【unity之IMGUI实践】敌方逻辑封装实现【六】

---

👨‍💻个人主页：@元宇宙-秩沅

👨‍💻 hallo 欢迎 点赞👍 收藏⭐ 留言📝 加关注✅!

👨‍💻 本文由 秩沅 原创

👨‍💻 收录于专栏：unityUI专题篇

---

⭐通用API实现抽象行为封装【五】⭐

---

---

🎶前言

---

🅰️

---

🎶（A）UML

---

---

🎶（B）需求分析

---

---

🎶（C）行为实现——炮台的自动检测并攻击

---

---

😶‍🌫️：步骤实现
1.炮台的行为逻辑封装：旋转，触发检测，发射炮弹及特效
2.检测玩家后自动瞄准攻击
3.玩家扣血，更新血条，触发保护罩特效及死亡

---

——————————————

涉及到四个脚本

炮台封装

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
//-------------------------------------
//—————————————————————————————————————
//___________项目:       ______________
//___________功能： 炮台的行为逻辑实现
//___________创建者：秩沅_______________
//_____________________________________
//-------------------------------------
public class battery : TankFather
{public AudioSource shootMusic;   //发射音效public GameObject shootball;     //发射的子弹类型public float shootSpeed = 1000f; //子弹的速度 public Transform shootTransform; //发射的组件信息public bool shootSwitch = false;//射击检测参数public Transform player;         //闯入者private float endTime = 8f;      //子弹发射间隔的时间private void Start(){//属性初始化赋值Head = transform.GetChild(0);maxBlood = 500;nowBlood = 500;attack = 20;   HeadSpeed = 50;//射击音效关闭shootMusic.enabled = false;}private void Update(){  if (shootSwitch == false)   //不停的旋转{Head.transform.Rotate(Vector3.up * HeadSpeed * Time.deltaTime);}          else {Head.transform.LookAt(player);//倒计时发射子弹endTime = Mathf.MoveTowards(endTime, 0, 0.1f);if(endTime <= 0){Fire();endTime = 3f;}}     }//玩家进入范围内就开始射击private void OnTriggerEnter(Collider other){if(other.tag == "Player"){shootSwitch = true;player = other.transform;}}//受伤检测private void OnTriggerStay(Collider other){float off = Vector3.Distance(other.transform.position, transform.position);if (other.gameObject.tag == "bullet" && off < 2){//添加子弹挂载的目标坦克，方便获取该子弹的攻击力，与受伤逻辑相结合BulletMove ball = other.gameObject.GetComponent<BulletMove>();TankFather ballTank = ball.Tank.GetComponent<TankFather>();//当子弹不是自己打的到自己身上的时候if (ballTank.tag != gameObject.tag){//扣血Heart(ballTank);}}}//玩家出去后就停止射击private void OnTriggerExit(Collider other){if (other.tag == "Player"){shootSwitch = false;}}//开火重写public override void Fire(){//开启射击音效shootMusic.enabled = true;shootMusic.Play();GameObject ball =  Instantiate(shootball, shootTransform.position , shootTransform.rotation);BulletMove movScript = ball.GetComponent<BulletMove>();Rigidbody shootBall = ball.GetComponent<Rigidbody>();shootBall.AddForce(shootTransform .transform.forward * shootSpeed );movScript.Tank =gameObject ;  //声明子弹是由谁打出去的}}

