类模板的定义格式 2.2 类模板的实例化 讲模板之前呢，我们先来谈谈泛型编程&am…...
[vite] 项目打包后页面空白,配置了base后也不生效
记录下解决问题的过程和思路 首先打开看打包后的 dist/index.html 文件，和页面上的报错 这里就发现了第一个问题 报错的意思是 index.html中引用的 css文件 和 js文件 找不到 为了解决这个问题，在vite.config.js配置中，增加一项 base:./ …...
springboot整合kafka-笔记
springboot整合kafka-笔记 配置pom.xml 这里我的springboot版本是2.3.8.RELEASE，使用的kafka-mq的版本是2.12 <dependencyManagement><dependencies><dependency><groupId>org.springframework.boot</groupId><artifactId>s…...
Rust软件外包开发语言的特点
Rust 是一种系统级编程语言，强调性能、安全性和并发性的编程语言，适用于广泛的应用领域，特别是那些需要高度可靠性和高性能的场景。下面和大家分享 Rust 语言的一些主要特点以及适用的场合，希望对大家有所帮助。北京木奇移动技术有…...
Spring Boot业务代码中使用@Transactional事务失效踩坑点总结
1.概述 接着之前我们对Spring AOP以及基于AOP实现事务控制的上文，今天我们来看看平时在项目业务开发中使用声明式事务Transactional的失效场景，并分析其失效原因，从而帮助开发人员尽量避免踩坑。 我们知道 Spring 声明式事务功能提供了极其…...
知识体系总结（九）设计原则、设计模式、分布式、高性能、高可用
文章目录 架构设计为什么要进行技术框架的设计 六大设计原则一、单一职责原则二、开闭原则三、依赖倒置原则四、接口分离原则五、迪米特法则（又称最小知道原则）六、里氏替换原则案例诠释 常见设计模式构造型单例模式工厂模式简单工厂工厂方法 生成器模式…...
Springboot 集成Beetl模板
一、在启动类下的pom.xml中导入依赖： <!--beetl模板引擎--><dependency><groupId>com.ibeetl</groupId><artifactId>beetl</artifactId><version>2.9.8</version></dependency> 二、 配置 beetl需要的Beetl…...
RabbitMQ查询队列使用情况和消费者详情实现
spring-boot-starter-amqp spring-boot-starter-amqp是Spring Boot框架中与AMQP（高级消息队列协议）相关的自动配置启动器。它提供了使用AMQP进行消息传递和异步通信的功能。 以下是spring-boot-starter-amqp的主要特性和功能： 自动配置：spring-boot-starter-amqp通过自动…...
Spark第二课RDD的详解
1.前言 RDD JAVA中的IO 1.小知识点穿插 1. 装饰者设计模式 装饰者设计模式:本身功能不变,扩展功能. 举例： 数据流的读取 一层一层的包装，进而将功能进行进一步的扩展 2.sleep和wait的区别 本质区别是字体不一样,sleep斜体,wait正常 斜体是静态方法…...
人工智能学习框架—飞桨Paddle人工智能
1.人工智能框架 机器学习的三要素：模型、学习策略、优化算法。 当我们用机器学习来解决一些模式识别任务时，一般的流程包含以下几个步骤： 1.1.浅层学习和深度学习 浅层学习(Shallow Learning)：不涉及特征学习，其特征…...
SElinux 导致 Keepalived 检测脚本无法执行
哈喽大家好，我是咸鱼 今天我们来看一个关于 Keepalived 检测脚本无法执行的问题 一位粉丝后台私信我，说他部署的 keepalived 集群 vrrp_script 模块中的脚本执行失败了，但是手动执行这个脚本却没有任何问题 这个问题也是咸鱼第一次遇到&…...
2022年电赛C题——小车跟随行驶系统——做题记录以及经验分享
前言 自己打算将做过的电赛真题，主要包含控制组的，近几年出现的小车控制题目，自己做过的真题以及在准备电赛期间刷真题出现的问题以及经验分享给大家 这次带来的是22年电赛C题——小车跟随行驶系统，这道题目指定使用的是TI的单片…...
vscode + python
序 参考链接： 【教程】VScode中配置Python运行环境_哔哩哔哩_bilibili Python部分 Python Releases for Windows | Python.org vscode部分 Visual Studio Code - Code Editing. Redefined 一路next，全部勾上： 就可以了： 安装插…...
badgerdb里面的事务
事务的ACID A 原子性（Atomicity） 多步骤操作，只能是两种状态，要么所有的步骤都成功执行，要么所有的步骤都不执行，举例说明就是小明向小红转账30元的场景，拆分成两个步骤，步骤1&#…...
C# this.Invoke(new Action(() =＞ { /* some code */ }))用法说明
在 C# 中，this.Invoke(new Action(() > { /* some code */ })) 是一种用于在 UI 线程上执行代码的方法，通常用于在后台线程中更新 UI 控件的值或执行其他需要在 UI 线程上执行的操作。 在 Windows Forms 或 WPF 等图形界面应用程序中，UI …...
MongoDB:MySQL,Redis,ES,MongoDB的应用场景
简单明了说明MySQL,ES,MongoDB的各自特点,应用场景,以及MongoDB如何使用的第一章节. 一. SQL与NoSQL SQL被称为结构化查询语言.是传统意义上的数据库,数据之间存在很明确的关联关系,例如主外键关联,这种结构可以确保数据的完整性(数据没有缺失并且正确).但是正因为这种严密的结…...
leetcode每日一题_2682.找出转圈游戏输家
2682.找出转圈游戏输家 题目: n 个朋友在玩游戏。这些朋友坐成一个圈，按 顺时针方向 从 1 到 n 编号。从第 i 个朋友的位置开始顺时针移动 1 步会到达第 (i 1) 个朋友的位置（1 < i < n），而从第 n 个朋友的位置开始顺时针移…...
