SpringCloud 微服务消息队列灰度方案 (RocketMQ 4.x)

背景

• 我们公司团队为了更好地控制版本发布的影响范围，自研了灰度发布流程，目前已经支持http、gRPC等接口调用方式进行灰度流量转发，但是消息队列基于业务实现展示不支持。
• 参考了网上很多灰度方案博文，比较热门的vivo鲁班RocketMQ的文章，但是涉及到的改造范围都是比较大，最后在看到关于Asyncer关于灰度分区 的博文，整体比较巧妙的利用MQ的原有机制，改动相对少了很多

遇到的问题

如上图所示普通的业务灰度流程，保证了RPC服务之间的调用灰度，但是当消息从服务发出到消息队列后，队列分区是被均分到正常服务和灰度服务监听的；这样会导致正常服务消费到灰度消息；同时灰度服务消费到正常的消息；所以MQ灰度是目前需要解决的问题，这样才能完成整个灰度链路；

RocketMQ 基础

基础消息模型

扩展后的消息模型

• 相同的ConsumerGroup下的消费者主要有两种负载均衡模式，即广播模式，和集群模式（图中是最常用的集群模式）。
• 在集群模式下，同一个 ConsumerGroup 中的 Consumer 实例是负载均衡消费，如图中 ConsumerGroupA 订阅 TopicA，TopicA 对应 3个队列，则 GroupA 中的 Consumer1 消费的是 MessageQueue 0和 MessageQueue 1的消息，Consumer2是消费的是MessageQueue2的消息。
• 在广播模式下，同一个 ConsumerGroup 中的每个 Consumer 实例都处理全部的队列。需要注意的是，广播模式下因为每个 Consumer 实例都需要处理全部的消息，因此这种模式仅推荐在通知推送、配置同步类小流量场景使用。

部署模型

Producer、Consumer又是如何找到Topic和Broker的地址呢？消息的具体发送和接收又是怎么进行的呢？

RocketMQ 部署架构上主要分为四部分:

• 生产者 Producer

  • 发布消息的角色。Producer通过 MQ 的负载均衡模块选择相应的 Broker 集群队列进行消息投递，投递的过程支持快速失败和重试。

• 消费者 Consumer

  • 消息消费的角色
  • 支持以推（push），拉（pull）两种模式对消息进行消费。
  • 同时也支持集群方式和广播方式的消费。
  • 提供实时消息订阅机制，可以满足大多数用户的需求。

• 名字服务器 NameServer

  • NameServer是一个简单的 Topic 路由注册中心，支持 Topic、Broker 的动态注册与发现。
    • Broker管理，NameServer接受Broker集群的注册信息并且保存下来作为路由信息的基本数据。然后提供心跳检测机制，检查Broker是否还存活；
    • 路由信息管理，每个NameServer将保存关于 Broker 集群的整个路由信息和用于客户端查询的队列信息。Producer和Consumer通过NameServer就可以知道整个Broker集群的路由信息，从而进行消息的投递和消费。

• 代理服务器 Broker

  • Broker主要负责消息的存储、投递和查询以及服务高可用保证。
  • NameServer几乎无状态节点，因此可集群部署，节点之间无任何信息同步。Broker部署相对复杂。
    • 每个 Broker 与 NameServer 集群中的所有节点建立长连接，定时注册 Topic 信息到所有 NameServer。
    • Producer 与 NameServer 集群中的其中一个节点建立长连接，定期从 NameServer 获取Topic路由信息，并向提供 Topic 服务的 Master 建立长连接，且定时向 Master 发送心跳。Producer 完全无状态。
    • Consumer 与 NameServer 集群中的其中一个节点建立长连接，定期从 NameServer 获取 Topic 路由信息，并向提供 Topic 服务的 Master、Slave 建立长连接，且定时向 Master、Slave发送心跳。Consumer 既可以从 Master 订阅消息，也可以从Slave订阅消息。