坦克基类更新

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
//-------------------------------------
//—————————————————————————————————————
//___________项目:
//___________功能： 坦克基类——集中子类相同点
//___________创建者：______秩沅______
//___________________________________
//-------------------------------------
public abstract  class TankFather : MonoBehaviour
{//攻击和防御相关public int attack;public int defence; public float  nowBlood;public float  maxBlood;//移动和转速相关public int moveSpeed;public int RotateSpeed;public int HeadSpeed;public Transform  Head;//击败特效public GameObject diedEffect;//收到伤害打开保护罩的特效public GameObject ProtectEffectMain;public GameObject ProtectEffectOther;private void Awake(){// ProtectEffectMain = Resources.Load<GameObject>(@"Prefabs/OherResoure/Protect1");// ProtectEffectOther = Resources.Load<GameObject>(@"Prefabs/OherResoure/Protect2");}//受伤行为public virtual  void Heart(TankFather other){//当攻击力大于防御力时才生效if (other.attack - defence > 0){nowBlood -= (other.attack - defence);}if (nowBlood <= 0){nowBlood = 0;Death();}if (gameObject.tag == "Player")//如果是主玩家才更新血条{//更新血条GamePlane.SingleInstance.UpdataBlood(maxBlood, nowBlood);//实例化保护罩的特效       GameObject eff = Instantiate(ProtectEffectMain, transform.position, transform.rotation);Destroy(eff,1f);}}//死亡行为public virtual  void Death(){//将特效实例化相关逻辑GameObject effect = Instantiate(diedEffect, this.transform.position ,this.transform.rotation);AudioSource soudClip = effect.GetComponent<AudioSource>();soudClip.enabled  = MusicContol.SingleMusicContol.nowMusicData.soundSwitch;soudClip.volume = MusicContol.SingleMusicContol.nowMusicData.soundRoll ;soudClip.mute = false;soudClip.playOnAwake = true;//死亡后展示死亡面板if (gameObject.tag == "Player"){Destroy(gameObject, 2F);DiedPlane.SingleInstance.Show();}elseDestroy(gameObject);}//开火行为public abstract void Fire();  //子类中每一个的开火方式都不同，作为抽象方法}

主坦克类更新

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
//-------------------------------------
//—————————————————————————————————————
//___________项目:
//___________功能：  坦克的移动和旋转
//___________创建者：_______秩沅_______
//_____________________________________
//-------------------------------------
public class MainTank : TankFather
{//主坦克专有特征public  Weapon nowWeapon;//特征属性初始化private void Awake(){Head = transform.GetChild(1).GetChild(0);maxBlood = 1000;nowBlood = 1000;attack = 30;defence = 10;moveSpeed = 5;RotateSpeed = 50;HeadSpeed = 500;}private void Update(){//坦克的移动 = 大小*方向transform.Translate(Input.GetAxis("Vertical") *Vector3.forward*moveSpeed *Time.deltaTime );//坦克的旋转 = 大小*轴向transform.Rotate(Input.GetAxis("Horizontal") *Vector3.up *RotateSpeed *Time .deltaTime );//头部炮管的旋转 = 大小*轴向Head.Rotate(Input.GetAxis ("Mouse X") *Vector3.up*HeadSpeed*Time .deltaTime );//左键发射炮弹if(Input.GetMouseButtonDown(0)){Fire();}}//捡武器行为public void ChangeWeapon(GameObject weapon){if (nowWeapon != null) nowWeapon.Vanish();  //销毁当前武器nowWeapon = weapon.GetComponent<Weapon>();       //头部留有存放武器的位置weapon.gameObject.transform.position = Head.GetChild(0).transform.position ;weapon.gameObject.transform.rotation = Head.GetChild(0).transform.rotation;weapon.gameObject.transform.SetParent(Head.GetChild(0));attack += nowWeapon.attack;}//开火行为重写public override void Fire() {nowWeapon.Shoot(); }//被子弹打到private void OnTriggerEnter(Collider other){if(other.tag == "bullet"){try{//添加子弹挂载的目标坦克，方便获取该子弹的攻击力，与受伤逻辑相结合BulletMove ball = other.GetComponent<BulletMove>();TankFather ballTank = ball.Tank.GetComponent<TankFather>();//当子弹不是自己打的到自己身上的时候if (ballTank.tag != "Player"){//扣血Heart(ballTank);}}catch{throw;}}}}

子弹发射更新

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
//-------------------------------------
//—————————————————————————————————————
//___________项目:       ______________
//___________功能：  子弹的逻辑相关
//___________创建者：秩沅_______________
//_____________________________________
//-------------------------------------
public class BulletMove : MonoBehaviour
{public  GameObject Tank;          //挂载在哪个坦克上public  GameObject DeidEffect;public  AudioSource distorySound; //销毁的音效private void Start(){}//子弹的销毁及特效private void OnTriggerEnter(Collider other){if (other.CompareTag("Environment")|| other.CompareTag("Enemy")){if (DeidEffect != null){GameObject eff =  Instantiate(DeidEffect, transform.position, transform.rotation);//音效控制distorySound = eff.GetComponent<AudioSource>();distorySound.enabled = MusicContol.SingleMusicContol.nowMusicData.soundSwitch;distorySound.volume = MusicContol.SingleMusicContol.nowMusicData.soundRoll;eff.AddComponent<SelfDestroy>();}Destroy(this.gameObject,2f);          }    }}

