redis7.x源码分析:(3) dict字典

dict字典采用经典hash表数据结构实现，由键值对组成，类似于C++中的unordered_map。两者在代码实现层面存在一些差异，比如gnustl的unordered_map分配的桶数组个数是（质数n），而dict分配的桶数组个数是（2^n）；另外，dict对hash值相同的key采用了常规的开链法存储，而unordered_map在采用开链法的前提下，又使用了_M_before_begin将不同桶中的链表串联成了一个大链表，从而将遍历速度优化为O(n)；还有就是，dict为应对服务器性能上的特殊要求，设计成了双hash表的形式，这也使得它的rehash等操作存在一些特殊性。

dict在redis里面的用途十分广泛，几乎所有的模块都会用到，其中的两大核心用途是：
 1. 16个数据库空间
 2. hash和zset类型数据的存储

dict相关结构定义：

// 节点
typedef struct dictEntry {// 任意类型键void *key;// 存储的值union {void *val;uint64_t u64;int64_t s64;double d;} v;// 同一个桶中链表的下一个元素struct dictEntry *next;     /* Next entry in the same hash bucket. */void *metadata[];           /* An arbitrary number of bytes (starting at a* pointer-aligned address) of size as returned* by dictType's dictEntryMetadataBytes(). */
} dictEntry;typedef struct dict dict;// 存储不同类型数据的字典，设置不同的处理函数
typedef struct dictType {uint64_t (*hashFunction)(const void *key);void *(*keyDup)(dict *d, const void *key);void *(*valDup)(dict *d, const void *obj);int (*keyCompare)(dict *d, const void *key1, const void *key2);void (*keyDestructor)(dict *d, void *key);void (*valDestructor)(dict *d, void *obj);int (*expandAllowed)(size_t moreMem, double usedRatio);/* Allow a dictEntry to carry extra caller-defined metadata.  The* extra memory is initialized to 0 when a dictEntry is allocated. */size_t (*dictEntryMetadataBytes)(dict *d);
} dictType;#define DICTHT_SIZE(exp) ((exp) == -1 ? 0 : (unsigned long)1<<(exp))
#define DICTHT_SIZE_MASK(exp) ((exp) == -1 ? 0 : (DICTHT_SIZE(exp))-1)struct dict {// 字典类型，不同的类型有不同的hash函数，dup函数dictType *type;// 双哈希表指针数组dictEntry **ht_table[2];// 存放的节点数unsigned long ht_used[2];// rehash索引（哈希表的下标），大于 -1 表示正在rehashlong rehashidx; /* rehashing not in progress if rehashidx == -1 *//* Keep small vars at end for optimal (minimal) struct padding */// rehash暂停标志int16_t pauserehash; /* If >0 rehashing is paused (<0 indicates coding error) */// 表示2的多少次幂，哈希表的大小=2^ht_size_expsigned char ht_size_exp[2]; /* exponent of size. (size = 1<<exp) */
};

hash表的创建比较简单直接略过，先看下 _dictExpand 的实现，它在hash表扩容缩容和创建时都会用到。当添加dictAdd时，存储的节点数 used / size >= 1，就需要调用它扩容。

int _dictExpand(dict *d, unsigned long size, int* malloc_failed)
{if (malloc_failed) *malloc_failed = 0;/* the size is invalid if it is smaller than the number of* elements already inside the hash table */// 正在rehash或者 used / size > 1直接退出if (dictIsRehashing(d) || d->ht_used[0] > size)return DICT_ERR;/* the new hash table */dictEntry **new_ht_table;unsigned long new_ht_used;// 获取第一个 2^N > size 的N的大小signed char new_ht_size_exp = _dictNextExp(size);/* Detect overflows */// 2^N 作为hash数组的长度, 另外判断分配的大小是否合法size_t newsize = 1ul<<new_ht_size_exp;if (newsize < size || newsize * sizeof(dictEntry*) < newsize)return DICT_ERR;/* Rehashing to the same table size is not useful. */if (new_ht_size_exp == d->ht_size_exp[0]) return DICT_ERR;/* Allocate the new hash table and initialize all pointers to NULL */if (malloc_failed) {new_ht_table = ztrycalloc(newsize*sizeof(dictEntry*));*malloc_failed = new_ht_table == NULL;if (*malloc_failed)return DICT_ERR;} elsenew_ht_table = zcalloc(newsize*sizeof(dictEntry*));new_ht_used = 0;/* Is this the first initialization? If so it's not really a rehashing* we just set the first hash table so that it can accept keys. */// 如果是第一次创建hash表,则设置完第一个表后直接退出if (d->ht_table[0] == NULL) {d->ht_size_exp[0] = new_ht_size_exp;d->ht_used[0] = new_ht_used;d->ht_table[0] = new_ht_table;return DICT_OK;}/* Prepare a second hash table for incremental rehashing */// 设置第二个表后退出,并且开始rehashd->ht_size_exp[1] = new_ht_size_exp;d->ht_used[1] = new_ht_used;d->ht_table[1] = new_ht_table;d->rehashidx = 0;return DICT_OK;
}