相关概念点

• CommitLog：消息体实际存储的地方，当我们发送的任一业务消息的时候，它最终会存储在commitLog上。MQ在Broker进行集群部署（这里为也简洁，不涉及主从部分）时，同一业务消息只会落到集群的某一个Broker节点上。而这个Broker上的commitLog就会存储所有Topic路由到它的消息，当消息数据量到达1个G后会重新生成一个新的commitLog。
• Topic：消息主题，表示一类消息的逻辑集合。每条消息只属于一个Topic，Topic中包含多条消息，是MQ进行消息发送订阅的基本单位。属于一级消息类型，偏重于业务逻辑设计。
• Tag：消息标签，二级消息类型，每一个具体的消息都可以选择性地附带一个Tag，用于区分同一个Topic中的消息类型
• Queue：实际上Topic更像是一个逻辑概念供我们使用，在源码层级看，Topic以Queue的形式分布在多个Broker上，一个topic往往包含多条Queue
• 消费组及其ID：表示一类Producer或Consumer，这类Producer或Consumer通常生产或消费同应用域的消息，且消息生产与消费的逻辑一致。每个消费组可以定义全局维一的GroupID来标识，由它来代表消费组。不同的消费组在消费时互相隔离，不会影响彼此的消费位点计算。

方案对比

影子Topic的方案

• 新建一系列新的Topic来处理隔离灰度的消息
  • 例如对于TOPIC_ORDER会创建TOPIC_ORDER_GRAY来给灰度环境使用。
• 发送方在发送时，对灰度的消息写入到影子Topic中。消费时，灰度环境只使用灰度的分组订阅灰度的Topic。

Tag的方案

• 发送方在发送时，对灰度环境产生的消息的Tag加灰度标识。
• 消费方，每次灰度版本发布时只订阅灰度Tag的消息，正常的版本订阅非灰度的Tag。

UserProperty的方案

• 发送方在发送时，对灰度环境产生的消息的UserProperty加灰度标识。
• 消费方的客户端需要进行改写，根据UserProperty来过滤，正常的版本会跳过这类消息，灰度的版本会处理灰度消息。
• 流程与灰度Tag差不错

影子Group的方案

• 发送消息：灰度的服务发送带有灰度标识的消息
• 消费消息：灰度服务只消费灰度标识的消息


灰度分区的方案

• 发送者注册时会检测当前将是不是灰度节点，灰度节点MQ注册的clientId会添加标识
• 消费者订阅时会检测当前节点是不是灰度节点，灰度节点会走灰度的Queue分配策略

方案对比

方案	优点	缺点	成本
影子Topic的方案	使用独立的两个TOPIC,订阅关系一致，改造比较容易	有临界问题，灰度切换生产时有可能会漏掉消息；同时需要根据生产、消费者关系维护对应的订阅关系；改造数据需求	需要维护两套消费组和TOPC,有维护成本
影子Group的方案	使用独立的两个GROUP，订阅关系一致	有临界问题；需要修改生产者、订阅者、DevOps改动范围较大；正常节点和灰度节点都需要知道当前服务的灰度状态，来做出对应的处理	需要维护两套GROUP的关系，维护成本高
Tag的方案	通过MQ提供的tag机制过滤，可以保证灰度的消息只会被灰度节点消费，改造简单；	如果Tag参与的业务过滤，不适合该方案；如果没有灰度节点订阅关系不一致，会出现消息丢失	无
UserProperty的方案	同上	同上	同上
灰度分区的方案	订阅关系一致，不需要额外维护多一套TOPIC、GROUP;	无（比较适合公司的一个运营模式）	无

灰度分区方案设计

灰度分区主要基于以下几点：

• DevOps：灰度服务的Pod容器内部会有 CANARY_RELEASE：true 的环境变量。
• MQ客户端心跳上报：源码中，RocketMQ客户端启动时会想向所有产生订阅关系的broker发送心跳，心跳中带有clientId,该值主要由实例名、容器ip等组成，可以利用canary环境变量做一层额外的注入
• MQ客户端重平衡：源码中，每隔20秒/客户端上下线，都会触发一次客户端重平衡；我们可以自定义该策略，加入灰度分区平衡逻辑，来实现灰度分区和正常分区的订阅
• MQ客户端发送方：源码中，RocketMQ发送方每次发送消息都会轮询队列发送，同时加入重试和故障规避的策略，可以通过重写该类来做扩展。

适配只有部分灰度的情况所做的功能扩展

• 基于ThreadLocal来实现消费和发送的链路标识传递
  • 拦截HTTP请求：通过拦截http请求识别请求是否灰度，基于ThreadLocal实现线程传递；
  • 拦截MQ消息消费：通过拦截消费者消息，识别UserProperty识别存在灰度标识；更新到ThreadLocal中
  • 拦截MQ生产者发送消息：获取ThreadLocal存储的当前线程的UserProperty标识,写入到发送消息的UserProperty中
• MQ客户端发送方：检测到环境和线程链路变量，做出对应的发送策略；从而来实现灰度消息通过正常应用后，发送MQ消息能被下级监听的灰度应用接收；