---

🎶（D）行为实现——敌军坦克的移动路线和检测攻击

---

😶‍🌫️：步骤实现

• 1.指定移动位置，设置朝向
• 2.行为逻辑封装。开火，受伤
• 3.自动检测闯入者

---

———— --------------————

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
//-------------------------------------
//—————————————————————————————————————
//___________项目:
//___________功能：敌方坦克逻辑封装
//___________创建者：秩沅_______________
//_____________________________________
//-------------------------------------
public class EnemyTank:TankFather
{//随机移动点的位置数组public  Transform[] randomPosition;//目标位置private Transform target;//目标坦克public Transform Player;//检测范围public float distance = 10f;public AudioSource shootMusic;   //发射音效public GameObject shootball;     //发射的子弹类型public float shootSpeed = 1000f; //子弹的速度 public Transform[] shootTransform; //发射的组件信息public bool shootSwitch = false;  private float endTime = 3f;      //子弹发射间隔的时间private void Start(){//属性初始化赋值maxBlood = 500;nowBlood = 500;attack = 30;HeadSpeed = 50;//射击音效关闭shootMusic.enabled = false;moveSpeed = 10f;//先随机整一个目标点RandomPosition();}private void Update(){    transform.LookAt(target);//始终超自己的正方向移动transform.Translate(Vector3.forward * moveSpeed * Time.deltaTime);  //当距离差不多相等时，再随机目标点if(Vector3.Distance(transform .position ,target .position)< 0.5f){RandomPosition();}//范围检测if (Vector3 .Distance(transform .position ,Player.position )<= distance && Player !=null ){//炮口瞄准玩家Head.transform.LookAt(Player);//倒计时发射子弹endTime = Mathf.MoveTowards(endTime, 0, 0.1f);if (endTime <= 0){Fire();endTime = 3f;}        }}//随机指向一个移动点public void RandomPosition(){if (randomPosition.Length != 0)target = randomPosition[Random.Range(0, randomPosition.Length)];}//触发检测private void OnTriggerEnter(Collider other){if (other.gameObject.tag == "bullet" ){//添加子弹挂载的目标坦克，方便获取该子弹的攻击力，与受伤逻辑相结合BulletMove ball = other.gameObject.GetComponent<BulletMove>();TankFather ballTank = ball.Tank.GetComponent<TankFather>();//当子弹不是自己打的到自己身上的时候if (ballTank.tag != gameObject.tag){//扣血Heart(ballTank);}}}public override void Fire(){//开启射击音效shootMusic.enabled = true;shootMusic.Play();for (int i = 0; i < shootTransform.Length ; i++){GameObject ball = Instantiate(shootball, shootTransform[i].position, shootTransform[i].rotation);BulletMove movScript = ball.GetComponent<BulletMove>();Rigidbody shootBall = ball.GetComponent<Rigidbody>();shootBall.AddForce(shootTransform[i].transform.forward * shootSpeed);movScript.Tank = gameObject;  //声明子弹是由谁打出去的}}}

问题：
1.受到伤害，开启了保护罩但是不扣血
2.敌方坦克，原地打转，未按规定路线移动
解决：
1.子弹检测逻辑错误
2.位置空点绑定在对象身上变成了子对象因此无法达到效果

总结：

• 1.检测触发的方式：①触发器检测②向量距离检测
• 2.多点指定移动，加入向量距离判断，重合的机率小，故此不能 A物体距离 == B物体距离
• 3.子坦克继承了父类脚本，引用传递时直接用父类即可获得该子类，（原因父类名字相同，但是子类名字不同，无法确定，所以里氏替换作用在此体现）

---