// 检查是否需要缩容
int htNeedsResize(dict *dict) {long long size, used;// 哈希表大小size = dictSlots(dict);// 哈希表已用节点数量used = dictSize(dict);// 当哈希表的大小大于 > 4 并且用量小于 10%时缩容return (size && used && size > DICT_HT_INITIAL_SIZE &&(used*100/size < REDIS_HT_MINFILL));
}

在执行databasesCron时，如果数据库满足 htNeedsResize 会进行缩容，另外hash和zset类型数据在执行删除操作时，也会判断是否需要缩容。

扩容缩容都会触发开启rehash，最终调用 dictRehash 实现rehash的动作，以下是它的代码：

int dictRehash(dict *d, int n) {// 累计访问多少个空桶后退出rehashint empty_visits = n*10; /* Max number of empty buckets to visit. */if (!dictIsRehashing(d)) return 0;// 进行n次rehashwhile(n-- && d->ht_used[0] != 0) {dictEntry *de, *nextde;/* Note that rehashidx can't overflow as we are sure there are more* elements because ht[0].used != 0 */assert(DICTHT_SIZE(d->ht_size_exp[0]) > (unsigned long)d->rehashidx);while(d->ht_table[0][d->rehashidx] == NULL) {// 遇到空桶, 索引后移d->rehashidx++;if (--empty_visits == 0) return 1;}// 得到桶中链表第一个节点de = d->ht_table[0][d->rehashidx];/* Move all the keys in this bucket from the old to the new hash HT */// 遍历链表上所有的节点, 添加到hash表2中while(de) {uint64_t h;nextde = de->next;/* Get the index in the new hash table */// 计算hash值对应的索引 = hash & (2^exp - 1)h = dictHashKey(d, de->key) & DICTHT_SIZE_MASK(d->ht_size_exp[1]);// 添加到hash表2中de->next = d->ht_table[1][h];d->ht_table[1][h] = de;d->ht_used[0]--;d->ht_used[1]++;de = nextde;}// 清空hash表1的桶d->ht_table[0][d->rehashidx] = NULL;d->rehashidx++;}/* Check if we already rehashed the whole table... */// 如果rehash全部完成了, 则用表2替换表1, 并且释放原来的表1if (d->ht_used[0] == 0) {zfree(d->ht_table[0]);/* Copy the new ht onto the old one */d->ht_table[0] = d->ht_table[1];d->ht_used[0] = d->ht_used[1];d->ht_size_exp[0] = d->ht_size_exp[1];_dictReset(d, 1);d->rehashidx = -1;return 0;}/* More to rehash... */return 1;
}// 执行多少毫秒的rehash操作
int dictRehashMilliseconds(dict *d, int ms) {if (d->pauserehash > 0) return 0;long long start = timeInMilliseconds();int rehashes = 0;// 还没超时的情况下，一次尝试执行100个桶的rehashwhile(dictRehash(d,100)) {rehashes += 100;if (timeInMilliseconds()-start > ms) break;}return rehashes;
}