消费者（无灰度）

消费者（有灰度）

改造流程

生产者改造逻辑

无论何时，只要发送方自己当前环境是灰度(CANARY_RELEASE=true)或者当前是灰度链路，则会最后两个分区作为灰度队列,否则选取其他分区发送，根据RocketMQ的源码,自定义发送策略即可实现。

import org.apache.rocketmq.client.common.ThreadLocalIndex;
import org.apache.rocketmq.client.impl.producer.TopicPublishInfo;
import org.apache.rocketmq.client.latency.LatencyFaultTolerance;
import org.apache.rocketmq.client.latency.LatencyFaultToleranceImpl;
import org.apache.rocketmq.client.log.ClientLogger;
import org.apache.rocketmq.common.message.MessageQueue;
import org.apache.rocketmq.logging.InternalLogger;import java.util.Collections;
import java.util.List;
import java.util.concurrent.ConcurrentHashMap;/*** Custom fault strategy*/
public class CustomMQFaultStrategy {private final InternalLogger log = ClientLogger.getLog();private final LatencyFaultTolerance<String> latencyFaultTolerance = new LatencyFaultToleranceImpl();private boolean sendLatencyFaultEnable = false;private long[] latencyMax = {50L, 100L, 550L, 1000L, 2000L, 3000L, 15000L};private long[] notAvailableDuration = {0L, 0L, 30000L, 60000L, 120000L, 180000L, 600000L};private final ConcurrentHashMap<TopicPublishInfo, TopicPublishInfoCache> topicPublishInfoCacheTable = new ConcurrentHashMap<>();public long[] getNotAvailableDuration() {return notAvailableDuration;}public void setNotAvailableDuration(final long[] notAvailableDuration) {this.notAvailableDuration = notAvailableDuration;}public long[] getLatencyMax() {return latencyMax;}public void setLatencyMax(final long[] latencyMax) {this.latencyMax = latencyMax;}public boolean isSendLatencyFaultEnable() {return sendLatencyFaultEnable;}public void setSendLatencyFaultEnable(final boolean sendLatencyFaultEnable) {this.sendLatencyFaultEnable = sendLatencyFaultEnable;}private TopicPublishInfoCache checkCacheChanged(TopicPublishInfo topicPublishInfo) {if (topicPublishInfoCacheTable.containsKey(topicPublishInfo)) {return topicPublishInfoCacheTable.get(topicPublishInfo);}synchronized (this) {TopicPublishInfoCache cache = new TopicPublishInfoCache();List<MessageQueue> canaryQueues = MessageStorage.getCanaryQueues(topicPublishInfo.getMessageQueueList());List<MessageQueue> normalQueues = MessageStorage.getNormalQueues(topicPublishInfo.getMessageQueueList());Collections.sort(canaryQueues);Collections.sort(normalQueues);cache.setCanaryQueueList(canaryQueues);cache.setNormalQueueList(normalQueues);topicPublishInfoCacheTable.putIfAbsent(topicPublishInfo, cache);}return topicPublishInfoCacheTable.get(topicPublishInfo);}/*** Queue selection strategy*/public MessageQueue selectOneMessageQueue(final TopicPublishInfo tpInfo, final String lastBrokerName) {List<MessageQueue> messageQueueList = tpInfo.getMessageQueueList();TopicPublishInfoCache topicPublishInfoCache = checkCacheChanged(tpInfo);if (MessageStorage.isCanaryRelease() || MessageStorage.isThreadCanaryRelease()) {MessageQueue messageQueue = selectDefaultMessageQueue(tpInfo, lastBrokerName, topicPublishInfoCache.getCanaryQueueList());log.debug("canary context,send message to canary