使用springboot-3.4.1搭建一个netty服务并且WebSocket消息通知(适用于设备直连操作，以及回复操作)

引入最新版本

<!--websocket-->
<dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-websocket</artifactId>
</dependency>

启动类加入

//netty 协议服务端口启动
NettyTcpHandler.start();

package com.cqcloud.platform.handler;import com.cqcloud.platform.service.IotMqttService;
import com.cqcloud.platform.service.impl.IotMqttServiceImpl;
import org.springframework.stereotype.Component;import io.netty.bootstrap.ServerBootstrap;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.ChannelPipeline;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioServerSocketChannel;/*** @author [e-mail] ✨* @date 💓💕 2022年9月23日 🐬🐇 💓💕*/
@Component
public class NettyTcpHandler {/*** IoT设备协议端口*/private static int PORT = 1883;/*** 使用方法在启动类* 加上 NettyTcpHandler.start();* @throws Exception*/public static void start() throws Exception {final NioEventLoopGroup bossGroup = new NioEventLoopGroup();final NioEventLoopGroup workerGroup = new NioEventLoopGroup();try {ServerBootstrap bootstrap = new ServerBootstrap();// 创建 IotPushService 实例IotMqttService iotPushService = new IotMqttServiceImpl();bootstrap.group(bossGroup, workerGroup).channel(NioServerSocketChannel.class).childHandler(new ChannelInitializer<SocketChannel>() {@Overrideprotected void initChannel(SocketChannel ch) {ChannelPipeline pipeline = ch.pipeline();// 添加处理器，处理所有连接的业务逻辑pipeline.addLast(new TcpMqttServerHandler(iotPushService));}});// 绑定端口并启动ChannelFuture future = bootstrap.bind(PORT).sync();// 等待服务器关闭future.channel().closeFuture().sync();} finally {// 优雅地关闭线程池workerGroup.shutdownGracefully();bossGroup.shutdownGracefully();}}
}

package com.cqcloud.platform.handler;import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import java.util.function.BiConsumer;import cn.hutool.json.JSONObject;
import org.springframework.stereotype.Component;
import lombok.extern.slf4j.Slf4j;/*** @author [e-mail] ✨* @date 💓💕 2022年10月06日 🐬🐇 💓💕*/
@Slf4j
@Component
public class TcpEventHandler {// 使用 BiConsumer 来处理两个参数private final static Map<String, BiConsumer<String, String>> eventActions = new HashMap<>();public void registerEventAction(String eventCode, BiConsumer<String, String> action) {// 动态注册事件处理逻辑eventActions.put(eventCode, action);}public static void handleEvent(String evt, String imei, String reportContent) {// 根据事件类型找到对应的处理逻辑，并执行eventActions.getOrDefault(evt, TcpEventHandler::handleUnknownEvent).accept(imei, reportContent);}private static void handleUnknownEvent(String imei, String reportContent) {// 处理未知事件的逻辑System.out.println("imei: " + imei + ", 报告内容: " + reportContent);}public static void handleAlarm(String imei, String reportContent) {log.info("内容: {}", reportContent);// 获取目标用户列表（包括固定的用户 ID）List<String> targetUsers = buildTargetUsersList();// 构建消息并发送sendAlarmMessage(targetUsers, imei, reportContent);}private static List<String> buildTargetUsersList() {List<String> targetUsers = new ArrayList<>();targetUsers.add("1");targetUsers.add("2");//实际根据业务查询数据targetUsers.add("26967563820859392");return targetUsers;}private static void sendAlarmMessage(List<String> targetUsers, String imei, String reportContent) {// 将目标用户列表转换为逗号分隔的字符串String users = String.join(",", targetUsers);// 构建 JSON 消息JSONObject obj = new JSONObject();obj.set("imei", imei);obj.set("message", reportContent);obj.set("userId", users);// 发送消息WebSocketHandler.sendMessageToUser(users, obj.toString());}
}

