kubectl基础命令详解

管理名称空间资源

查看名称空间

[root@ceshi-130 conf]# kubectl get ns
[root@ceshi-130 conf]# kubectl get namespace
NAME              STATUS   AGE
default           Active   7d17h
kube-node-lease   Active   7d17h
kube-public       Active   7d17h
kube-system       Active   7d17h

查询default空间所有资源

[root@ceshi-130 conf]# kubectl get all -n default
[root@ceshi-130 conf]# kubectl get all  #默认default
pod资源
NAME                 READY   STATUS    RESTARTS   AGE
pod/nginx-ds-c7bnr   1/1     Running   1          18h
pod/nginx-ds-lkznc   1/1     Running   1          18hservice资源
NAME                 TYPE        CLUSTER-IP    EXTERNAL-IP   PORT(S)   AGE
service/kubernetes   ClusterIP   192.168.0.1   <none>        443/TCP   7d17hdaemonset控制器资源
NAME                      DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR   AGE
daemonset.apps/nginx-ds   2         2         2       2            2           <none>          18h

创建名称空间

[root@ceshi-130 conf]# kubectl create ns ceshi
namespace/ceshi created
[root@ceshi-130 conf]# kubectl get ns
NAME              STATUS   AGE
ceshi             Active   44s

删除名称空间

[root@ceshi-130 conf]# kubectl delete ns ceshi
namespace "ceshi" deleted

管理Deployment资源

创建deployment

[root@ceshi-130 conf]# kubectl create deployment nginx-test --image=harbor.od.com/public/nginx:v1.7.9 -n kube-public
[root@ceshi-130 conf]# kubectl get deployment -n kube-public
NAME         READY   UP-TO-DATE   AVAILABLE   AGE
nginx-test   1/1     1            1           17s
[root@ceshi-130 conf]# kubectl get pods -n kube-public
NAME                         READY   STATUS    RESTARTS   AGE
nginx-test-88bc69dd6-cgh8k   1/1     Running   0          41s

查看

[root@ceshi-130 conf]# kubectl get deployment -n kube-public
NAME         READY   UP-TO-DATE   AVAILABLE   AGE
nginx-test   1/1     1            1           9m13s
[root@ceshi-130 conf]# kubectl get deployment -n kube-public -o wide
NAME         READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES                              SELECTOR
nginx-test   1/1     1            1           10m   nginx        harbor.od.com/public/nginx:v1.7.9   app=nginx-test

详细查看

[root@ceshi-130 conf]# kubectl describe deployment nginx-test -n kube-public
Name:                   nginx-test #名称
Namespace:              kube-public #名称空间
CreationTimestamp:      Tue, 03 Aug 2021 10:34:12 +0800 #创建时间
Labels:                 app=nginx-test #标签
Annotations:            deployment.kubernetes.io/revision: 1 #注解
Selector:               app=nginx-test #标签选择器
Replicas:               1 desired | 1 updated | 1 total | 1 available | 0 unavailable
状态副本集			    	预期一个	  最新状态  	总共一个	   1个存在		 0个不存在
StrategyType:           RollingUpdate #更新策略，默认滚动发布(蓝绿发布，灰度发布，滚动发布，金丝雀发布)
MinReadySeconds:        0
RollingUpdateStrategy:  25% max unavailable, 25% max surge
Pod Template:Labels:  app=nginx-testContainers:nginx:Image:        harbor.od.com/public/nginx:v1.7.9Port:         <none>Host Port:    <none>Environment:  <none>Mounts:       <none>Volumes:        <none>
Conditions:Type           Status  Reason----           ------  ------Available      True    MinimumReplicasAvailableProgressing    True    NewReplicaSetAvailable
OldReplicaSets:  <none>
NewReplicaSet:   nginx-test-88bc69dd6 (1/1 replicas created)
Events:Type    Reason             Age   From                   Message----    ------             ----  ----                   -------Normal  ScalingReplicaSet  12m   deployment-controller  Scaled up replica set nginx-test-88bc69dd6 to 1