queue:{}", messageQueue.getBrokerName() + messageQueue.getQueueId());return messageQueue;} else {if (this.sendLatencyFaultEnable) {try {int index = tpInfo.getSendWhichQueue().incrementAndGet();int size = topicPublishInfoCache.getNormalQueueList().size();for (int i = 0; i < size; i++) {int pos = Math.max(Math.abs(index++) % size, 0);MessageQueue mq = topicPublishInfoCache.getNormalQueueList().get(pos);if (latencyFaultTolerance.isAvailable(mq.getBrokerName())) {return mq;}}final String notBestBroker = latencyFaultTolerance.pickOneAtLeast();int writeQueueNums = tpInfo.getQueueIdByBroker(notBestBroker);if (writeQueueNums > 0) {final MessageQueue mq = tpInfo.selectOneMessageQueue();if (!topicPublishInfoCache.getCanaryQueueList().contains(mq)) {if (notBestBroker != null) {mq.setBrokerName(notBestBroker);mq.setQueueId(tpInfo.getSendWhichQueue().incrementAndGet() % writeQueueNums);}return mq;}} else {latencyFaultTolerance.remove(notBestBroker);}} catch (Exception e) {log.error("Error occurred when selecting message queue", e);}}return selectDefaultMessageQueue(tpInfo, lastBrokerName, topicPublishInfoCache.getNormalQueueList());}}/*** Default message queue selection strategy** @param topicPublishInfo* @param lastBrokerName* @param queues* @return {@link MessageQueue }*/private MessageQueue selectDefaultMessageQueue(final TopicPublishInfo topicPublishInfo, final String lastBrokerName,List<MessageQueue> queues) {ThreadLocalIndex sendWhichQueue = topicPublishInfo.getSendWhichQueue();int size = queues.size();if (lastBrokerName != null) {for (int i = 0; i < size; i++) {int index = sendWhichQueue.incrementAndGet();int pos = Math.max(Math.abs(index) % size, 0);MessageQueue mq = queues.get(pos);if (!mq.getBrokerName().equals(lastBrokerName)) {return mq;}}}int i = sendWhichQueue.incrementAndGet();int res = Math.max(Math.abs(i) % size, 0);log.debug("selectDefaultMessageQueue, lastBrokerName:{}, res:{}", lastBrokerName, topicPublishInfo.getMessageQueueList().get(res));return queues.get(res);}public void updateFaultItem(final String brokerName, final long currentLatency, boolean isolation) {if (this.sendLatencyFaultEnable) {long duration = computeNotAvailableDuration(isolation ? 30000 : currentLatency);this.latencyFaultTolerance.updateFaultItem(brokerName, currentLatency, duration);}}private long computeNotAvailableDuration(final long currentLatency) {for (int i = latencyMax.length - 1; i >= 0; i--) {if (currentLatency >= latencyMax[i]) {return this.notAvailableDuration[i];}}return 0;}/*** Cache of topic publish info*/private static class TopicPublishInfoCache {/*** Grayscale message queue list*/private List<MessageQueue> canaryQueueList;private List<MessageQueue> normalQueueList;public List<MessageQueue> getCanaryQueueList() {return canaryQueueList;}public void setCanaryQueueList(List<MessageQueue> canaryQueueList) {this.canaryQueueList = canaryQueueList;}public List<MessageQueue> getNormalQueueList() {return normalQueueList;}public void setNormalQueueList(List<MessageQueue> normalQueueList) {this.normalQueueList = normalQueueList;}}
}