package com.cqcloud.platform.handler;import java.util.ArrayList;
import java.util.List;
import java.util.Optional;import com.cqcloud.platform.service.IotMqttService;import io.netty.buffer.ByteBuf;
import io.netty.buffer.Unpooled;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.SimpleChannelInboundHandler;/*** 物联网云平台设备协议* @author [e-mail] ✨* @date 💓💕 2022年9月23日 🐬🐇 💓💕*/
public class TcpMqttServerHandler extends SimpleChannelInboundHandler<ByteBuf>  {// 接口注入private final IotMqttService iotPushService;public TcpMqttServerHandler(IotMqttService iotPushService) {this.iotPushService = iotPushService;}@Overrideprotected void channelRead0(ChannelHandlerContext ctx, ByteBuf in) throws Exception {byte[] byteArray;if (in.readableBytes() <= 0) {in.release();return;}byteArray = new byte[in.readableBytes()];in.readBytes(byteArray);if (byteArray.length <= 0) {in.release();return;}// 将消息传递给 iotPushServiceiotPushService.pushMessageArrived(byteArray);// 下发指令，假设返回的是多个指令List<String> externalValues = extractExternalValue("deviceId");// 转换为十六进制字符串String hexString = bytesToHex(byteArray);System.out.println("来自于物联网云平台设备协议的数据: " + hexString);// 使用 Optional 判断外部值// 使用 Optional 判断外部值，如果不为空则逐一处理每条指令Optional.ofNullable(externalValues).ifPresent(values -> {values.forEach(value -> {// 提取外部数据值并发送System.out.println("来自于物联网云平台设备协议的1885端口的提取外部数据值: " + value);sendResponse(ctx, value);});});}// 辅助方法：将字节数组转换为十六进制字符串private static String bytesToHex(byte[] bytes) {StringBuilder hexString = new StringBuilder();for (byte b : bytes) {String hex = Integer.toHexString(0xFF & b);if (hex.length() == 1) {hexString.append('0'); // 确保每个字节都为两位}hexString.append(hex);}return hexString.toString().toUpperCase(); // 返回大写格式}// 发送响应的统一辅助方法private void sendResponse(ChannelHandlerContext ctx, String hexResponse) {byte[] responseBytes = hexStringToByteArray(hexResponse);ByteBuf responseBuffer = Unpooled.copiedBuffer(responseBytes);ctx.writeAndFlush(responseBuffer);}// 将响应消息转换为字节数组public static byte[] hexStringToByteArray(String s) {int len = s.length();byte[] data = new byte[len / 2];for (int i = 0; i < len; i += 2) {data[i / 2] = (byte) ((Character.digit(s.charAt(i), 16) << 4) + Character.digit(s.charAt(i + 1), 16));}return data;}// 查询数据库当前设备号下需要下发的命令private List<String> extractExternalValue(String deviceId) {//这里自行查询数据库数据库，这里只模拟一个list集合ArrayList<Object> list = new ArrayList<>();// 如果记录不为空，获取最新记录的 externalValuelist.stream().findFirst() // 获取最新的一条记录.map(latestRecord -> {// 处理最新记录的逻辑return ""; // 需要返回的值是 externalValue});// 获取最新的一条记录return null; // 如果没有找到，返回 null}@Overridepublic void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) {// 打印异常堆栈跟踪，便于调试和错误排查cause.printStackTrace();// 关闭当前的通道，释放相关资源ctx.close();}
}