pod资源

进入pod资源
[root@ceshi-130 conf]# kubectl exec -it nginx-test-88bc69dd6 bash -n kube-public配置端口
[root@ceshi-130 conf]# kubectl expose deployment nginx-test --port=80 -n kube-public
service/nginx-test exposed
[root@ceshi-130 conf]# kubectl get all -n kube-public
NAME                             READY   STATUS    RESTARTS   AGE
pod/nginx-test-88bc69dd6-cgh8k   1/1     Running   2          5h16m对外提供的唯一出口
NAME                 TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)   AGE
service/nginx-test   ClusterIP   192.168.37.172   <none>        80/TCP    25sNAME                         READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/nginx-test   1/1     1            1           5h16mNAME                                   DESIRED   CURRENT   READY   AGE
replicaset.apps/nginx-test-88bc69dd6   1         1         1       5h16m查看LVS规则，上面的CLUSTER-IP代理172.7.200.1节点
[root@ceshi-131 certs]# ipvsadm -Ln
IP Virtual Server version 1.2.1 (size=4096)
Prot LocalAddress:Port Scheduler Flags-> RemoteAddress:Port           Forward Weight ActiveConn InActConn
TCP  192.168.0.1:443 nq-> 10.1.74.22:6443              Masq    1      0          0         -> 10.1.74.23:6443              Masq    1      0          0
TCP  192.168.37.172:80 nq-> 172.7.200.1:80               Masq    1      0          1 扩容节点
[root@ceshi-130 conf]# kubectl scale deployment nginx-test --replicas=2 -n kube-public
deployment.extensions/nginx-test scaled[root@ceshi-130 conf]# ipvsadm -Ln
IP Virtual Server version 1.2.1 (size=4096)
Prot LocalAddress:Port Scheduler Flags-> RemoteAddress:Port           Forward Weight ActiveConn InActConn
TCP  192.168.0.1:443 nq-> 10.1.74.22:6443              Masq    1      0          0         -> 10.1.74.23:6443              Masq    1      0          0
TCP  192.168.37.172:80 nq-> 172.7.200.1:80               Masq    1      0          0         -> 172.7.200.3:80               Masq    1      0          0

删除deployment

查看
[root@ceshi-131 certs]# kubectl get deploy
NAME        READY   UP-TO-DATE   AVAILABLE   AGE
nginx-ljx   1/1     1            1           42m
删除
[root@ceshi-131 certs]# kubectl delete deploy nginx-ljx
deployment.extensions "nginx-ljx" deleted[root@ceshi-131 certs]# kubectl get pods
NAME                         READY   STATUS        RESTARTS   AGE
nginx-ds-f82d2               1/1     Running       0          2m43s
nginx-ds-lkznc               1/1     Running       3          24h
nginx-ljx-669cc7d666-hj9qh   0/1     Terminating   0          73s

---

通过和本机8080 apiserver进行通信，将用户再命令行输入的命令，组织并转换为apiserver识别的信息，实现管理各种资源的一种有限途径

---

以yaml格式显示pod

 [root@ceshi-130 conf]# kubectl get pods nginx-test-88bc69dd6-4vk58 -o yaml -n kube-public

以yaml格式显示service

[root@ceshi-130 conf]# kubectl get svc nginx-test -o yaml -n kube-public

创建资源配置清单

[root@ceshi-130 ~]# cat nginx-ljx.yaml
apiVersion: v1
kind: Service
metadata:name: nginx-ljxnamespace: defaultlabels:app: nginx-ljx
spec:ports:- port: 80protocol: TCPtargetPort: 80selector:type: ClusterIP
[root@ceshi-130 ~]# kubectl create -f nginx-ljx.yaml
service/nginx-ljx created
查看service
[root@ceshi-130 ~]# kubectl get svc
NAME         TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   192.168.0.1      <none>        443/TCP   8d
nginx-ljx    ClusterIP   192.168.134.19   <none>        80/TCP    35s  离线修改并应用
[root@ceshi-130 ~]# kubectl apply -f nginx-ljx.yaml 在线修改并应用
[root@ceshi-130 ~]# kubectl edit svc nginx-ljx
service/nginx-ljx edited
[root@ceshi-130 ~]# kubectl get svc
NAME         TYPE        CLUSTER-IP        EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   192.168.0.1       <none>        443/TCP   8d
nginx-ljx    ClusterIP   192.168.129.159   <none>        888/TCP   3m5s陈述式删除(命令行)
[root@ceshi-130 ~]# kubectl delete svc nginx-ljx
service "nginx-ljx" deleted
声明式删除(yaml/json)
[root@ceshi-130 ~]# kubectl delete -f nginx-ljx.yaml