消费者改造逻辑

• 其实最大的问题在于消费方如何动态的感知灰度的状态流转，这也是产生之前灰度分区方案的临界问题的根本原因。但是通过源码的深入探索，发现其实我们可以通过改造ClientId和自定义负载均衡策略来实现；

• RocketMQ客户端启动的时候，会构建本地客户端id(包括实例名、ip名等)，然后向broker注册自己。我们可以通过DevOps注入的环境变量CANARY_RELEASE来做改造，即灰度服务clientId后面追加canary表示，default服务后面追加default标识；

消费者自定义负载均衡

import com.alibaba.fastjson.JSON;
import org.apache.commons.collections.CollectionUtils;
import org.apache.commons.lang3.StringUtils;
import org.apache.rocketmq.client.consumer.AllocateMessageQueueStrategy;
import org.apache.rocketmq.client.log.ClientLogger;
import org.apache.rocketmq.common.MixAll;
import org.apache.rocketmq.common.message.MessageQueue;
import org.apache.rocketmq.logging.InternalLogger;import java.util.ArrayList;
import java.util.Collections;
import java.util.List;public class CanaryAllocateMessageQueueStrategyImpl implements AllocateMessageQueueStrategy {private final InternalLogger log = ClientLogger.getLog();@Overridepublic List<MessageQueue> allocate(String consumerGroup, String currentCID, List<MessageQueue> mqAll, List<String> cidAll) {log.info("consumerGroup:{} currentCID:{} cidAll:{}",consumerGroup,currentCID, JSON.toJSONString(cidAll));if (!check(consumerGroup, currentCID, mqAll, cidAll)) {return Collections.emptyList();}if (mqAll.stream().anyMatch(mq -> mq.getTopic().startsWith(MixAll.RETRY_GROUP_TOPIC_PREFIX))) {return allocateByAvg(consumerGroup, currentCID, mqAll, cidAll);}if (!MessageStorage.hasCanaryRelease(cidAll)) {List<MessageQueue> allocate = allocateByAvg(consumerGroup, currentCID, mqAll, cidAll);return allocate;}if (MessageStorage.allCanaryRelease(cidAll)) {List<MessageQueue> messageQueues = this.balanceAllocate(consumerGroup, currentCID, mqAll, cidAll);log.info("[canary allocate]: group:{} sub topic:{} has all canary release client,maybe the sub is new,use the default avg strategy.\n" +"current cid:{}\n" +"allocate total {} message queue\n" +"result:\n{}",consumerGroup,mqAll.get(0).getTopic(),messageQueues.size(),currentCID,MessageStorage.joinMessageQueue(messageQueues));return messageQueues;}List<String> canaryCids = MessageStorage.getCanaryCids(cidAll);List<String> normalCids = MessageStorage.getNormalCids(cidAll);List<MessageQueue> canaryQueues = MessageStorage.getCanaryQueues(mqAll);List<MessageQueue> normalQueues = MessageStorage.getNormalQueues(mqAll);Collections.sort(canaryCids);Collections.sort(normalCids);Collections.sort(normalQueues);Collections.sort(canaryQueues);List<MessageQueue> result = null;if (canaryCids.contains(currentCID)) {result = allocateByAvg(consumerGroup, currentCID, canaryQueues, canaryCids);} else {result = allocateByAvg(consumerGroup, currentCID, normalQueues, normalCids);}return result;}/*** @param consumerGroup* @param currentCID* @param mqAll* @param cidAll* @return {@link List }<{@link MessageQueue }>*/private List<MessageQueue> allocateByAvg(String consumerGroup, String currentCID, List<MessageQueue> mqAll,List<String> cidAll) {List<MessageQueue> result = new ArrayList<MessageQueue>();if (!check(consumerGroup, currentCID, mqAll, cidAll)) {return result;}int index = cidAll.indexOf(currentCID);int mod = mqAll.size() % cidAll.size();int averageSize =mqAll.size() <= cidAll.size() ? 1 : (mod > 0 && index < mod ? mqAll.size() / cidAll.size()+ 1 : mqAll.size() / cidAll.size());int startIndex = (mod > 0 && index < mod) ? index * averageSize : index * averageSize + mod;int range = Math.min(averageSize, mqAll.size() - startIndex);for (int i = 0; i < range; i++) {result.add(mqAll.get((startIndex + i) % mqAll.size()));}return result;}@Overridepublic String getName() {return "CANARY";}public boolean check(String consumerGroup, String currentCID, List<MessageQueue> mqAll,List<String> cidAll) {if (StringUtils.isEmpty(currentCID)) {throw new IllegalArgumentException("currentCID is empty");}if (CollectionUtils.isEmpty(mqAll)) {throw new IllegalArgumentException("mqAll is null or mqAll empty");}if (CollectionUtils.isEmpty(cidAll)) {throw new IllegalArgumentException("cidAll is null or cidAll empty");}if (!cidAll.contains(currentCID)) {log.info("[BUG] ConsumerGroup: {} The consumerId: {} not in cidAll: {}",consumerGroup,currentCID,cidAll);return false;}return true;}public List<MessageQueue> balanceAllocate(String consumerGroup, String currentCID, List<MessageQueue> mqAll, List<String> cidAll) {List<MessageQueue> result = new ArrayList<MessageQueue>();if (!check(consumerGroup, currentCID, mqAll, cidAll)) {return result;}int index = cidAll.indexOf(currentCID);int mod = mqAll.size() % cidAll.size();int averageSize =mqAll.size() <= cidAll.size() ? 1 : (mod > 0 && index < mod ? mqAll.size() / cidAll.size()+ 1 : mqAll.size() / cidAll.size());int startIndex = (mod > 0 && index < mod) ? index * averageSize : index * averageSize + mod;int range = Math.min(averageSize, mqAll.size() - startIndex);for (int i = 0; i < range; i++) {result.add(mqAll.get((startIndex + i) % mqAll.size()));}return result;}
}