package com.cqcloud.platform.handler;import java.io.IOException;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.CopyOnWriteArraySet;import org.springframework.stereotype.Component;import cn.hutool.json.JSONUtil;
import io.micrometer.common.util.StringUtils;
import jakarta.websocket.OnClose;
import jakarta.websocket.OnError;
import jakarta.websocket.OnMessage;
import jakarta.websocket.OnOpen;
import jakarta.websocket.Session;
import jakarta.websocket.server.PathParam;
import jakarta.websocket.server.ServerEndpoint;/*** @author [e-mail] ✨* @date 💓💕 2022年4月12日 🐬🐇 💓💕*/
@Component
@ServerEndpoint("/websocket/{username}")
public class WebSocketHandler {public static synchronized int getOnlineCount() {return onlineCount;}public static synchronized void addOnlineCount() {WebSocketHandler.onlineCount++;}public static synchronized void subOnlineCount() {WebSocketHandler.onlineCount--;}// 静态变量，用来记录当前在线连接数。应该把它设计成线程安全的。private static int onlineCount = 0;// 根据名字存储websocket对象CopyOnWriteArraySet线程安全set，ConcurrentHashMap线程安全mappublic static Map<String, CopyOnWriteArraySet<WebSocketHandler>> webSocketMap = new ConcurrentHashMap<>();// 与某个客户端的连接会话，需要通过它来给客户端发送数据public Session session;// 心跳时间,长时间没心跳踢掉连接public long heartBeatTime;// 初次连接时间，用于控制连接时间过长，踢掉连接public long beginTime;/*** 用户名称*/public String username;/*** 发送消息* @param username* @param message*/public static void sendMessageToUser(String username, String message) {// 检查用户名是否在 map 中存在if (webSocketMap.containsKey(username)) {// 获取该用户的 WebSocketHandler 集合CopyOnWriteArraySet<WebSocketHandler> userHandlers = webSocketMap.get(username);// 遍历该用户的所有连接（每个用户可能有多个 WebSocket 连接）for (WebSocketHandler handler : userHandlers) {// 通过 WebSocketHandler 实例发送消息handler.sendMessageOne(message, username);}} else {System.out.println("并无在线用户: " + username);}}/*** 连接建立成功调用的方法*/@OnOpenpublic void onOpen(@PathParam("username") String username, Session session) {this.username = username;this.session = session;this.heartBeatTime = System.currentTimeMillis();this.beginTime = System.currentTimeMillis();// 登陆用户必须按照用户id 格式登陆if (!"server".equals(username) && username.split(",").length < 3) {return;}// 将用户添加到websocket，支持单用户多出链接if (webSocketMap.containsKey(username)) {webSocketMap.get(username).add(this);} else {CopyOnWriteArraySet websocketSet = new CopyOnWriteArraySet();websocketSet.add(this);webSocketMap.put(username, websocketSet);addOnlineCount(); // 在线数加1}//注释掉 会退出Map<String, Object> messageMap = new ConcurrentHashMap<>();messageMap.put("type", "0");messageMap.put("message", username + "加入8000端口的的当前在线人数为" + getOnlineCount());messageMap.put("to", "all");messageMap.put("users", webSocketMap.keySet());messageMap.put("username", "server");sendMessageAll(JSONUtil.toJsonStr(messageMap));}/*** 发送消息给所有用户** @param message* @throws IOException*/public void sendMessageAll(String message) {for (String key : webSocketMap.keySet()) {for (WebSocketHandler websocket : webSocketMap.get(key)) {websocket.session.getAsyncRemote().sendText(message);}}}/*** 连接关闭调用的方法*/@OnClosepublic void onClose() {if (StringUtils.isNotEmpty(this.username)) {try {if (this.session.isOpen()) {this.session.close();// 强制关闭}webSocketMap.get(username).remove(this);// 删除链接if (webSocketMap.get(username).isEmpty()) {webSocketMap.remove(username);subOnlineCount(); // 在线数减1// 刷新用户列表Map<String, Object> messageMap = new ConcurrentHashMap<>();messageMap.put("type", 0);messageMap.put("message", username + "退出！当前在线人数为" + getOnlineCount());messageMap.put("users", webSocketMap.keySet());sendMessageAll(JSONUtil.toJsonStr(messageMap));}} catch (Exception e) {System.err.println("关闭连接出错 : " + e.getLocalizedMessage());}}}/*** 收到客户端消息后调用的方法** @param message 客户端发送过来的消息*/@OnMessagepublic void onMessage(String message) {// 刷新心跳时间this.heartBeatTime = System.currentTimeMillis();// 群发消息cn.hutool.json.JSONObject messageJson = JSONUtil.parseObj(message);Object type = messageJson.get("type");// 消息类型Object toUser = messageJson.get("to");// 接收对象// 心跳检测if ("999".equals(type)) {Map<String, Object> messageMap = new ConcurrentHashMap<>();messageMap.put("type", "1");messageMap.put("message", "pong");messageMap.put("username", "服务器");messageMap.put("to", this.username);sendMessageOne(JSONUtil.toJsonStr(messageMap), this.username);return;}// 发送消息if ("All".equalsIgnoreCase(type + "")) {sendMessageAll(message);}else {sendMessageOne(message, toUser + "");}}/*** 发生错误时调用*/@OnErrorpublic void onError(Throwable error) {error.printStackTrace();}/*** 发送消息** @param message* @throws IOException*/public void sendMessage(String message){//this.session.getBasicRemote().sendText(message);//同步this.session.getAsyncRemote().sendText(message);// 异步}/*** 发送消息给指定用户** @param message* @param toUserName*/public void sendMessageOne(String message, String toUserName) {webSocketMap.keySet().forEach(e -> {if (e.equals(toUserName)) {webSocketMap.get(e).forEach(f -> {try {f.session.getAsyncRemote().sendText(message);} catch (Exception e2) {f.session.getAsyncRemote().sendText(message);}});}});}
}

package com.cqcloud.platform.service;/*** @author [e-mail]* @date 💓💕2022年9月8日🐬🐇💓💕*/
public interface IotMqttService {/*** 扩展传输原文* @param message*/void pushMessageArrived(byte[] message);
}

package com.cqcloud.platform.service.impl;import org.springframework.stereotype.Service;import com.cqcloud.platform.service.IotMqttService;import lombok.AllArgsConstructor;/*** @author [e-mail]* @date 💓💕2022年9月8日🐬🐇💓💕*/
@Service
@AllArgsConstructor
public class IotMqttServiceImpl implements IotMqttService {/*** 获取拓展接口原文值* @param message*/@Overridepublic void pushMessageArrived(byte[] message) {// 拓展方法TcpEventHandler.handleAlarm("设备号","告警信息");}
}

package com.cqcloud.platform.config;import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.socket.server.standard.ServerEndpointExporter;/*** @author [e-mail] ✨* @date 💓💕 2022年4月12日 🐬🐇 💓💕*/
@Configuration
public class WebSocketConfig {/*** 注入ServerEndpointExporter， 这个bean会自动注册使用了@ServerEndpoint注解声明的Websocket endpoint* @return*/@Beanpublic ServerEndpointExporter serverEndpointExporter() {return new ServerEndpointExporter();}
}

进行批量用户的id进行下发webscoket信息