再分别看一下 dictAddRaw、dictGenericDelete、dictFind的代码：

/* Low level add or find:* This function adds the entry but instead of setting a value returns the* dictEntry structure to the user, that will make sure to fill the value* field as they wish.** This function is also directly exposed to the user API to be called* mainly in order to store non-pointers inside the hash value, example:** entry = dictAddRaw(dict,mykey,NULL);* if (entry != NULL) dictSetSignedIntegerVal(entry,1000);** Return values:** If key already exists NULL is returned, and "*existing" is populated* with the existing entry if existing is not NULL.** If key was added, the hash entry is returned to be manipulated by the caller.*/
dictEntry *dictAddRaw(dict *d, void *key, dictEntry **existing)
{long index;dictEntry *entry;int htidx;// 正在rehash过程中，则执行一次rehash操作（只把老表中一个桶对应链表内的数据节点重新hash到新表的不同桶中）if (dictIsRehashing(d)) _dictRehashStep(d);/* Get the index of the new element, or -1 if* the element already exists. */// 获取新节点用的数组索引if ((index = _dictKeyIndex(d, key, dictHashKey(d,key), existing)) == -1)return NULL;/* Allocate the memory and store the new entry.* Insert the element in top, with the assumption that in a database* system it is more likely that recently added entries are accessed* more frequently. */// 如果在rehash的话，新节点只会加到第二个哈希表中htidx = dictIsRehashing(d) ? 1 : 0;size_t metasize = dictMetadataSize(d);entry = zmalloc(sizeof(*entry) + metasize);if (metasize > 0) {memset(dictMetadata(entry), 0, metasize);}// 新节点添加到链表头entry->next = d->ht_table[htidx][index];d->ht_table[htidx][index] = entry;d->ht_used[htidx]++;/* Set the hash entry fields. */// 设置新节点的key, 如果设置了 type->KeyDup 函数, 则复制出一个key的副本保存到节点中dictSetKey(d, entry, key);return entry;
}/* Search and remove an element. This is a helper function for* dictDelete() and dictUnlink(), please check the top comment* of those functions. */
static dictEntry *dictGenericDelete(dict *d, const void *key, int nofree) {uint64_t h, idx;dictEntry *he, *prevHe;int table;/* dict is empty */if (dictSize(d) == 0) return NULL;// 正在rehash过程中，则执行一次rehash操作if (dictIsRehashing(d)) _dictRehashStep(d);h = dictHashKey(d, key);// 在hash表1和2中查找for (table = 0; table <= 1; table++) {// 计算索引获取桶中链表节点idx = h & DICTHT_SIZE_MASK(d->ht_size_exp[table]);he = d->ht_table[table][idx];prevHe = NULL;while(he) {// 遍历链表找到对应key的节点并删除if (key==he->key || dictCompareKeys(d, key, he->key)) {/* Unlink the element from the list */if (prevHe)prevHe->next = he->next;elsed->ht_table[table][idx] = he->next;if (!nofree) {// 释放节点中key/valuedictFreeUnlinkedEntry(d, he);}d->ht_used[table]--;return he;}prevHe = he;he = he->next;}if (!dictIsRehashing(d)) break;}return NULL; /* not found */
}dictEntry *dictFind(dict *d, const void *key)
{dictEntry *he;uint64_t h, idx, table;if (dictSize(d) == 0) return NULL; /* dict is empty */// 执行一次rehashif (dictIsRehashing(d)) _dictRehashStep(d);h = dictHashKey(d, key);// 在hash表1和2中查找for (table = 0; table <= 1; table++) {idx = h & DICTHT_SIZE_MASK(d->ht_size_exp[table]);he = d->ht_table[table][idx];while(he) {if (key==he->key || dictCompareKeys(d, key, he->key))return he;he = he->next;}if (!dictIsRehashing(d)) return NULL;}return NULL;
}

dict的rehash并不是一次完成的，这个是基于性能、响应时间上的考虑。会执行rehash有以下几个函数：

• databasesCron函数，它会定时执行，对16个db中的dict和expires进行rehash，每次调用dictRehashMilliseconds执行1ms时间
• dictAddRaw、dictGenericDelete、dictFind、dictGetRandomKey、dictGetSomeKeys函数，它们每次rehash只处理一个桶

最后看下迭代器的定义：

/* If safe is set to 1 this is a safe iterator, that means, you can call* dictAdd, dictFind, and other functions against the dictionary even while* iterating. Otherwise it is a non safe iterator, and only dictNext()* should be called while iterating. */
typedef struct dictIterator {// 迭代器对应的字典dict *d;// 正在迭代的hash索引long index;// table表示迭代的表是两张表中的哪一张；safe表示是否是安全迭代器int table, safe;// entry表示迭代器当前的节点；nextEntry表示下个节点dictEntry *entry, *nextEntry;/* unsafe iterator fingerprint for misuse detection. */// 指纹，判断迭代过程中有没执行被禁止的操作（dictNext以外的函数）unsigned long long fingerprint;
} dictIterator;

迭代器分为安全和不安全迭代器：

• 安全迭代器，针对字典可以执行 dictAdd 等有可能修改的函数
• 不安全迭代器，针对字典只能执行 dictNext

迭代的实现：

dictEntry *dictNext(dictIterator *iter)
{while (1) {if (iter->entry == NULL) {// 第一个迭代或者桶中的链表遍历完了if (iter->index == -1 && iter->table == 0) {// 安全模式暂停rehashif (iter->safe)dictPauseRehashing(iter->d);elseiter->fingerprint = dictFingerprint(iter->d);}// 依次轮询两张hash表，查找非空节点iter->index++;if (iter->index >= (long) DICTHT_SIZE(iter->d->ht_size_exp[iter->table])) {if (dictIsRehashing(iter->d) && iter->table == 0) {iter->table++;iter->index = 0;} else {break;}}iter->entry = iter->d->ht_table[iter->table][iter->index];} else {// 取当前节点的下一个节点iter->entry = iter->nextEntry;}if (iter->entry) {// 如果不为空，返回当前节点，保存下个节点/* We need to save the 'next' here, the iterator user* may delete the entry we are returning. */iter->nextEntry = iter->entry->next;return iter->entry;}}return NULL;
}