MQ注册ClientID修改

    public String buildMQClientId() {StringBuilder sb = new StringBuilder();sb.append(this.getClientIP());sb.append("@");sb.append(this.getInstanceName());if (!UtilAll.isBlank(this.unitName)) {sb.append("@");sb.append(this.unitName);}//The key is hereif (MessageStorage.isCanaryRelease()) {sb.append(CustomCommonConstant.CANARY_RELEASE_PREFIX);} else {sb.append("@default");}if (this.enableStreamRequestType) {sb.append("@");sb.append(RequestType.STREAM);}return sb.toString();}

常量配置类

public class CustomCommonConstant {/*** Number of grayscale queues*/public static final Integer GRAYSCALE_QUEUE_SIZE = 2;/*** Grayscale client identification*/public static final String CANARY_RELEASE_PREFIX = "@canary";/*** Thread identification*/public static final String THREAD_CANARY_RELEASE = "canary.release";
}

链路信息传递BasicMDC类

import java.util.Collections;
import java.util.HashMap;
import java.util.Map;
import java.util.Set;public class BasicMDC {final ThreadLocal<Map<String, String>> copyOnThreadLocal = new ThreadLocal<>();private static final int WRITE_OPERATION = 1;private static final int MAP_COPY_OPERATION = 2;final ThreadLocal<Integer> lastOperation = new ThreadLocal();private Integer getAndSetLastOperation(int op) {Integer lastOp = (Integer)this.lastOperation.get();this.lastOperation.set(op);return lastOp;}private boolean wasLastOpReadOrNull(Integer lastOp) {return lastOp == null || lastOp == 2;}private Map<String, String> duplicateAndInsertNewMap(Map<String, String> oldMap) {Map<String, String> newMap = Collections.synchronizedMap(new HashMap());if (oldMap != null) {synchronized(oldMap) {newMap.putAll(oldMap);}}this.copyOnThreadLocal.set(newMap);return newMap;}public void put(String key, String val) throws IllegalArgumentException {if (key == null) {throw new IllegalArgumentException("key cannot be null");} else {Map<String, String> oldMap = (Map)this.copyOnThreadLocal.get();Integer lastOp = this.getAndSetLastOperation(1);if (!this.wasLastOpReadOrNull(lastOp) && oldMap != null) {oldMap.put(key, val);} else {Map<String, String> newMap = this.duplicateAndInsertNewMap(oldMap);newMap.put(key, val);}}}public void remove(String key) {if (key != null) {Map<String, String> oldMap = (Map)this.copyOnThreadLocal.get();if (oldMap != null) {Integer lastOp = this.getAndSetLastOperation(1);if (this.wasLastOpReadOrNull(lastOp)) {Map<String, String> newMap = this.duplicateAndInsertNewMap(oldMap);newMap.remove(key);} else {oldMap.remove(key);}}}}public void clear() {this.lastOperation.set(1);this.copyOnThreadLocal.remove();}public String get(String key) {Map<String, String> map = (Map)this.copyOnThreadLocal.get();return map != null && key != null ? (String)map.get(key) : null;}public Map<String, String> getPropertyMap() {this.lastOperation.set(2);return (Map)this.copyOnThreadLocal.get();}public Set<String> getKeys() {Map<String, String> map = this.getPropertyMap();return map != null ? map.keySet() : null;}public Map<String, String> getCopyOfContextMap() {Map<String, String> hashMap = (Map)this.copyOnThreadLocal.get();return hashMap == null ? null : new HashMap(hashMap);}public void setContextMap(Map<String, String> contextMap) {this.lastOperation.set(1);Map<String, String> newMap = Collections.synchronizedMap(new HashMap());newMap.putAll(contextMap);this.copyOnThreadLocal.set(newMap);}
}

MessageStorage类

import com.alibaba.fastjson.JSON;
import org.apache.rocketmq.client.consumer.AllocateMessageQueueStrategy;
import org.apache.rocketmq.client.log.ClientLogger;
import org.apache.rocketmq.common.message.MessageQueue;
import org.apache.rocketmq.logging.InternalLogger;import java.util.ArrayList;
import java.util.Collections;
import java.util.List;
import java.util.Objects;
import java.util.stream.Collectors;/*** Message storage*/
public class MessageStorage {private static final InternalLogger log = ClientLogger.getLog();private static BasicMDC mdcUtils;static {mdcUtils = new BasicMDC();}/*** Determine whether there is a grayscale client** @param cidAll* @return*/public static boolean hasCanaryRelease(List<String> cidAll) {return !getCanaryCids(cidAll).isEmpty();}/*** Determine if all are grayscale clients** @param cidAll* @return*/public static boolean allCanaryRelease(List<String> cidAll) {List<String> canaryCids = getCanaryCids(cidAll);return canaryCids.size() == cidAll.size();}/*** Connect the message queue into a string** @param messageQueues* @return*/public static String joinMessageQueue(List<MessageQueue> messageQueues) {return messageQueues.stream().map(mq -> mq.getBrokerName() + ":" + mq.getQueueId()).collect(Collectors.joining(", "));}/*** Get the list of grayscale clients** @param cidAll* @return*/public static List<String> getCanaryCids(List<String> cidAll) {return cidAll.stream().filter(cid -> cid.contains(CustomCommonConstant.CANARY_RELEASE_PREFIX)).collect(Collectors.toList());}/*** Get a list of non grayscale clients** @param cidAll* @return*/public static List<String> getNormalCids(List<String> cidAll) {return cidAll.stream().filter(cid -> !cid.contains(CustomCommonConstant.CANARY_RELEASE_PREFIX)).collect(Collectors.toList());}/*** Get the list of grayscale queues** @param mqAll* @return*/public static List<MessageQueue> getCanaryQueues(List<MessageQueue> mqAll) {Collections.sort(mqAll);log.info("topic:{} reBalance, has canary release client, allocate {} message queue by canary release strategy.\n", JSON.toJSONString(mqAll));int size = mqAll.size();if (size > CustomCommonConstant.GRAYSCALE_QUEUE_SIZE) {List<MessageQueue> lastTwo = mqAll.subList(size - CustomCommonConstant.GRAYSCALE_QUEUE_SIZE, size);return new ArrayList<>(lastTwo);} else {return new ArrayList<>();}}/*** Get non grayscale queue list** @param mqAll* @return*/public static List<MessageQueue> getNormalQueues(List<MessageQueue> mqAll) {Collections.sort(mqAll);log.info("topic:{} reBalance, has normal release client, allocate {} message queue by canary release strategy.\n", JSON.toJSONString(mqAll));int size = mqAll.size();if (size > CustomCommonConstant.GRAYSCALE_QUEUE_SIZE) {List<MessageQueue> lastTwo = mqAll.subList(0, size - 2);return new ArrayList<>(lastTwo);} else {return new ArrayList<>(mqAll);}}private static volatile String canaryRelease = null;/*** Determine whether it is a grayscale client** @return*/public static boolean isCanaryRelease() {return Boolean.parseBoolean(getCanaryRelease());}/*** Determine whether it is a grayscale client** @return boolean*/public static boolean isThreadCanaryRelease() {String data = mdcUtils.get(CustomCommonConstant.THREAD_CANARY_RELEASE);return Boolean.parseBoolean(data);}/*** Set MDC** @param key* @param value*/public static void setMDC(String key, String value) {mdcUtils.put(key, value);}/*** @param key* @return {@link String }*/public static String getMdcKey(String key) {return mdcUtils.get(key);}/*** Clear MDC*/public static void clearMDC() {mdcUtils.clear();}/*** Replacement strategy** @return {@link AllocateMessageQueueStrategy }*/public static AllocateMessageQueueStrategy getAllocateMessageQueueAveragely(AllocateMessageQueueStrategy allocateMessageQueueStrategy) {
//        if (isCanaryRelease()) {
//            return new CanaryAllocateMessageQueueStrategyImpl();
//        } else {
//            return allocateMessageQueueStrategy;
//        }return new CanaryAllocateMessageQueueStrategyImpl();}private static String getCanaryRelease() {if (Objects.isNull(canaryRelease)) {synchronized (MessageStorage.class) {if (Objects.nonNull(canaryRelease)) {return canaryRelease;}//CANARY_RELEASEString tmpCanaryRelease = System.getProperty("canary.release");if (Objects.isNull(tmpCanaryRelease)) {tmpCanaryRelease = "false";}canaryRelease = tmpCanaryRelease;return canaryRelease;}}return canaryRelease;}
}

拦截配置

消费者拦截

@Component
@Aspect
public class ConsumerAOP {@Pointcut("execution(public * org.apache.rocketmq.client.consumer.listener.*.*(..))")public void aspectConsumer() {}@Before("aspectConsumer()")public void doBefore(JoinPoint joinPoint) {Object[] args = joinPoint.getArgs();for (Object arg : args) {if (arg instanceof List<?>) {List<MessageExt> messageExtList = (List<MessageExt>) arg;for (MessageExt messageExt : messageExtList) {String threadCanaryRelease = messageExt.getProperty(CustomCommonConstant.THREAD_CANARY_RELEASE);if(StringUtils.isEmpty(threadCanaryRelease)){threadCanaryRelease = "false";}MessageStorage.setMDC(CustomCommonConstant.THREAD_CANARY_RELEASE, threadCanaryRelease);}}}}
}

@Component
@Aspect
public class ListenerAOP {@Pointcut("execution(public * org.apache.rocketmq.spring.core.*.*(..))")public void aspectListener(){}@Before("aspectListener()")public void doBefore(JoinPoint joinPoint){Object[] args = joinPoint.getArgs();for (Object arg : args) {if (arg instanceof MessageExt){MessageExt messageExt = (MessageExt) arg;String threadCanaryRelease = messageExt.getProperty(CustomCommonConstant.THREAD_CANARY_RELEASE);if(StringUtils.isEmpty(threadCanaryRelease)){threadCanaryRelease = "false";}MessageStorage.setMDC(CustomCommonConstant.THREAD_CANARY_RELEASE, threadCanaryRelease);}}}
}

生产者拦截

@Component
@Aspect
public class ProducerAOP {@Pointcut("execution(public * org.apache.rocketmq.client.producer.*.*(..))")public void aspectProducer() {}@Before("aspectProducer()")public void doBefore(JoinPoint joinPoint) {Object[] args = joinPoint.getArgs();for (Object arg : args) {if (arg instanceof Message) {Message message = (Message) arg;String threadCanaryRelease = MessageStorage.getMdcKey(CustomCommonConstant.THREAD_CANARY_RELEASE);if(StringUtils.isEmpty(threadCanaryRelease)){threadCanaryRelease = "false";}message.putUserProperty(CustomCommonConstant.THREAD_CANARY_RELEASE, threadCanaryRelease);}}}
}

请求拦截

@Slf4j
@Component
@WebFilter(urlPatterns = "/*", filterName = "requestFilter")
@Order(Integer.MIN_VALUE)
@RequiredArgsConstructor(onConstructor = @__(@Autowired))
public class ForwardFilter implements Filter {@SneakyThrows@Overridepublic void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain) {HttpServletRequest req = (HttpServletRequest) servletRequest;String threadCanaryRelease = req.getHeader("THREAD_CANARY_RELEASE");log.info("attributeNames:{}", JSON.toJSONString(req.getHeaderNames()));if(Objects.nonNull(threadCanaryRelease)){MessageStorage.setMDC(CustomCommonConstant.THREAD_CANARY_RELEASE, "true");}filterChain.doFilter(servletRequest, servletResponse);}
}

验证过程

消费者（未启动灰度订阅）

消费者（灰度订阅）

验证消息链路

发送端

@Slf4j
@RestController
@RequestMapping("/producer")
public class ProducerMessageContrlller {@Autowiredprivate RocketMQTemplate rocketMQTemplate;@PostMapping("/send")public void send(){boolean canaryRelease = MessageStorage.isCanaryRelease();String body = String.format("发送消息,环境:%s", canaryRelease ? "灰度" : "正式");
//        for (Integer i = 0; i < 100; i++) {log.info("发送消息,环境:{}", canaryRelease ? "灰度" : "正式");rocketMQTemplate.convertAndSend("TEST-DATA-MSG", body);
//        }}
}

消费端

@Slf4j
@Service
@RocketMQMessageListener(topic = "TEST-DATA-MSG", consumerGroup = "test-consumer-group")
public class MyConsumer1 implements RocketMQListener<MessageExt> {@Overridepublic void onMessage(MessageExt message) {boolean canaryRelease = MessageStorage.isCanaryRelease();Map<String, String> properties = message.getProperties();log.info("received message: 【{}】 环境:【{}】 配置参数：【{}】 ", new String(message.getBody()),canaryRelease ? "灰度" : "正式",JSON.toJSONString(properties));}
}

发送灰度消息
